Earth Science Frontiers ›› 2025, Vol. 32 ›› Issue (2): 290-310.DOI: 10.13745/j.esf.sf.2024.2.22
Previous Articles Next Articles
ZHU Ziguang1(), ZHU Guangyou2,*(
), LI Xi1
Received:
2023-12-13
Revised:
2024-02-29
Online:
2025-03-25
Published:
2025-03-25
CLC Number:
ZHU Ziguang, ZHU Guangyou, LI Xi. The enrichment mechanism of U element in black shale and its significant influence on the performance of organic matter oil and gas production[J]. Earth Science Frontiers, 2025, 32(2): 290-310.
Fig.1 Schematic diagram of U morphology of seawater system with Eh-Ph. Modified after [24]. (gray area represents minerals, white area represents dissolved uranyl complex)
富集类型 | 富集方式 | 富集机理 | 价态 | 实例 | 数据来源 |
---|---|---|---|---|---|
有机质 | 络合 | 有机化合物(富里酸和腐殖酸)和U络合形成稳定的化合物 | U(Ⅳ) U(Ⅵ) | 有机化合物的类型 环境的pH值 | 文献[ |
物理吸附 | 有机质本身作为一种良好的吸附剂将U吸附在其表面 | U(Ⅳ) U(Ⅵ) | 环境的pH值 | 文献[ | |
还原 | 有机质热演化过程中分解的H2S,CH4,H2和NH3等强还原物质 | U(Ⅵ) | 温度 | 文献[ | |
微生物 | 生物还原作用 | 微生物通过细胞色素、菌毛、电子穿梭体等介质向U传输电子 | U(Ⅵ) | 乙醇或乙酸盐浓度 环境金属离子浓度 | 文献[ |
生物吸附作用 | U被动且快速地吸附在微生物的表面 | U(Ⅳ) U(Ⅵ) | 环境pH和离子强度,环境 金属离子浓度,环境U浓度 | 文献[ | |
生物矿化作用 | U在微生物表面沉淀形成结晶或结晶结构 | U(Ⅵ) | 环境的pH值 | 文献[ | |
生物积聚作用 | 微生物主动摄取与微生物必需元素相近的金属元素 | U(Ⅳ) U(Ⅵ) | 环境pH值 碳酸盐碱度 | 文献[ | |
黏土矿物 | 吸附 | 黏土矿物的结构表面和颗粒边缘产生电荷对U产生吸附作用 | U(Ⅳ) U(Ⅵ) | 硫酸盐、碳酸盐、磷酸盐,黏土矿物的类型,环境金属离子浓度,腐殖酸;环境pH | 文献[ |
含铁矿物 | 吸附 | 含铁矿物本身作为一种良好的吸附剂将U吸附在其表面 | U(Ⅳ) U(Ⅵ) | 环境pH,碳酸盐浓度 | 文献[ |
还原 | 含铁矿物对U的还原主要通过Fe(Ⅱ)来完成 | U(Ⅵ) | 矿物的表面催化作用, 环境pH,可溶性的Fe(Ⅱ) | 文献[ | |
含硫矿物 | 吸附 | 含硫矿物表面不均匀吸附U | U(Ⅵ) | 环境pH、溶解性有机质 | 文献[ |
还原 | 含硫基团对U(Ⅵ)的还原 | U(Ⅵ) | 环境pH | 文献[ | |
含磷矿物 | 络合 | 磷酸盐和U形成稳定的络合物 | U(Ⅵ) | 环境pH,碳酸盐含量 | 文献[ |
Table 1 Methods and types of U enrichment of different components in black shale
富集类型 | 富集方式 | 富集机理 | 价态 | 实例 | 数据来源 |
---|---|---|---|---|---|
有机质 | 络合 | 有机化合物(富里酸和腐殖酸)和U络合形成稳定的化合物 | U(Ⅳ) U(Ⅵ) | 有机化合物的类型 环境的pH值 | 文献[ |
物理吸附 | 有机质本身作为一种良好的吸附剂将U吸附在其表面 | U(Ⅳ) U(Ⅵ) | 环境的pH值 | 文献[ | |
还原 | 有机质热演化过程中分解的H2S,CH4,H2和NH3等强还原物质 | U(Ⅵ) | 温度 | 文献[ | |
微生物 | 生物还原作用 | 微生物通过细胞色素、菌毛、电子穿梭体等介质向U传输电子 | U(Ⅵ) | 乙醇或乙酸盐浓度 环境金属离子浓度 | 文献[ |
生物吸附作用 | U被动且快速地吸附在微生物的表面 | U(Ⅳ) U(Ⅵ) | 环境pH和离子强度,环境 金属离子浓度,环境U浓度 | 文献[ | |
生物矿化作用 | U在微生物表面沉淀形成结晶或结晶结构 | U(Ⅵ) | 环境的pH值 | 文献[ | |
生物积聚作用 | 微生物主动摄取与微生物必需元素相近的金属元素 | U(Ⅳ) U(Ⅵ) | 环境pH值 碳酸盐碱度 | 文献[ | |
黏土矿物 | 吸附 | 黏土矿物的结构表面和颗粒边缘产生电荷对U产生吸附作用 | U(Ⅳ) U(Ⅵ) | 硫酸盐、碳酸盐、磷酸盐,黏土矿物的类型,环境金属离子浓度,腐殖酸;环境pH | 文献[ |
含铁矿物 | 吸附 | 含铁矿物本身作为一种良好的吸附剂将U吸附在其表面 | U(Ⅳ) U(Ⅵ) | 环境pH,碳酸盐浓度 | 文献[ |
还原 | 含铁矿物对U的还原主要通过Fe(Ⅱ)来完成 | U(Ⅵ) | 矿物的表面催化作用, 环境pH,可溶性的Fe(Ⅱ) | 文献[ | |
含硫矿物 | 吸附 | 含硫矿物表面不均匀吸附U | U(Ⅵ) | 环境pH、溶解性有机质 | 文献[ |
还原 | 含硫基团对U(Ⅵ)的还原 | U(Ⅵ) | 环境pH | 文献[ | |
含磷矿物 | 络合 | 磷酸盐和U形成稳定的络合物 | U(Ⅵ) | 环境pH,碳酸盐含量 | 文献[ |
