The components of the subducted continental basement within the Dabieshan orogenic belt as evidenced by xenocrystic/inherited zircons from Cretaceous dykes

doi:10.13745/j.esf.sf.2023.5.1

Abstract

Abstract:

Ancient continental basement of young orogenic belts may reveal the early evolutionary history of continental blocks. Continental basement of subduction plate in a collision orogen is generally located in the Earth’s lower crust and unlikely to be widely exposed on the Earth’s surface, however, xenocrystic/inherited zircons from shallow igneous rocks can be used to trace the content and evolution of continental crust at depth. Here we present in situ U-Pb and Hf isotope data for the newly discovered xenocrystic/inherited zircons from Late-Mesozoic dykes (140-127 Ma) in the southern Dabieshan orogen to address the critical issue about the nature, age and evolution of geologic basement of the Dabieshan orogenic belt. The xenocrystic/inherited zircons are dated to the Precambrian and show an episodic age distribution. They record a large number of multi-stage magmatic events (at 3.44-3.23 Ga, 2.99-2.82 Ga, 2.79-2.60 Ga, 2.47 Ga, 2.00 Ga, 1.82 Ga, 0.89 Ga, 0.82-0.78 Ga and 0.71-0.59 Ga) as well as six metamorphic events (at 3.28 Ga, 2.87 Ga, 2.73 Ga, 2.51 Ga, 1.98 Ga and 0.80 Ga). The Hf isotopic composition of the xenocrystic/inherited zircons shows that the southern Dabieshan orogen experienced significant continental growth in the Archean, mainly concentrated in the Paleoarchean (3.6-3.3 Ga) and Neoarchean (2.7-2.6 Ga), and underwent multi-stage reconstruction (3.4-3.2 Ga, 3.0~2.8 Ga, 2.7-2.5 Ga, 2.0-1.8 Ga, 0.9-0.6 Ga and 0.1 Ga). According to comprehensive analysis, the southern Dabie orogen should represent basement of subduction plate that was not involved in deep subduction and at least modified by multi-stage tectono-thermal events in the Paleoproterozoic and Neoproterozoic relating to the formation of the Columbia and breakup of the Rodinia supercontinents, respectively.

Key words: Dabieshan orogenic belt, Archean, Proterozoic, Precambrian, xenocrystic/inherited zircon, crustal growth and reconstruction

CLC Number:

P542
P534

XU Daliang, DENG Xin, PENG Lianhong, TIAN Yang, JIN Wei, JIN Xinbiao. The components of the subducted continental basement within the Dabieshan orogenic belt as evidenced by xenocrystic/inherited zircons from Cretaceous dykes[J]. Earth Science Frontiers, 2023, 30(4): 299-316.

Figures/Tables 7

References 78

[1]	GRIFFIN W L, BELOUSOVA E A, SHEE S R, et al. Archean crustal evolution in the northern Yilgarn Craton: U-Pb and Hf-isotope evidence from detrital zircons[J]. Precambrian Research, 2004, 131(3): 231-282. DOI URL
[2]	BELOUSOVA E A, KOSTITSYN Y A, GRIFFIN W L, et al. The growth of the continental crust: constraints from zircon Hf-isotope data[J]. Lithos, 2010, 119(3): 457-466. DOI URL
[3]	ZHENG J P, GRIFFIN W L, O’REILLY S Y, et al. Widespread Archean basement beneath the Yangtze Craton[J]. Geology, 2006, 34(6): 417-420. DOI URL
[4]	李俊辉, 于洋, 韦龙猛, 等. 大别山造山带宿松岩群锆石U-Pb年龄和Nd同位素特征: 宿松地体物源和属性[J]. 地球科学与环境学报, 2016, 38(1): 21-33.
[5]	刘超然, 徐大良, 赵小明, 等. 南大别蕲春构造混杂岩带中变质沉积岩源区和时代限定[J]. 华南地质, 2021, 37(1): 1-28.
[6]	WANG K, DONG S W, YAO W H, et al. Xenocrystic/inherited Precambrian zircons entrained within igneous rocks from eastern South China: tracking unexposed ancient crust and implications for late Paleoproterozoic orogenesis[J]. Gondwana Research, 2020, 84: 194-210. DOI URL
[7]	WANG K, DONG S W, YAO W H, et al. Nature and evolution of Pre-Neoproterozoic continental crust in South China: a review and tectonic implications[J]. Acta Gelogica Sinica(English Edition), 2020, 94(6): 1731-1756.
[8]	游振东, 索书田, 韩郁菁, 等. 年轻褶皱带内前寒武纪基底的地质特征[C]// 中国地质科学院地质研究所文集(25). 北京: 地质出版社, 1993: 36-45.
[9]	徐树桐, 刘贻灿, 江来利, 等. 大别山造山带的构造几何学和运动学[M]. 合肥: 中国科学技术大学出版社, 2002: 53-68.
[10]	《大别山超高压变质作用与碰撞造山动力学》编写组. 大别山超高压变质作用与碰撞造山动力学[M]. 北京: 科学出版社, 2005: 1-209.
[11]	ZHENG Y F, ZHOU J B, WU Y B, et al. Low-grade metamorphic rocks in the Dabie-Sulu orogenic belt: a passive-margin accretionary wedge deformed during continent subduction[J]. International Geology Review, 2005, 47(8): 851-871. DOI URL
[12]	OKAY A L, SENGöR A M C. Tectonics of an ultrahigh-pressure metamorphic terrane: the Dabie Shan/Tongbai Shan orogen, China[J]. Tectonics, 1993, 12(6): 1320-1334. DOI URL
[13]	HACKER B R, RATSCHBACHER L, WEBB L, et al. U/Pb zircon ages constrain the architecture of the ultrahigh-pressure Qinling-Dabie Orogen, China[J]. Earth and Planetary Science Letters, 1998, 161(1/2/3/4): 215-230. DOI URL
[14]	LIU Y C, LI S G, XU S T. Zircon SHRIMP U-Pb dating for gneiss in northern Dabie high T/p metamorphic zone, central China: implication for decoupling within subducted continental crust[J]. Lithos, 2007, 96: 170-185. DOI URL
[15]	李远, 刘贻灿, 杨阳, 等. 大别山宿松变质带花岗片麻岩的锆石U-Pb年龄和Hf同位素成分[J]. 地球科学与环境学报, 2018, 40(1): 61-75.
[16]	江来利, 吴维平, 刘贻灿, 等. 大别山南部宿松杂岩的U-Pb锆石和Ar-Ar角闪石年龄及其地质意义[J]. 岩石学报, 2003, 19(3): 497-505.
[17]	XUE H M, DONG S W, JIAN P. Zircon U-Pb SHRIMP ages of weakly to unmetamorphosed granitoids of the Yangtze basement outcrop in Dabieshan, central China[J]. Journal of Asian Earth Sciences, 2006, 27: 779-787. DOI URL
[18]	孙洋, 马昌前, 张超. 大别山鲁家寨花岗岩地球化学、锆石年代学和Hf同位素特征: 扬子克拉通北东缘新元古代岩浆活动证据[J]. 地学前缘, 2011, 18(2): 85-99.
[19]	吴元保, 陈道公, 夏群科, 等. 北大别黄土岭麻粒岩锆石U-Pb离子探针定年[J]. 岩石学报, 2002, 18(3): 378-382.
[20]	WU Y B, ZHENG Y F, GAO S, et al. Zircon U-Pb age and trace element evidence for Paleoproterozoic granulite-facies metamorphism and Archean crustal rocks in the Dabie Orogen[J]. Lithos, 2008, 101: 308-322. DOI URL
[21]	陈道公, DELOULE E, 夏群科, 等. 大别山双河超高压榴辉岩中变质锆石: 离子探针和微区结构研究[J]. 岩石学报, 2002, 18(3): 369-377.
[22]	石永红, 王次松, 康涛, 等. 安徽省宿松变质杂岩岩石学特征和锆石U-Pb年龄研究[J]. 岩石学报, 2012, 28(10): 3389-3402.
[23]	徐大良, 彭练红, 邓新, 等. 大别山南缘翁门杂岩中太古代-古元古代岩浆构造热事件的识别及其地质意义[J]. 地球科学, 2023(待刊).
[24]	王涛, 侯增谦. 同位素填图与深部物质探测(I): 揭示岩石圈组成演变与地壳生长[J]. 地学前缘, 2018, 25(6): 1-19. DOI
[25]	鲁麟, 梁婷, 任文琴, 等. 江西崇义淘西坑钨矿区煌斑岩LA-ICP-MS锆石U-Pb同位素定年及地质意义[J]. 地学前缘, 2017, 24(5): 93-108. DOI
[26]	JIANG C H, WANG X L, WANG S, et al. Paleoproterozoic basement beneath the Eastern Cathaysia Block revealed by zircon xenocrysts from late Mesozoic volcanics[J]. Precambrian Research, 2020, 350: 105922. DOI URL
[27]	WANG X, GUO J W, TAO W, et al. Paleoproterozoic tectonic evolution of the Yangtze Craton: evidence from magmatism and sedimentation in the Susong area, South China[J]. Precambrian Research, 2021, 347: 105834. DOI URL
[28]	ZHAO T, ZHU G, WU Q, et al. Evidence for discrete Archean microcontinents in the Yangtze Craton[J]. Precambrian Research, 2021, 361: 106259. DOI URL
[29]	湖北省地质矿产局. 湖北省区域地质志[M]. 北京: 地质出版社, 1990: 1-705.
[30]	LI S G, HE Y S, WANG S J. Process and mechanism of mountain-root removal of the Dabie Orogen: constraints from geochronology and geochemistry of post-collisional igneous rocks[J]. Chinese Science Bulletin, 2013, 58: 2-3.
[31]	赵子福, 郑永飞, 戴立群. 大陆碰撞造山带花岗岩中继承锆石成因与岩浆源区性质[J]. 科学通报, 2013, 58(23): 2285-2289.
[32]	LIU Y S, HU Z C, GAO S, et al. In situanalysis of Major and Trace elements of anhydrous minerals by LA-ICP-MS without applying an internal Standard[J]. Chemical Geology, 2007, 257(1/2): 34-43. DOI URL
[33]	ZHAO Z F, LIU Z B, CHEN Q. Melting of subducted continental crust: geochemical evidence from Mesozoic granitoids in the Dabie-Sulu orogenic belt, east-central China[J]. Journal of Asian Earth Sciences, 2017, 145: 260-277. DOI URL
[34]	XU D L, PENG L H, DENG X, et al. Zircon U-Pb age evidence for the Mesoarchean (2.9-3.2 Ga) crustal remnant in the Southern Dabie Orogen, South China[J]. China Geology, 2023, 6(1): 174-176.
[35]	赵子福, 郑永飞, 魏春生, 等. 大别山中生代中酸性岩浆岩锆石U-Pb定年、元素和氧同位素地球化学研究[J]. 岩石学报, 2004, 20(5): 1151-1174.
[36]	WANG K, ZHAO T Y, ZHANG S H. Discovery of the oldest (ca. 2.87 Ga) granitic gneisses in the Qinling-Dabie Orogenic Belt: direct evidence for Mesoarchean crust[J]. China Geology, 2023, doi: 10.31035/cg2022084. DOI
[37]	JIAO W F, WU Y B, YANG S H, et al. The oldest basement rock in the Yangtze Craton revealed by zircon U-Pb age and Hf isotope composition[J]. Science in China Series D: Earth Sciences, 2009, 52: 1-2.
[38]	GAO S, YANG J, ZHOU L, et al. Age and growth of the Archean Kongling terrain, South China, with emphasis on 3.3 Ga granitoid gneisses[J]. American Journal of Science, 2011, 311(2): 153-182. DOI URL
[39]	CHEN K, GAO S, WU Y B, et al. 2.6-2.7 Ga crustal growth in Yangtze craton, South China[J]. Precambrian Research, 2013, 224: 472-490. DOI URL
[40]	GUO J L, GAO S, WU Y B, et al. 3.45 Ga granitic gneisses from the Yangtze Craton, South China: implications for Early Archean crustal growth[J]. Precambrian Research, 2014, 242: 82-95. DOI URL
[41]	GUO J L, WU Y B, GAO S, et al. Episodic Paleoarchean-Paleoproterozoic (3.3-2.0 Ga) granitoid magmatism in Yangtze craton, South China: implications for late Archean tectonics[J]. Precambrian Research, 2015, 270: 246-266. DOI URL
[42]	LI L M, LIN S F, DONALD W D, et al. Geochronology and geochemistry of igneous rocks from the Kongling terrane: implications for Mesoarchean to Paleoproterozoic crustal evolution of the Yangtze Block[J]. Precambrian Research, 2014, 255: 30-47. DOI URL
[43]	邱啸飞, 陈伟雄, 徐大良, 等. 扬子陆核崆岭杂岩太古宙地壳演化[J]. 华南地质, 2022, 38(1): 56-66.
[44]	涂城, 张少兵, 苏克, 等. 肥东杂岩锆石U-Pb年龄和Lu-Hf同位素:对扬子克拉通统一结晶基底的限制[J]. 地球科学, 2021, 46(5): 1630-1643.
[45]	QIU X F, TONG X R, JIANG T, et al. Reworking of Hadean continental crust in the Dabie orogen: evidence from the Muzidian granitic gneisses[J]. Gondwana Research, 2021, 89: 119-130. DOI URL
[46]	ZHANG L, LIU H J, ZHANG S B, et al. Tectonic switch of the north Yangtze Craton at ca. 2.0 Ga: implications for its position in Columbia supercontinent[J]. Precambrian Research, 2022, 381: 106842. DOI URL
[47]	YUAN X Y, NIU M L, CAI Q R, et al. The nature of Paleoproterozoic basement in the northern Yangtze and its geological implication[J]. Precambrian Research, 2022, 378: 106761. DOI URL
[48]	QIU Y M, GAO S, MCNAUGHTON N J, et al. First evidence of >3.2 Ga continental crust in the Yangtze craton of south China and its implications for Archean crustal evolution and Phanerozoic tectonics[J]. Tectonics, 2000, 28: 11-14.
[49]	WEI Y X, ZHOU W X, HU Z X, et al. Geochronology and geochemistry of Archean TTG and tremolite schist xenoliths in Yemadong complex: evidence for ≥3.0 Ga Archean continental crust in Kongling high-grade metamorphic terrane, Yangtze Craton, China[J]. Minerals, 2019, 9: 1-22. DOI URL
[50]	JIANG X F, PENG S B, WANG Q. Precambrian tectonic evolution of southern Kongling terrane, Yangtze Craton: constraint from the detrital zircon U-Pb geochronology of the metasedimentary rocks[J]. Earth and Space Science, 2022, 9: 1-15.
[51]	CHEN Q, SUN M, ZHAO G C, et al. Episodic crustal growth and reworking of the Yudongzi terrane, South China: constraints from the Archean TTGs and potassic granites and Paleoproterozoic amphibolites[J]. Lithos, 2019, 326: 1-18.
[52]	聂峰, 石永红, 张忠宝, 等. 安徽北部郯庐断裂两侧基底岩石年龄及对郯庐断裂初始开启时间的限定[J]. 科学通报, 2015, 60(24): 2315-2326.
[53]	YIN C Q, LIN S F, DONALD W D, et al. 2.1-1.85 Ga tectonic events in the Yangtze Block, South China: petrological and geochronological evidence from the Kongling Complex and implications for the reconstruction of supercontinent Columbia[J]. Lithos, 2013, 182-183: 200-210.
[54]	WANG Z J, WANG J, DENG Q, et al. Paleoproterozoic I-type granites and their implications for the Yangtze block position in the Columbia supercontinent: evidence from the Lengshui Complex, South China[J]. Precambrian Research, 2015, 263: 157-173. DOI URL
[55]	WANG K, DONG S W. New insights into Paleoproterozoic tectonics of the Yangtze Block in the context of early Nuna assembly: possible collisional granitic magmatism in the Zhongxiang Complex, South China[J]. Precambrian Research, 2019, 334: 105452. DOI URL
[56]	尹须伟, 徐扬, 杨坤光, 等. 红安造山带南缘古元古代杂岩体的发现对扬子板块古元古代造山事件的约束[J]. 岩石学报, 2021, 37(7): 2123-2161.
[57]	ZHANG L J, MA C Q, WANG L X, et al. Discovery of Paleoproterozoic rapakivi granite on the northern margin of the Yangtze Block and its geological significance[J]. China Science Bulletin, 2011, 56: 306-318. DOI URL
[58]	PENG M, WU Y B, GAO S, et al. Geochemistry, zircon U-Pb age and Hf isotope compositions of Paleoproterozoic aluminous A-type granites from the Kongling terrain, Yangtze Block: constraints on petrogenesis and geologic implications[J]. Gondwana Research, 2012, 22: 140-151. DOI URL
[59]	CHEN Z H, XING G F. Geochemical and zircon U-Pb-Hf-O isotopic evidence for a coherent Paleoproterozoic basement beneath the Yangtze Block, South China[J]. Precambrian Research, 2016, 279: 81-90. DOI URL
[60]	DONG Y P, SUN S S, SANTOSH M, et al. Central China Orogenic Belt and amalgamation of East Asian continents[J]. Gondwana Research, 2021, 100: 131-194. DOI URL
[61]	张继彪, 丁孝忠, 刘燕学. 扬子西缘洋岛型与岛弧型火山岩岩石成因与构造意义: 从板内裂谷到洋-陆俯冲[J]. 地学前缘, 2021, 28(4): 250-266. DOI
[62]	ZHAO J H, ASIMOW P D. Formation and evolution of a magmatic system in a rifting continental margin: Neoproterozoic arc- and MORB-like dike swarms in South China[J]. Journal of Petrology, 2018, 9: 1-34. DOI URL
[63]	刘磊鑫, 李江海, 马昌明. 扬子板块、澳大利亚板块、印度板块在新元古代晚期(750-540 Ma)古板块再造: 来自古地磁制约[J]. 地学前缘, 2023, 30(2): 154-162. DOI
[64]	SHI Y R, LIU D Y, ZHANG Z Q, et al. SHRIMP zircon U-Pb dating of gabbro and granite from the Huashan ophiolite, Qinling orogenic belt, China: Neoproterozoic suture on the northern margin of the Yangtze Craton[J]. Acta Geologica Sinica, 2007, 81: 239-243. DOI URL
[65]	WU P, ZHANG S B, ZHENG Y F, et al. Amalgamation of South China into Rodinia during the Grenvillian accretionary orogeny: geochemical evidence from Early Neoproterozoic igneous rocks in the northern margin of the South China Block[J]. Precambrian Research, 2019, 321: 221-243. DOI URL
[66]	ZHANG S B, ZHENG Y F, ZHAO Z F, et al. The extremely enriched mantle beneath the Yangtze Craton in the Neoproterozoic: constraints from the Qichun pyroxenite[J]. Precambrian Research, 2016, 276: 194-210. DOI URL
[67]	HU J, LIU X C, QU W, et al. Mid-Neoproterozoic amphibolite facies metamorphism at the northern margin of the Yangtze craton[J]. Precambrian Research, 2019, 326, 333-343. DOI URL
[68]	WANG M X, WANG C Y, SUN Y L. Mantle source, magma differentiation and sulfide saturation of the -637Ma Zhouan mafic-ultramafic intrusion in the northern margin of the Yangtze Block, Central China[J]. Precambrian Research, 2013, 228: 206-222. DOI URL
[69]	WANG R R, XU Z Q, SANTOSH M, et al. Late Neoproterozoic magmatism in South Qinling, Central China: geochemistry, zircon U-Pb-Lu-Hf isotopes and tectonic implications[J]. Tectonophysics, 2016, 683: 43-61. DOI URL
[70]	第五春荣, 孙勇, 王倩. 华北克拉通地壳生长和演化: 来自现代河流碎屑锆石Hf同位素组成的启示[J]. 岩石学报, 2012, 28(11): 3520-3530.
[71]	LI S G, HUANG F, ZHOU H Y, et al. U-Pb isotopic compositions of the ultrahigh pressure metamorphic (UHPM) rocks from Shuanghe and gneisses from Northern Dabie zone in the Dabie Mountains, central China: constraint on the exhumation mechanismof UHPM rocks[J]. Sicence China (Series D), 2003, 46: 200-209.
[72]	LIU Y C, LI S G. Detachment within subducted continental crust and multi-slice successive exhumation of ultrahigh-pressure metamorphic rocks: evidence from the Dabie-Sulu orogenic belt[J]. Chinese Science Bulletin, 2008, 53: 3105-3119.
[73]	ZHAO Z F, ZHENG Y F, WEI C S, et al. Origin of postcollisional magmatic rocks in the Dabie orogen: implications for crust-mantle interaction and crustal architecture[J]. Lithos, 2011, 126: 99-114. DOI URL
[74]	李三忠, 张国伟, 董树文, 等. 大别山髙压-超高压岩石折返与扬子北缘构造变形的关系[J]. 岩石学报, 2010, 26(12): 3549-3562.
[75]	YUAN X C, KLEMPERER S L, TENG W B, et al. Crustal structure and exhumation of the Dabie Shan ultrahigh-pressure orogen, eastern China, from seismic reflection profiling[J]. Geology, 2003, 31: 435-438. DOI URL
[76]	DONG S W, GAO R, CONG B L, et al. Crustal structure of the southern Dabie ultrahigh-pressure orogen and Yangtze foreland from deep seismic reflection profiling[J]. Terra Nova, 2004, 6: 319-324.
[77]	侯爵, 徐涛, 吕庆田, 等. 华南东北部中生代铜金钨大规模成矿的深部背景: 来自英山-常山宽角地震资料的约束[J]. 中国科学: 地球科学, 2022, 52(11): 2305-2322.
[78]	FAURE M, LIN W, SCHARER U, et al. Insight into continental subduction and exhumation of UHP rocks from structural and radiometric data of the Dabieshan (E. China)[J]. Lithos, 2003, 70: 213-241. DOI URL

样品号	点位	名称	分析点数	捕获/继承锆石数量	捕获/继承锆石峰值年龄/Ma	年龄解释
D904-2	30°17'13.7″ 115°30'20.9″	正长岩脉	130	74	812、1 985、2 470、688、2 932~2 602	岩浆锆石
D904-2	30°17'13.7″ 115°30'20.9″	正长岩脉	130	74	2 433	变质锆石
D964	30°13'50.7″ 115°32'57.6″	正长岩脉	70	47	799、1 985、2 380、2 652	岩浆锆石
D964	30°13'50.7″ 115°32'57.6″	正长岩脉	70	47	2 566、2 054、1 976	变质锆石
D912	30°13'59.1″ 115°32'38.3″	正长岩脉	110	82	2 003、803、2 479、2 873~2 591	岩浆锆石
D912	30°13'59.1″ 115°32'38.3″	正长岩脉	110	82	2 733、2 024、2 013、1 902、804、470	变质锆石
D910-2	30°13'13.1″ 115°33'15.6″	闪长岩脉	55	14	2 004、2 455、791~724	岩浆锆石
D961-7	30°19'11.4″ 115°55'21.8″	闪长岩脉	70	47	1 985、2 735、2 902、2 612	岩浆锆石
D961-7	30°19'11.4″ 115°55'21.8″	闪长岩脉	70	47	2 736、2 298、1 973	变质锆石
D966-6	30°16'54.1″ 115°29'55.8″	变基性岩脉	90	61	1 822、3 376、2 958~2 198	岩浆锆石
D966-6	30°16'54.1″ 115°29'55.8″	变基性岩脉	90	61	3 285	变质锆石
D7466n	30°16'55.9″ 115°30'36.2″	变基性岩脉	90	85	2 929、1 994、2 776~2 443、821	岩浆锆石
D7466n	30°16'55.9″ 115°30'36.2″	变基性岩脉	90	85	2 915~2 861、2 510、2 155、2 072、2 040、 1 984~1 980	变质锆石
D9523-1	30°11'17.7″ 115°17'43.4″	变基性岩脉	105	67	2 460、813、2 007、3 287~2 822	岩浆锆石
D9523-1	30°11'17.7″ 115°17'43.4″	变基性岩脉	105	67	2 502	变质锆石

样品号	点位	名称	分析点数	捕获/继承锆石数量	捕获/继承锆石峰值年龄/Ma	年龄解释
D904-2	30°17'13.7″ 115°30'20.9″	正长岩脉	130	74	812、1 985、2 470、688、2 932~2 602	岩浆锆石
D904-2	30°17'13.7″ 115°30'20.9″	正长岩脉	130	74	2 433	变质锆石
D964	30°13'50.7″ 115°32'57.6″	正长岩脉	70	47	799、1 985、2 380、2 652	岩浆锆石
D964	30°13'50.7″ 115°32'57.6″	正长岩脉	70	47	2 566、2 054、1 976	变质锆石
D912	30°13'59.1″ 115°32'38.3″	正长岩脉	110	82	2 003、803、2 479、2 873~2 591	岩浆锆石
D912	30°13'59.1″ 115°32'38.3″	正长岩脉	110	82	2 733、2 024、2 013、1 902、804、470	变质锆石
D910-2	30°13'13.1″ 115°33'15.6″	闪长岩脉	55	14	2 004、2 455、791~724	岩浆锆石
D961-7	30°19'11.4″ 115°55'21.8″	闪长岩脉	70	47	1 985、2 735、2 902、2 612	岩浆锆石
D961-7	30°19'11.4″ 115°55'21.8″	闪长岩脉	70	47	2 736、2 298、1 973	变质锆石
D966-6	30°16'54.1″ 115°29'55.8″	变基性岩脉	90	61	1 822、3 376、2 958~2 198	岩浆锆石
D966-6	30°16'54.1″ 115°29'55.8″	变基性岩脉	90	61	3 285	变质锆石
D7466n	30°16'55.9″ 115°30'36.2″	变基性岩脉	90	85	2 929、1 994、2 776~2 443、821	岩浆锆石
D7466n	30°16'55.9″ 115°30'36.2″	变基性岩脉	90	85	2 915~2 861、2 510、2 155、2 072、2 040、 1 984~1 980	变质锆石
D9523-1	30°11'17.7″ 115°17'43.4″	变基性岩脉	105	67	2 460、813、2 007、3 287~2 822	岩浆锆石
D9523-1	30°11'17.7″ 115°17'43.4″	变基性岩脉	105	67	2 502	变质锆石
