Petrogenesis of the Early Cretaceous Jiguanshan granite porphyry in the Liaodong Peninsula: Constraints from geochemistry and single mineral U-Pb-Hf-Nd isotopes

doi:10.13745/j.esf.sf.2024.11.81

Abstract

Abstract:

We systematically study the characteristics of zircon U-Pb geochronology, whole-rock major and trace elements, in-situ apatite trace elements and Nd isotopes, and in-situ zircon Hf isotopes of the Jiguanshan granite porphyry in the Liaodong Peninsula, northeastern North China Craton, aiming to reevaluate its emplacement age and petrogensis, and further to constrain its tectonic significance. The zircon grains in the Jiguanshan granite porphyry show euhedral to subhedral textures, typical oscillatory growth zoning, and high Th/U(0.27-1.12) ratios, indicating a magmatic origin. The zircon U-Pb dating results of fifteen magmatic zircon grains illustrate that the Jiguanshan granite porphyry formed in Early Cretaceous(126±1.4 Ma). The Jiguanshan granite porphyry shows relatively high SiO₂(75.70%-76.07%) and alkali(Na₂O+K₂O, 7.88%-8.30%) but low MgO(0.08%-0.15%) contents (mass fraction). The aluminum saturation index of the Jiguanshan granite porphyry ranges from 1.19 to 1.30, with a peraluminous characteristics. In addition, the Jiguanshan granite porphyry is enriched in light rare earth elements(LREEs), but depleted in heavy rare earth elements(HREEs) with distinctly negative Eu anomalies(Eu/Eu^*=0.36-0.51). Furthermore, the Jiguanshan granite porphyry exhibits a typical arc affinity, with enrichment in large ion lithophile elements(LILEs; e.g., Rb, Th, U) and depletion in high field strength elements(HFSEs; e.g., Nb, Ta). The apatite grains in the Jiguanshan granite porphyry are of magmatic origin. They are enriched in LREEs and LILEs, and depleted in HREEs and HFSEs, with distinctly negative Eu anomalies(Eu/Eu^*=0.11-0.24), which are similar with its host rock. The Jiguanshan granite porphyry belongs to highly fractionated I-type granite. Combining with the relatively low zircon ε_Hf(t) values(-15.5 to -20.1), and apatite ε_Nd(t) values(-15.0 to -16.7), as well as relatively old two-stage Nd-Hf model age (2454-2135 Ma), we believe that the Jiguanshan granite porphyry originated from partial melting of the Paleoproterozoic lower crust that mainly consists of meta-igneous rocks of the Liaohe Group. In combination with the extensive distribution of A-type granites, metamorphic core complexes and large-scale extensional basins in the study area, as well as the migration of magmatic activity from inland to trench during the Late Jurassic to Early Cretaceous, we conclude that the Jiguanshan granite porphyry formed in the extensional tectonic setting related to the roll-back of the subducted Paleo-Pacific plate towards the northeastern North China Craton.

Key words: Liaodong Peninsula, Early Cretaceous, granite porphyry, apatite, zircon

CLC Number:

WU Ke, YAN Xiangyu, YANG Donghong. Petrogenesis of the Early Cretaceous Jiguanshan granite porphyry in the Liaodong Peninsula: Constraints from geochemistry and single mineral U-Pb-Hf-Nd isotopes[J]. Earth Science Frontiers, 2025, 32(4): 388-404.

Figures/Tables 17

References 62

[1]	WU F Y, YANG J H, XU Y G, et al. Destruction of the North China Craton in the Mesozoic[J]. Annual Review of Earth and Planetary Sciences, 2019, 47: 173-195.
[2]	YANG J H, WU F Y, WILDE S A, et al. Mesozoic decratonization of the North China Block[J]. Geology, 2008, 36(6): 467.
[3]	吴福元, 杨进辉, 柳小明. 辽东半岛中生代花岗质岩浆作用的年代学格架[J]. 高校地质学报, 2005, 11(3): 305-317.
[4]	WU F Y, LIN J Q, WILDE S, et al. Nature and significance of the Early Cretaceous giant igneous event in Eastern China[J]. Earth and Planetary Science Letters, 2005, 233: 103-119.
[5]	WU F Y, YANG J H, WILDE S A, et al. Geochronology, petrogenesis and tectonic implications of Jurassic granites in the Liaodong Peninsula, NE China[J]. Chemical Geology, 2005, 221(1/2): 127-156.
[6]	路孝平, 吴福元, 林景仟, 等. 辽东半岛南部早前寒武纪花岗质岩浆作用的年代学格架[J]. 地质科学, 2004, 39(1): 123-138.
[7]	QUAN Y K, YANG D B, YANG H T, et al. Petrogenesis of Jurassic granitic plutons in Liaodong Peninsula, NE China: insights into the subduction of Paleo-Pacific plate[J]. Journal of Asian Earth Sciences, 2022, 236:105310.
[8]	QUAN Y K, YANG D B, MU M S, et al. Tectonic evolution of the northeastern North China Craton: constraints from geochronology and Sr-Nd-Hf-O isotopic data from Late Triassic intrusive rocks on Liaodong Peninsula, NE China[J]. Lithos, 2020, 362: 105489.
[9]	QUAN Y K, YANG D B, YANG H T, et al. Reworking of continental crust on northeastern North China Craton: evidence from geochronology and geochemistry of Early Cretaceous granitic rocks[J]. Tectonophysics, 2022, 829: 229306.
[10]	JI Z, GE W C, HE Y, et al. Mixing of cognate magmas as a process for producing high-silica granites: insights from Guanmenshan Complex in Liaodong Peninsula, China[J]. Lithos, 2021, 406: 106495.
[11]	LIU Y, WEI J H, ZHANG D H, et al. Mesozoic crustal reworking at different depths in the North China Craton: insight from the coexisting Early Cretaceous high and low Sr/Y granitoids[J]. Lithos, 2023, 462/463:107402.
[12]	李三忠, 郝德峰, 赵国春, 等. 丹东花岗岩的地球化学特征及其成因[J]. 岩石学报, 2004, 20(6): 1417-23
[13]	孟恩, 刘福来, 施建荣, 等. 丹东地区前震旦纪花岗岩年代学[J]. 岩石学报, 2012, 29(2): 421-436.
[14]	辽宁省地质矿产局. 辽林省区域地质志[M]. 北京: 地质出版社, 2001.
[15]	ZHAO G C, CAWOOD P A, WILDE S A, et al. High-pressure granulites (retrograded eclogites) from the Hengshan complex, North China Craton: petrology and tectonic implications[J]. Journal of Petrology, 2001, 42(6): 1141-1170.
[16]	ZHU R X, XU Y G. The subduction of the west Pacific plate and the destruction of the North China Craton[J]. Science China Earth Sciences, 2019, 62(9): 1340-1350.
[17]	MU M S, YANG D B, YANG H T, et al. Petrogenesis and tectonic implications of the Paleoproterozoic gaoliduntai plagiogranites in the Jiao-Liao-Ji Belt, North China Craton[J]. Precambrian Research, 2022, 368: 106465.
[18]	MU M S, YANG D B, YANG H T, et al. Petrogenesis of late Paleoproterozoic post-collisional magmatism in southern North China Craton: insights from geochemistry and Nd-Hf isotopic compositions of A-type granites[J]. Precambrian Research, 2022, 383: 106887.
[19]	QUAN Y K, MU M S, YANG D B, et al. Geochronology and in situ apatite geochemistry of late Paleoproterozoic A-type granites in the Jiao-Liao-Ji Belt, North China Craton: implications for petrogenesis and tectonic evolution[J]. Geochemistry, 2023, 83(4): 126009.
[20]	崔维龙, 刘正宏, 杜洋, 等. 辽东地区大兴岩体LA-ICP-MS锆石U-Pb定年、地球化学特征及地质意义[J]. 地球科学与环境学报, 2016, 38(5): 623-637.
[21]	YANG J H, WU F Y, CHUNG S L, et al. A hybrid origin for the Qianshan A-type granite, Northeast China: geochemical and Sr-Nd-Hf isotopic evidence[J]. Lithos, 2006, 89(1/2): 89-106.
[22]	刘杰勋. 华北克拉通北缘东段辽东地区中生代构造演化[D]. 长春: 吉林大学, 2019.
[23]	ZONG K Q, KLEMD R, YUAN Y, et al. The assembly of Rodinia: the correlation of early Neoproterozoic (ca. 900 Ma) high-grade metamorphism and continental arc formation in the southern Beishan Orogen, southern Central Asian Orogenic Belt (CAOB)[J]. Precambrian Research, 2017, 290: 32-48.
[24]	WIEDENBECK M, ALLÉ P, CORFU F, et al. Three natural zircon standards for U-Th-Pb, Lu-Hf, trace element and ree analyses[J]. Geostandards Newsletter, 1995, 19(1): 1-23.
[25]	MA Q, ZHENG J P, GRIFFIN W L, et al. Triassic “adakitic” rocks in an extensional setting (North China): melts from the cratonic lower crust[J]. Lithos, 2012, 149: 159-173.
[26]	HU Z C, LIU Y S, GAO S, et al. Improved in situ Hf isotope ratio analysis of zircon using newly designed X skimmer cone and jet sample cone in combination with the addition of nitrogen by laser ablation multiple collector ICP-MS[J]. Journal of Analytical Atomic Spectrometry, 2012, 27(9): 1391-1399.
[27]	GRIFFIN W L, PEARSON N J, BELOUSOVA E A, et al. Comment: Hf-isotope heterogeneity in zircon 91500[J]. Chemical Geology, 2006, 233(3/4): 358-363.
[28]	QIAN S P, ZHANG L. Simultaneous in situ determination of rare earth element concentrations and Nd isotope ratio in apatite by laser ablation ICP-MS[J]. Geochemical Journal, 2019, 53(5): 319-328.
[29]	YANG Y H, WU F Y, YANG J H, et al. Sr and Nd isotopic compositions of apatite reference materials used in U-Th-Pb geochronology[J]. Chemical Geology, 2014, 385: 35-55.
[30]	BELOUSOVA E, GRIFFIN W, O’REILLY S Y, et al. Igneous zircon: trace element composition as an indicator of source rock type[J]. Contributions to Mineralogy and Petrology, 2002, 143(5): 602-622.
[31]	MIDDLEMOST E A K. Naming materials in the magma/igneous rock system[J]. Earth-Science Reviews, 1994, 37(3/4): 215-224.
[32]	PECCERILLO A, TAYLOR S. Geochemistry of Eocene calc-alkaline volcanic rocks from the Kastamonu area, Northern Turkey[J]. Contributions to Mineralogy and Petrology, 1976, 58(1): 63-81.
[33]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publications, 1989, 42(1): 313-345.
[34]	BELOUSOVA E A, GRIFFIN W L, O’REILLY S Y, et al. Apatite as an indicator mineral for mineral exploration: trace-element compositions and their relationship to host rock type[J]. Journal of Geochemical Exploration, 2002, 76(1): 45-69.
[35]	O’SULLIVAN G, CHEW D, KENNY G, et al. The trace element composition of apatite and its application to detrital provenance studies[J]. Earth-Science Reviews, 2020, 201: 103044.
[36]	郭春丽, 吴福元, 杨进辉, 等. 中国东部早白垩世岩浆作用的伸展构造性质: 以辽东半岛南部饮马湾山岩体为例[J]. 岩石学报, 2004, 20(5): 204-215.
[37]	WU F Y, LIU X C, JI W Q, et al. Highly fractionated granites: recognition and research[J]. Science China Earth Sciences, 2017, 60(7): 1201-1219.
[38]	GREEN T H. Significance of Nb/Ta as an indicator of geochemical processes in the crust-mantle system[J]. Chemical Geology, 1995, 120(3/4): 347-359.
[39]	MichaelBau. Controls on the fractionation of isovalent trace elements in magmatic and aqueous systems: evidence from Y/Ho, Zr/Hf, and lanthanide tetrad effect[J]. Contributions to Mineralogy and Petrology, 1996, 123(3): 323-333.
[40]	WHALEN J B, CURRIE K L, CHAPPELL B W. A-type granites: geochemical characteristics, discrimination and petrogenesis[J]. Contributions to Mineralogy and Petrology, 1987, 95(4): 407-419.
[41]	CHAPPELL B W, WHITE A J R. Two contrasting granite types[J]. Pacific Geology, 1974, 8(2): 173-174.
[42]	WATSON E B, HARRISON T M. Zircon saturation revisited: temperature and composition effects in a variety of crustal magma types[J]. Earth and Planetary Science Letters, 1983, 64(2): 295-304.
[43]	CHAPPELL B W, WHITE A J R. I- and S-type granites in the Lachlan fold belt[J]. Earth and Environmental Science Transactions of the Royal Society of Edinburgh, 1992, 83(1/2): 1-26.
[44]	HSIEH P S, CHEN C H, YANG H J, et al. Petrogenesis of the Nanling Mountains granites from South China: constraints from systematic apatite geochemistry and whole-rock geochemical and Sr-Nd isotope compositions[J]. Journal of Asian Earth Sciences, 2008, 33(5/6): 428-451.
[45]	BELOUSOVA E A, WALTERS S, GRIFFIN W L, et al. Trace-element signatures of apatites in granitoids from the Mt Isa Inlier, northwestern Queensland[J]. Australian Journal of Earth Sciences, 2001, 48(4): 603-619.
[46]	GAO S, LUO T C, ZHANG B R, et al. Chemical composition of the continental crust as revealed by studies in East China[J]. Geochimica et Cosmochimica Acta, 1998, 62(11): 1959-1975.
[47]	GAO L E, ZENG L S, ASIMOW P D. Contrasting geochemical signatures of fluid-absent versus fluid-fluxed melting of muscovite in metasedimentary sources: the Himalayan leucogranites[J]. Geology, 2017, 45(1): 39-42.
[48]	孟恩, 王朝阳, 刘超辉, 等. 辽东半岛东南部南辽河群变质火山岩的时代、成因及其对区域构造演化的制约[J]. 吉林大学学报(地球科学版), 2017, 47(6): 1589-1619.
[49]	ALTHERR R, SIEBEL W. I-type plutonism in a continental back-arc setting: miocene granitoids and monzonites from the central Aegean Sea, Greece[J]. Contributions to Mineralogy and Petrology, 2002, 143(4): 397-415.
[50]	QUAN Y K, YANG D B, YAN X Y, et al. Petrogenesis of Mesozoic granitoids in the northeastern North China Craton: constraints from apatite trace elements and in situ Nd isotopic data[J]. Lithos, 2023, 450: 107190.
[51]	HOSKIN P W O, KINNY P D, WYBORN D, et al. Identifying accessory mineral saturation during differentiation in granitoid magmas: an integrated approach[J]. Journal of Petrology, 2000, 41(9): 1365-1396.
[52]	PICCOLI P M, CANDELA P A. Apatite in igneous systems[J]. Reviews in Mineralogy and Geochemistry, 2002, 48(1): 255-292.
[53]	PROWATKE S, KLEMME S. Trace element partitioning between apatite and silicate melts[J]. Geochimica et Cosmochimica Acta, 2006, 70(17): 4513-4527.
[54]	MILES A J, GRAHAM C M, HAWKESWORTH C J, et al. Evidence for distinct stages of magma history recorded by the compositions of accessory apatite and zircon[J]. Contributions to Mineralogy and Petrology, 2013, 166(1): 1-19.
[55]	YAN X Y, YANG D B, XU W L, et al. Apatite geochemistry from mafic rocks in the northeastern North China Craton: new insights into petrogenesis[J]. Lithos, 2023, 436: 106942.
[56]	SUN J F, YANG J H, ZHANG J H, et al. Apatite geochemical and Sr-Nd isotopic insights into granitoid petrogenesis[J]. Chemical Geology, 2021, 566: 120104.
[57]	STEPANOV A S, HERMANN J, RUBATTO D, et al. Experimental study of monazite/melt partitioning with implications for the REE, Th and U geochemistry of crustal rocks[J]. Chemical Geology, 2012, 300: 200-220.
[58]	BARTH S, OBERLI F, MEIER M. Th-Pb versus U-Pb isotope systematics in allanite from co-genetic rhyolite and granodiorite: implications for geochronology[J]. Earth and Planetary Science Letters, 1994, 124(1/2/3/4): 149-159.
[59]	PEARCE J A, HARRIS N B W, TINDLE A G. Trace element discrimination diagrams for the tectonic interpretation of granitic rocks[J]. Journal of Petrology, 1984, 25(4): 956-983.
[60]	LIN W, WANG Q C, WANG J, et al. Late Mesozoic extensional tectonics of the Liaodong Peninsula massif: response of crust to continental lithosphere destruction of the North China Craton[J]. Science China Earth Sciences, 2011, 54(6): 843-857.
[61]	MA Q, XU Y G. Magmatic perspective on subduction of Paleo-Pacific plate and initiation of big mantle wedge in East Asia[J]. Earth-Science Reviews, 2021, 213: 103473.
[62]	YAN X Y, YANG D B, XU W L, et al. Identification of metasomatic components in lithospheric mantle under multiple tectonic regimes: insights from Early Cretaceous mafic rocks in the northeastern North China Craton[J]. Lithos, 2023, 454: 107262.

测点号	w_B/10^-6		Th/ U	同位素比值及误差							年龄及误差/Ma
测点号	Th	U	Th/ U	²⁰⁷Pb/ ²⁰⁶Pb	1σ	²⁰⁷Pb/ ²³⁵U	1σ	²⁰⁶Pb/ ²³⁸U	1σ		²⁰⁷Pb/ ²⁰⁶Pb	1σ	²⁰⁷Pb/ ²³⁵U	1σ	²⁰⁶Pb/ ²³⁸U	1σ
21L03-1-1	420	903	0.47	0.048 97	0.002 55	0.130 95	0.006 72	0.019 27		0.000 20	146	98	125	6	123	1
21L03-1-2	584	1 097	0.53	0.049 49	0.002 03	0.138 36	0.005 67	0.020 16		0.000 22	171	76	132	5	129	1
21L03-1-3	682	946	0.72	0.048 89	0.001 75	0.135 04	0.004 73	0.019 99		0.000 25	143	58	129	4	128	2
21L03-1-4	472	522	0.90	0.049 73	0.002 87	0.128 63	0.007 27	0.018 76		0.000 28	182	102	123	7	120	2
21L03-1-5	907	808	1.12	0.053 08	0.003 31	0.146 59	0.008 70	0.020 07		0.000 42	332	97	139	8	128	3
21L03-1-6	261	253	1.03	0.058 25	0.004 75	0.155 15	0.012 13	0.019 63		0.000 36	539	140	146	11	125	2
21L03-1-8	313	671	0.47	0.048 99	0.003 01	0.134 32	0.008 35	0.019 76		0.000 26	147	116	128	7	126	2
21L03-1-10	457	1 134	0.40	0.049 62	0.001 77	0.136 20	0.004 87	0.019 83		0.000 18	177	66	130	4	127	1
21L03-1-11	247	494	0.50	0.050 51	0.002 07	0.135 59	0.005 38	0.019 58		0.000 20	219	73	129	5	125	1
21L03-1-12	385	737	0.52	0.050 87	0.003 55	0.138 77	0.010 22	0.019 66		0.000 27	235	142	132	9	125	2
21L03-1-13	745	1 136	0.66	0.049 29	0.002 42	0.135 40	0.006 53	0.019 91		0.000 22	162	90	129	6	127	1
21L03-1-14	88	322	0.27	0.052 02	0.004 05	0.139 97	0.010 57	0.01975		0.00037	286	138	133	9	126	2
21L03-1-15	235	233	1.01	0.058 72	0.003 58	0.158 00	0.008 76	0.019 83		0.000 32	557	93	149	8	127	2

测点号	w_B/10^-6		Th/ U	同位素比值及误差							年龄及误差/Ma
测点号	Th	U	Th/ U	²⁰⁷Pb/ ²⁰⁶Pb	1σ	²⁰⁷Pb/ ²³⁵U	1σ	²⁰⁶Pb/ ²³⁸U	1σ		²⁰⁷Pb/ ²⁰⁶Pb	1σ	²⁰⁷Pb/ ²³⁵U	1σ	²⁰⁶Pb/ ²³⁸U	1σ
21L03-1-1	420	903	0.47	0.048 97	0.002 55	0.130 95	0.006 72	0.019 27		0.000 20	146	98	125	6	123	1
21L03-1-2	584	1 097	0.53	0.049 49	0.002 03	0.138 36	0.005 67	0.020 16		0.000 22	171	76	132	5	129	1
21L03-1-3	682	946	0.72	0.048 89	0.001 75	0.135 04	0.004 73	0.019 99		0.000 25	143	58	129	4	128	2
21L03-1-4	472	522	0.90	0.049 73	0.002 87	0.128 63	0.007 27	0.018 76		0.000 28	182	102	123	7	120	2
21L03-1-5	907	808	1.12	0.053 08	0.003 31	0.146 59	0.008 70	0.020 07		0.000 42	332	97	139	8	128	3
21L03-1-6	261	253	1.03	0.058 25	0.004 75	0.155 15	0.012 13	0.019 63		0.000 36	539	140	146	11	125	2
21L03-1-8	313	671	0.47	0.048 99	0.003 01	0.134 32	0.008 35	0.019 76		0.000 26	147	116	128	7	126	2
21L03-1-10	457	1 134	0.40	0.049 62	0.001 77	0.136 20	0.004 87	0.019 83		0.000 18	177	66	130	4	127	1
21L03-1-11	247	494	0.50	0.050 51	0.002 07	0.135 59	0.005 38	0.019 58		0.000 20	219	73	129	5	125	1
21L03-1-12	385	737	0.52	0.050 87	0.003 55	0.138 77	0.010 22	0.019 66		0.000 27	235	142	132	9	125	2
21L03-1-13	745	1 136	0.66	0.049 29	0.002 42	0.135 40	0.006 53	0.019 91		0.000 22	162	90	129	6	127	1
21L03-1-14	88	322	0.27	0.052 02	0.004 05	0.139 97	0.010 57	0.01975		0.00037	286	138	133	9	126	2
21L03-1-15	235	233	1.01	0.058 72	0.003 58	0.158 00	0.008 76	0.019 83		0.000 32	557	93	149	8	127	2

样品号	主量元素含量/%
样品号	SiO₂	TiO₂	Al₂O₃	^TFe₂O₃	MnO	MgO	CaO	Na₂O	K₂O	P₂O₅	LOI	Total
21L03-1	75.70	0.14	13.00	1.51	0.05	0.15	0.11	3.25	4.96	0.04	0.81	99.72
21L03-5	76.03	0.10	13.51	1.24	0.02	0.09	0.09	3.06	4.82	0.02	0.87	99.86
21L03-6	76.07	0.10	13.17	1.08	0.02	0.08	0.11	3.12	5.19	0.01	0.61	99.56
样品号	微量元素含量/10^-6
样品号	Be	Sc	V	Cr	Co	Ni	Cu	Zn	Ga	Rb	Sr	Y
21L03-1	1.96	1.59	8.26	16.77	1.20	6.60	1.38	23.74	17.17	226.70	53.50	13.04
21L03-5	5.11	1.76	2.21	10.10	0.43	2.51	3.09	153.50	17.53	246.60	73.45	7.87
21L03-6	1.90	1.79	1.97	9.26	0.29	3.55	7.44	52.50	13.85	194.15	62.75	9.20
样品号	微量元素含量/10^-6
样品号	Zr	Nb	Cs	Ba	Hf	Ta	Pb	Th	U	Ge	Li	Sn
21L03-1	135.60	16.80	1.08	306.35	5.37	3.14	24.05	18.88	3.84	2.38	8.71	2.01
21L03-5	92.00	13.59	2.32	427.90	3.91	2.89	34.00	21.92	4.63	2.17	9.38	7.25
21L03-6	72.35	11.98	1.63	328.95	3.30	2.58	29.74	23.35	5.27	1.89	5.80	3.13
样品号	微量元素含量/10^-6
样品号	Tl	Ti	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho
21L03-1	1.14	865.28	6.36	38.17	1.72	5.95	1.44	0.18	1.70	0.33	2.27	0.52
21L03-5	1.35	607.62	17.39	43.97	3.61	11.67	2.07	0.27	1.73	0.25	1.49	0.31
21L03-6	1.00	582.22	22.39	45.30	4.79	15.74	2.92	0.48	2.74	0.35	1.86	0.37
样品号	微量元素含量/10^-6							(La/Yb)_N	Eu/Eu^*	Rb/Sr	Sr/Y	Nb/Ta
样品号	Er	Tm	Yb	Lu	∑REE	∑LREE	∑HREE	(La/Yb)_N	Eu/Eu^*	Rb/Sr	Sr/Y	Nb/Ta
21L03-1	1.67	0.29	2.07	0.32	62.97	53.81	9.16	2.07	0.36	4.24	4.10	5.36
21L03-5	0.94	0.15	1.02	0.15	85.00	78.97	6.03	11.54	0.42	3.36	9.34	4.70
21L03-6	1.07	0.17	1.08	0.17	99.43	91.61	7.82	14.02	0.51	3.09	6.82	4.64

样品号	主量元素含量/%
样品号	SiO₂	TiO₂	Al₂O₃	^TFe₂O₃	MnO	MgO	CaO	Na₂O	K₂O	P₂O₅	LOI	Total
21L03-1	75.70	0.14	13.00	1.51	0.05	0.15	0.11	3.25	4.96	0.04	0.81	99.72
21L03-5	76.03	0.10	13.51	1.24	0.02	0.09	0.09	3.06	4.82	0.02	0.87	99.86
21L03-6	76.07	0.10	13.17	1.08	0.02	0.08	0.11	3.12	5.19	0.01	0.61	99.56
样品号	微量元素含量/10^-6
样品号	Be	Sc	V	Cr	Co	Ni	Cu	Zn	Ga	Rb	Sr	Y
21L03-1	1.96	1.59	8.26	16.77	1.20	6.60	1.38	23.74	17.17	226.70	53.50	13.04
21L03-5	5.11	1.76	2.21	10.10	0.43	2.51	3.09	153.50	17.53	246.60	73.45	7.87
21L03-6	1.90	1.79	1.97	9.26	0.29	3.55	7.44	52.50	13.85	194.15	62.75	9.20
样品号	微量元素含量/10^-6
样品号	Zr	Nb	Cs	Ba	Hf	Ta	Pb	Th	U	Ge	Li	Sn
21L03-1	135.60	16.80	1.08	306.35	5.37	3.14	24.05	18.88	3.84	2.38	8.71	2.01
21L03-5	92.00	13.59	2.32	427.90	3.91	2.89	34.00	21.92	4.63	2.17	9.38	7.25
21L03-6	72.35	11.98	1.63	328.95	3.30	2.58	29.74	23.35	5.27	1.89	5.80	3.13
样品号	微量元素含量/10^-6
样品号	Tl	Ti	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho
21L03-1	1.14	865.28	6.36	38.17	1.72	5.95	1.44	0.18	1.70	0.33	2.27	0.52
21L03-5	1.35	607.62	17.39	43.97	3.61	11.67	2.07	0.27	1.73	0.25	1.49	0.31
21L03-6	1.00	582.22	22.39	45.30	4.79	15.74	2.92	0.48	2.74	0.35	1.86	0.37
样品号	微量元素含量/10^-6							(La/Yb)_N	Eu/Eu^*	Rb/Sr	Sr/Y	Nb/Ta
样品号	Er	Tm	Yb	Lu	∑REE	∑LREE	∑HREE	(La/Yb)_N	Eu/Eu^*	Rb/Sr	Sr/Y	Nb/Ta
21L03-1	1.67	0.29	2.07	0.32	62.97	53.81	9.16	2.07	0.36	4.24	4.10	5.36
21L03-5	0.94	0.15	1.02	0.15	85.00	78.97	6.03	11.54	0.42	3.36	9.34	4.70
21L03-6	1.07	0.17	1.08	0.17	99.43	91.61	7.82	14.02	0.51	3.09	6.82	4.64

样品号		微量元素含量/10^-6
样品号		Rb	Sr		Y			Zr	Nb	Cs	Ba		Hf		Pb		Th		U		La		Ce		Pr
21L3-1-01		0.24	338.06		1 163.58			1.88	0.01	0.00	1.38		0.02		3.89		36.64		9.33		1 502.72		4 052.83		468.91
21L3-1-02		0.54	325.22		793.61			1.10	0.00	0.05	4.65		0.00		3.36		11.87		2.70		817.38		2 255.64		282.54
21L3-1-03		0.00	341.69		826.02			2.29	0.02	0.03	1.53		0.01		3.49		23.24		5.73		1 265.17		3 269.44		366.28
21L3-1-04		0.21	245.16		888.35			3.22	0.00	0.00	1.74		0.05		3.19		13.39		3.74		850.36		2 402.37		292.85
21L3-1-05		0.00	372.97		796.39			2.07	0.01	0.07	1.86		0.01		3.56		22.76		5.05		1 151.19		2 996.50		342.71
21L3-1-06		0.15	210.01		927.36			4.08	0.01	0.03	0.64		0.04		3.12		15.78		4.17		867.63		2 475.38		302.00
21L3-1-07		0.44	238.52		1 277.60			2.30	0.02	0.13	0.35		0.02		3.96		34.72		8.08		1 067.82		3 179.90		394.85
21L3-1-08		0.00	391.93		526.11			0.03	0.00	0.00	1.92		0.00		3.27		5.62		2.55		658.90		1 597.25		201.88
21L3-1-09		1.72	408.13		900.73			0.89	0.05	0.00	2.32		0.02		2.80		14.88		3.87		441.52		1 303.10		190.51
21L3-1-10		0.00	278.68		655.17			0.87	0.01	0.05	1.40		0.02		3.56		13.56		4.07		1 075.99		2 864.07		324.45
样品号	微量元素含量/10^-6																							Eu/Eu^*		Nd/Nd^*
样品号	Nd			Sm		Eu	Gd		Tb	Dy		Ho		Er		Tm		Yb		Lu		∑REE		Eu/Eu^*		Nd/Nd^*
21L3-1-01	2 080.56			389.99		26.82	316.37		42.14	223.42		41.56		100.65		12.44		68.84		8.94		10 500.09		0.23		1.19
21L3-1-02	1 244.49			249.96		15.20	220.03		27.20	148.65		27.86		68.47		7.34		44.94		6.17		6 209.48		0.19		1.16
21L3-1-03	1 597.69			289.81		20.30	225.46		29.04	153.30		28.05		67.90		8.51		48.18		6.14		8 201.44		0.23		1.19
21L3-1-04	1 376.71			293.48		10.26	256.96		33.34	174.35		32.61		74.98		9.11		50.64		6.08		6 752.51		0.11		1.18
21L3-1-05	1 530.73			277.99		20.42	219.23		28.29	150.60		27.64		65.03		7.83		45.10		5.58		7 665.34		0.24		1.21
21L3-1-06	1 400.57			293.53		10.29	256.64		33.89	182.48		33.23		76.93		8.98		50.10		6.36		6 925.49		0.11		1.18
21L3-1-07	1 863.54			399.28		20.10	336.44		45.59	245.18		45.75		109.59		13.26		76.61		9.60		9 085.29		0.16		1.18
21L3-1-08	908.83			180.52		10.49	155.74		19.82	100.29		18.93		43.88		5.39		29.51		3.73		4 461.55		0.19		1.18
21L3-1-09	952.64			250.14		11.12	240.04		33.02	178.59		33.02		75.46		9.33		48.08		5.90		4 673.54		0.14		1.12
21L3-1-10	1 422.63			248.29		16.64	190.50		23.30	125.55		23.53		58.45		7.81		45.24		5.66		7 087.38		0.23		1.21
