Mineralogical characteristics and release mechanism of arsenic-thallium from As-bearing tailings

doi:10.13745/j.esf.sf.2023.9.8

Abstract

Abstract:

Arsenic (As) and associated thallium (Tl) can be released from As-bearing tailings and enter the surface water and soil environment. It is of great importance to understand the mineralogy and release characteristics of the toxic elements in tailings. In this study, the ore phases and their release mechanisms of As and Tl in As-bearing tailings from a realgar mining area are studied using batch leaching tests combined chemical analysis and mineral phases analysis. The results showed that the release of As and Tl was affected by the phases and speciation of the elements. The main As phases in the tailings were sperrylite and angelellite and they were prone to As release due to weathering. Thallium, as accompanying element, was associated with phases composed of Ca, Mn, Mg minerals, and the release of Tl was controlled by the precipitation and dissolution of these minerals. In the tailings, As mainly bounded to Fe-Mn oxides and organic materials, whilst Tl mainly bounded to Fe-Mn oxides and residual materials. The exchangeable fraction of As increased from 0.29% (before leaching) to 1.67% (after acid leaching); while for Tl it increased from 5.46% to 8.67%. The release of As was enhanced while Tl was inhibited under acidic conditions, which suggested the release of As and Tl in tailings was competitive. The leaching behavior of As conformed to the two-constant equation, indicating the leaching of As was a physiochemical process controlled by many factors. The leaching of Tl, which conformed to a parabolic diffusion equation, was mainly controlled by diffusion mechanisms such as structural incorporation and surface adsorption. In this study, the release characteristics, speciation and mineralogy of As and Tl in As-bearing tailings were clarified, which provided an essential reference of the pollution risk control for As and Tl in As-bearing tailings.

Key words: As-bearing tailings, arsenic, thallium, mineral phase, release mechanism

CLC Number:

LIANG Huizhi, GUO Zhaohui, ZHANG Yunxia, XU Rui. Mineralogical characteristics and release mechanism of arsenic-thallium from As-bearing tailings[J]. Earth Science Frontiers, 2024, 31(2): 20-30.

Figures/Tables 10

References 55

[1]	QIU J P, ZHAO Y L, LONG H, et al. Low-carbon binder for cemented paste backfill: flowability, strength and leaching characteristics[J]. Minerals, 2019, 9(11): 707.
[2]	ROUSSEL C, BRIL H, FERNANDEZ A. Arsenic speciation: involvement in evaluation of environmental impact caused by mine wastes[J]. Journal of Environmental Quality, 2000, 29(1): 182-188.
[3]	ASSAWINCHAROENKIJ T, HAUZENBERGER C, SUTTHIRAT C. Mineralogy and geochemistry of tailings from a gold mine in northeastern Thailand[J]. Human and Ecological Risk Assessment: An International Journal, 2017, 23(2): 364-387.
[4]	WU Y, ZHOU X Y, LEI M, et al. Migration and transformation of arsenic: contamination control and remediation in realgar mining areas[J]. Applied Geochemistry, 2017, 77: 44-51.
[5]	马玉玲, 马杰, 陈雅丽, 等. 水铁矿及其胶体对砷的吸附与吸附形态[J]. 环境科学, 2018, 39(1):179-186.
[6]	LIU J, WANG J, TSANG D C W, et al. Emerging thallium pollution in China and source tracing by thallium isotopes[J]. Environmental Science and Technology, 2018, 52(21): 11977-11979.
[7]	LI D X, GAO Z M, ZHU Y X, et al. Photochemical reaction of Tl in aqueous solution and its environmental significance[J]. Geochemical Journal, 2005, 39(2): 113-119.
[8]	XIAO T F, GUHA J, BOYLE D, et al. Environmental concerns related to high thallium levels in soils and thallium uptake by plants in Southwest Guizhou, China[J]. Science of the Total Environment, 2004, 318(1/2/3): 223-244.
[9]	CHEN W, HUANGFU X, XIONG J, et al. Retention of thallium(I) on goethite, hematite, and manganite: quantitative insights and mechanistic study[J]. Water Research, 2022, 221: 118836.
[10]	WEN J C, WU Y G, LU Q, et al. Releasing characteristics and biological toxicity of the heavy metals from waste of mercury-thalliummine in Southwest Guizhou of China[J]. Bulletin of Environmental Contamination and Toxicology, 2021, 107(6): 1111-1120.
[11]	RAN H, GUO Z, YI L, et al. Pollution characteristics and source identification of soil metal(loid)s at an abandoned arsenic-containing mine, China[J]. Journal of Hazardous Materials, 2021, 413:125382.
[12]	SUN R G, GAO Y, YANG Y. Leaching of heavy metals from lead-zinc mine tailings and the subsequent migration and transformation characteristics in paddy soil[J]. Chemosphere, 2022, 291: 132792.
[13]	WANG P, SUN Z H, HU yuanan, et al. Leaching of heavy metals from abandoned mine tailings brought by precipitation and the associated environmental impact[J]. Science of the Total Environment, 2019, 695: 133893.
[14]	陈志良, 赵述华, 钟松雄, 等. 添加稳定剂对尾矿土中砷形态及转换机制的影响[J]. 环境科学, 2016, 37(6): 2345-2352.
[15]	AKHAVAN A, GOLCHIN A. Estimation of arsenic leaching from Zn-Pb Mine tailings under environmental conditions[J]. Journal of Cleaner Production, 2021, 295: 126477.
[16]	YANG F, XIE S W, WEI C Y, et al. Arsenic characteristics in the terrestrial environment in the vicinity of the Shimen realgar mine, China[J]. Science of the Total Environment, 2018, 626: 77-86.
[17]	WANG X, ZHANG H, WANG L L, et al. Transformation of arsenic during realgar tailings stabilization using ferrous sulfate in a pilot-scale treatment[J]. Science of the Total Environment, 2019, 668: 32-39.
[18]	LARIOS R, FERNÁNDEZ-MARTÍNEZ R, SILVA V, et al. Chemical availability of arsenic and heavy metals in sediments from abandoned cinnabar mine tailings[J]. Environmental Earth Sciences, 2013, 68(2): 535-546.
[19]	ZHAO Z Z, ZHANG H, WANG X, et al. The mechanism of microwave-induced mineral transformation and stabilization of arsenic in realgar tailings using ferrous sulfate[J]. Chemical Engineering Journal, 2020, 393: 124732.
[20]	NIEVA N E, BORGNINO L, LOCATI F, et al. Mineralogical control on arsenic release during sediment-water interaction in abandoned mine wastes from the Argentina Puna[J]. Science of the Total Environment, 2016, 550: 1141-1151.
[21]	贺文霄, 刘雪敏. 表生环境铊污染现状及国内外治理技术进展[J]. 复旦学报(自然科学版), 2023, 62(2):248-262.
[22]	邱国良, 陈泓霖. 衡阳市湘江流域地表水铊预警监测体系探讨[J]. 供水技术, 2023, 17(3): 20-22.
[23]	EIGHMY T T, EUSDEN J D, KRZANOWSKI J E, et al. Comprehensive approach toward understanding element speciation and leaching behavior in municipal solid waste incineration electrostatic precipitator ash[J]. Environmental Science and Technology, 1995, 29(3): 629-646.
[24]	SAIKIA N, BORAH R R, KONWAR K, et al. pH dependent leachings of some trace metals and metalloid species from lead smelter slag and their fate in natural geochemical environment[J]. Groundwater for Sustainable Development, 2018, 7: 348-358.
[25]	COSTIS S, COUDERT L, MUELLER K, et al. Behaviour of flotation tailings from a rare earth element deposit at high salinity[J]. Journal of Environmental Management, 2021, 300: 113773.
[26]	XU D M, FU R, TONG Y, et al. The potential environmental risk implications of heavy metals based on their geochemical and mineralogical characteristics in the size-segregated zinc smelting slags[J]. Journal of Cleaner Production, 2021, 315: 128199.
[27]	VOEGELIN A, PFENNINGER N, PETRIKIS J, et al. Thallium speciation and extractability in a thallium- and arsenic-rich soil developed from mineralized carbonate rock[J]. Environmental Science and Technology, 2015, 49(9): 5390-5398.
[28]	WEN Q Q, YANG X, YAN X L, et al. Evaluation of arsenic mineralogy and geochemistry in gold mine-impacted matrices: speciation, transformation, and potential associated risks[J]. Journal of Environmental Management, 2022, 308: 114619.
[29]	KIM J Y, DAVIS A P, KIM K W. Stabilization of available arsenic in highly contaminated mine tailings using iron[J]. Environmental Science and Technology, 2003, 37(1): 189-195.
[30]	DRAHOTA P, KULAKOWSKI O, CULKA A, et al. Arsenic mineralogy of near-neutral soils and mining waste at the Smolotely-Líšnice historical gold district, Czech Republic[J]. Applied Geochemistry, 2018, 89: 243-254.
[31]	李惠全, 胡麓华, 樊娟, 等. “十二五” 期间湖南省酸雨污染现状及成因分析研究[J]. 环境科学与管理, 2015, 40(11):57-60.
[32]	RIEUWERTS J S, MIGHANETARA K, BRAUNGARDT C B, et al. Geochemistry and mineralogy of arsenic in mine wastes and stream sediments in a historic metal mining area in the UK[J]. Science of the Total Environment, 2014, 472: 226-234.
[33]	TESSIER A, CAMPBELL P G C, BISSON M. Sequential extraction procedure for the speciation of particulate trace metals[J]. Analytical Chemistry, 1979, 51(7): 844-851.
[34]	MALMSTRÖM M E, GLEISNER M, HERBERT R B. Element discharge from pyritic mine tailings at limited oxygen availability in column experiments[J]. Applied Geochemistry, 2006, 21(1): 184-202.
[35]	吴攀, 刘丛强, 杨元根, 等. 矿山环境中(重)金属的释放迁移地球化学及其环境效应[J]. 矿物学报, 2001, 21(2):213-218.
[36]	BERGER A C, BETHKE C M, KRUMHANSL J L. A process model of natural attenuation in drainage from a historic mining district[J]. Applied Geochemistry, 2000, 15(5): 655-666.
[37]	DONAHUE R, HENDRY M J. Geochemistry of arsenic in uranium mine mill tailings, Saskatchewan, Canada[J]. Applied Geochemistry, 2003, 18(11): 1733-1750.
[38]	王云燕, 徐慧, 唐巾尧, 等. 硫化砷渣的环境稳定性与金属释放风险研究[J]. 中南大学学报(自然科学版), 2023, 54(2):548-561.
[39]	SAIKIA N, KATO S, KOJIMA T. Behavior of B, Cr, Se, As, Pb, Cd, and Mo present in waste leachates generated from combustion residues during the formation of ettringite[J]. Environmental Toxicology and Chemistry, 2006, 25(7): 1710-1719.
[40]	TURNER A, CABON A, GLEGG G A, et al. Sediment-water interactions of thallium under simulated estuarine conditions[J]. Geochimica et Cosmochimica Acta, 2010, 74(23): 6779-6787.
[41]	VAXEVANIDOU K, CHRISTOU C, KREMMYDAS G, et al. Role of indigenous arsenate and iron(III) respiring microorganisms in controlling the mobilization of arsenic in a contaminated soil sample[J]. Bulletin of Environmental Contamination and Toxicology, 2015, 94(3): 282-288.
[42]	KE W, ZENG J, ZHU F, et al. Geochemical partitioning and spatial distribution of heavy metals in soils contaminated by lead smelting[J]. Environmental Pollution, 2022, 307: 119486.
[43]	XIE Y Y, LU G N, YANG C F, et al. Mineralogical characteristics of sediments and heavy metal mobilization along a river watershed affected by acid mine drainage[J]. PLoS One, 2018, 13(1): e0190010.
[44]	DONG Y B, CHEN D N, LIN H. The behavior of heavy metal release from sulfide waste rock under microbial action and different environmental factors[J]. Environmental Science and Pollution Research, 2022, 29(50): 75293-75306.
[45]	ZHU W X, XIA J, YANG Y, et al. Sulfur oxidation activities of pure and mixed thermophiles and sulfur speciation in bioleaching of chalcopyrite[J]. Bioresource Technology, 2011, 102(4): 3877-3882.
[46]	MCKIBBEN M A. Oxidation of pyrite in low temperature acidic solutions: rate laws and surface textures[J]. Geochimica et Cosmochimica Acta, 1986, 50(7): 1509-1520.
[47]	RIMSTIDT J D, NEWCOMB W D. Measurement and analysis of rate data: the rate of reaction of ferric iron with pyrite[J]. Geochimica et Cosmochimica Acta, 1993, 57(9): 1919-1934.
[48]	NICHOLSON R V, GILLHAM R W, REARDON E J. Pyrite oxidation in carbonate-buffered solution: 1. Experimental kinetics[J]. Geochimica et Cosmochimica Acta, 1988, 52(5): 1077-1085.
[49]	JOHNSON R H, BLOWES D W, ROBERTSON W D, et al. The hydrogeochemistry of the nickel rim mine tailings impoundment, Sudbury, Ontario[J]. Journal of Contaminant Hydrology, 2000, 41(1/2): 49-80.
[50]	JOHNSON D B, HALLBERG K B. Acid mine drainage remediation options: a review[J]. Science of the Total Environment, 2005, 338(1/2): 3-14.
[51]	袁婧, 吴骥子, 连斌, 等. 氧化石墨烯负载铁锰复合材料对镉砷污染土壤的钝化修复[J]. 环境科学, 2024, 45(2): 1107-1117.
[52]	SMEDLEY P L, KINNIBURGH D G. A review of the source, behaviour and distribution of arsenic in natural waters[J]. Applied Geochemistry, 2002, 17(5): 517-568.
[53]	AGUILAR-CARRILL J, HERRERA L, GUTIERREZ E J, et al. Solid-phase distribution and mobility of thallium in mining-metallurgical residues: environmental hazard implications[J]. Environmental Pollution, 2018, 243: 1833-1845.
[54]	BUTLER B A. Effect of pH, ionic strength, dissolved organic carbon, time, and particle size on metals release from mine drainage impacted streambed sediments[J]. Water Research, 2009, 43(5): 1392-1402.
[55]	CHEN T, YAN Z A, XU D M, et al. Current situation and forecast of environmental risks of a typical lead-zinc sulfide tailings impoundment based on its geochemical characteristics[J]. Journal of Environmental Sciences, 2020, 93: 120-128.

元素	w_B/%	元素	w_B/%
As	0.16	Mn	0.018
Tl	0.000 566	Pb	0.005
Ca	22.3	Sr	0.012
Mg	11.2	Al	0.26
Fe	0.21	S	0.038

元素	w_B/%	元素	w_B/%
As	0.16	Mn	0.018
Tl	0.000 566	Pb	0.005
Ca	22.3	Sr	0.012
Mg	11.2	Al	0.26
Fe	0.21	S	0.038

矿物种类		化学式	w_B/%	矿物种类		化学式	w_B/%
Dolomite	白云石	CaMg(CO₃)₂	82.12	Angelellite	砷铁矿	Fe₄(AsO₄)₂O₃	0.41
Calcite	方解石	CaCO₃	4.87	Kaolinite	高岭石	Al₂Si₂O₅(OH)₄	0.18
Gedrite	铝直闪石	Mg₅A1₂(Si₆A1₂O₂₂)(OH)₂	0.23	Albite	钠长石	Na₂OAl₂O₃6SiO₂	0.17
Sperrylite	砷铂矿	PtAs₂	0.23	Ferritschermakite	铁镁钙闪石	Ca₂Fe₂MgA1₃Si₇O₂₂(OH)₂	0.8
Orthoclase	正长石	KAlSi₃O₈	1.25	Quartz	石英	SiO₂	2.88
Iron	铁	Fe	0.09

矿物种类		化学式	w_B/%	矿物种类		化学式	w_B/%
Dolomite	白云石	CaMg(CO₃)₂	82.12	Angelellite	砷铁矿	Fe₄(AsO₄)₂O₃	0.41
Calcite	方解石	CaCO₃	4.87	Kaolinite	高岭石	Al₂Si₂O₅(OH)₄	0.18
Gedrite	铝直闪石	Mg₅A1₂(Si₆A1₂O₂₂)(OH)₂	0.23	Albite	钠长石	Na₂OAl₂O₃6SiO₂	0.17
Sperrylite	砷铂矿	PtAs₂	0.23	Ferritschermakite	铁镁钙闪石	Ca₂Fe₂MgA1₃Si₇O₂₂(OH)₂	0.8
Orthoclase	正长石	KAlSi₃O₈	1.25	Quartz	石英	SiO₂	2.88
Iron	铁	Fe	0.09

元素	浸出环境	符合模型	参数
元素	浸出环境	符合模型	a	b	R²
As	pH=3.0	双常数方程	2.754 1	0.242 6	0.997 0
	pH=4.5	双常数方程	2.345 1	0.311 3	0.990 2
	pH=7.0	双常数方程	2.418 9	0.297 4	0.993 4
	pH=9.0	双常数方程	2.445 6	0.294 8	0.993 2
	Fe³⁺浓度:200×10^-6 mg·L^-1	Elovich方程	2.513 2	2.474 5	0.971 9
	Fe³⁺浓度:400×10^-6 mg·L^-1	抛物线扩散方程	0.704 3	0.143 7	0.869 3
	Fe³⁺浓度:600×10^-6 mg·L^-1	双常数方程	-2.603 5	0.389 5	0.917 4
	粒径>0.850 mm	抛物线扩散方程	9.165 5	3.006 2	0.968 7
	粒径0.250~0.850 mm	抛物线扩散方程	8.773 3	3.014 7	0.987 9
	粒径0.150~<0.250 mm	抛物线扩散方程	9.767 2	2.618 0	0.991 8
	粒径<0.150 mm	双常数方程	2.754 1	0.242 6	0.997 0
Tl	pH=3.0	抛物线扩散方程	2.762 1	-0.033 8	0.432 0
	pH=4.5	二级动力学方程	0.158 7	0.467 2	0.138 0
	pH=7.0	抛物线扩散方程	2.017 9	0.021 8	0.302 9
	pH=9.0	抛物线扩散方程	2.757 3	0.014 9	0.383 2
	Fe³⁺浓度:200×10^-6 mg·L^-1	Elovich方程	5.638 9	-0.475 4	0.794 6
	Fe³⁺浓度:400×10^-6 mg·L^-1	Elovich方程	8.459 9	-0.793 9	0.867 4
	Fe³⁺浓度:600×10^-6 mg·L^-1	Elovich方程	10.889 2	-1.072 1	0.859 0
	粒径>0.850 mm	抛物线扩散方程	1.864 7	-0.040 6	0.678 3
	粒径0.250~0.850 mm	抛物线扩散方程	2.262 3	-0.056 3	0.692 2
	粒径0.150~<0.250 mm	双常数方程	0.922 6	-0.078 9	0.537 4
	粒径<0.150 mm	抛物线扩散方程	2.762 0	-0.033 8	0.432 0
