Genesis of bird's-eye structure in the Triassic Dongmaanshan Formation in Chaohu, Anhui Province

doi:10.13745/j.esf.sf.2020.4.46

Abstract

Abstract:

Bird's-eye structure is a special structure in carbonate stratum indicative of the sedimentary environment of supratidal-intertidal zone. A layer of bird's-eye structure is widely developed in the bottom of the Triassic Dongmaanshan Formation in Chaohu, Anhui Province, but its mineralogy, geochemistry and genesis are still poorly understood. Here, we used optical microscope, X-ray diffraction (XRD), Raman spectroscopy and LA-ICP-MS to investigate the mineralogy and geochemical characteristics of bird's-eye structure in the Dongmaanshan Formation. The results showed that the major mineral in bird's-eye structure was calcite, enriched in Sr, REE, etc., with decreasing crystalline size from the core to edge; while the major matrix mineral was dolomite, containing enriched Fe, Cu, Ti, etc. The contents of quartz, clay minerals and organic matters in matrix were higher than in bird's-eye core. These results demonstrated that bird's-eye structure in the Dongmaanshan Formation developed as a result of calcite formation, from matrix re-precipitation in cavities formed by accumulation and decomposition of sedimentary organic matters after Ca separation in the diagenetic stage due to dolomitization.

Key words: Dongmaanshan Formation, bird's-eye structure, dolomitization, mineralogy, geochemistry, Chaohu, Anhui

CLC Number:

P534.51
P583

XU Liang, CHEN Tianhu, GAO Yang, CHEN Ping, XIE Qiaoqin, ZHOU Yuefei. Genesis of bird's-eye structure in the Triassic Dongmaanshan Formation in Chaohu, Anhui Province[J]. Earth Science Frontiers, 2020, 27(4): 294-301.

Figures/Tables 7

References 30

[1]	张萌本. 碳酸岩中的鸟眼构造[J]. 地球化学, 1980, 3(1):91-95.
[2]	薛耀松, 唐天福, 俞从流. 鸟眼构造的成因及其环境意义[J]. 沉积学报, 1984, 2(1):85-95.
[3]	叶德胜, 王恕一. 碳酸盐岩中的鸟眼构造及其环境意义[J]. 岩相古地理, 1989, 42(4):36-43.
[4]	唐天福, 薛耀松, 俞从流. 中国南方震旦纪藻碳酸盐岩的特征及环境意义[J]. 科学通报, 1980, 25(18):853-855.
[5]	王尚彦, 杨家騄, 孟德保, 等. 湘黔交界娄山关组层序地层学研究[J]. 地质论评, 2000, 46(3):295-300.
[6]	唐兰, 邱达光. 桂林上泥盆统融县组灰岩中的鸟眼构造[J]. 中国岩溶, 2000, 19(3):224-231.
[7]	吴亚生, 范嘉松, 金玉玕. 晚二叠世末的生物礁出露及意义[J]. 地质学报, 2003, 77(3):289-296.
[8]	HAM W E. Algal origin of the “birdseye” limestone in the Mclish Formation[J]. Proceedings of the Oklahoma Academy of Science, 2015, 33:200-203.
[9]	LLLNG L V. Deposition and diagenesis of some upper Paleozoic carbonate sediments in western Canada[C]// Proceedings of the fifth world petroleum congress. New York, 1959, 1:23-52.
[10]	SHINN E A. Practical significance of birdseye structures in carbonate rocks[J]. Journal of Sedimentary Research, 1968, 38:215-223.
[11]	DEELMAN J C. On mechanisms causing birdseye structures[J]. Neues Jahrbuch für Geologie und Paläontologie, 1972, 10:582-595.
[12]	SWART P K. The geochemistry of carbonate diagenesis: the past, present and future[J]. Sedimentology, 2015, 62(5):1233-1304.
[13]	GREGG J M, BISH D L, KACZMAREK S E, et al. Mineralogy, nucleation and growth of dolomite in the laboratory and sedimentary environment: a review[J]. Sedimentology, 2015, 62:1749-1769. DOI URL
[14]	BRAUCHLI M, MCKENZIE J A, STROHMENGER C J, et al. The importance of microbial mats for dolomite formation in the Dohat Faishakh sabkha, Qatar[J]. Carbonates and Evaporites, 2016, 31(3):339-345. DOI URL
[15]	PETRASH D A, BIALIK O M, BONTOGNALI T R R, et al. Microbially catalyzed dolomite formation: from near-surface to burial[J]. Earth-Science Reviews, 2017, 171:558-582.
[16]	WARREN J. Dolomite: occurrence evolution and economically important associations[J]. Earth-Science Reviews, 2000, 52(1):1-81.
[17]	HOLLAND H D, ZIMMERMAN H. The dolomite problem revisited[J]. International Geology Review, 2000, 42(6):37-41.
[18]	BRADY P V, KRUMHANSL J L, PAPENGUTH H W. Surface complexation clues to dolomite growth[J]. Geochimica et Cosmochimica Acta, 1996, 60(4):727-731. DOI URL
[19]	ARVIDSON R S, MACKENZIE F T. The dolomite problem: control of precipitation kinetics by temperature and saturation state[J]. American Journal of Science, 1999, 299(4):257-288. DOI URL
[20]	KIM I G, JO B H, KANG D G, et al. Biomineralization-based conversion of carbon dioxide to calcium carbonate using recombinant carbonic anhydrase[J]. Chemosphere, 2012, 87(10):1091-1096. DOI URL
[21]	KACZMAREK S E, SIBLEY D F. Direct physical evidence of dolomite recrystallization[J]. Sedimentology, 2014, 61(6):1862-1882. DOI URL
[22]	LIU Y, HU Z, ZONG K, et al. Reappraisement and refinement of zircon U-Pb isotope and trace element analyses by LA-ICP-MS[J]. Chinese Science Bulletin, 2010, 55(15):1535-1546.
[23]	EDWARDS H G M, VILLAR S E J, JEHLICKA J, et al. FT-Raman spectroscopic study of calcium-rich and magnesium-rich carbonate minerals[J]. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 2005, 61(10):2273-2280. DOI URL
[24]	汪凯明, 罗顺社. 海相碳酸盐岩锶同位素及微量元素特征与海平面变化[J]. 海洋地质与第四纪地质, 2009, 29(6):55-62.
[25]	ZHAO M Y, ZHENG Y F. Marine carbonate records of terrigenous input into Paleotethyan seawater: geochemical constraints from Carboniferous limestones[J]. Geochimica et Cosmochimica Acta, 2014, 141:508-531. DOI URL
[26]	倪善芹, 侯泉林, 王安建, 等. 碳酸盐岩中锶元素地球化学特征及其指示意义: 以北京下古生界碳酸盐岩为例[J]. 地质学报, 2010, 84(10):1510-1516.
[27]	李双应, 金福全, 王道轩. 碳酸盐岩成岩作用的微量元素地球化学特征[J]. 石油实验地质, 1995, 17(1):55-62.
[28]	高帮飞, 江少卿, 周迎春. 湖北蛇屋山金矿床含金碳酸盐岩风化成矿过程[J]. 地质与勘探, 2011, 47(3):361-369.
[29]	柳永清, 尹崇玉, 高林志, 等. 峡东震旦系层型剖面沉积相研究[J]. 地质论评, 2003, 49(2):187-194.
[30]	CLÉBER P C, THOMAS R F, BARBARA C, et al. Dolomitized cells within chert of the Permian Assistência Formation, Paraná Basin, Brazil[J]. Sedimentary Geology, 2016, 335:120-135. DOI URL

样品	w_B/%								w_B/10^-6
样品	Na	Mg		Al	Si	K	Mn	Fe	Li	B	P	Ti	V	Cr	Co	Ni	Cu	Zn	As	Rb
H-1	0.006	0.360		0.137	0.335	0.087	0.006	0.096	4.78	6.29	48.83	37.00	2.41	4.03	0.22	0.68	0.92	4.98	3.32	2.66
H-2	0.011	0.308		0.448	0.773	0.236	0.005	0.162	8.00	10.69	41.43	100.02	5.28	4.11	0.70	1.98	1.42	5.26	2.84	8.26
H-3	0.006	0.359		0.328	0.694	0.206	0.006	0.173	9.46	12.23	69.20	104.23	4.60	4.91	0.60	2.15	2.17	4.10	4.22	6.02
H-4	0.008	0.232		0.306	0.601	0.128	0.007	0.216	19.27	12.81	58.98	86.46	4.79	5.53	0.82	3.05	1.94	5.83	4.29	5.65
H-5	0.004	0.264		0.171	0.563	0.089	0.006	0.111	8.09	8.66	56.69	105.40	2.68	3.69	0.20	0.83	0.81	3.08	2.16	3.27
H-6	0.003	0.227		0.121	0.280	0.081	0.008	0.116	8.09	6.52	62.04	89.15	1.83	1.47	0.18	0.86	2.94	4.31	2.74	2.59
H-7	0.005	0.242		0.131	0.360	0.103	0.005	0.256	5.28	4.89	47.73	98.15	1.86	1.60	1.77	2.61	4.11	3.53	6.73	3.42
H-8	0.003	0.162		0.035	0.089	0.029	0.006	0.063	1.99	2.77	50.95	11.45	0.90	0.13	0.09	0.37	0.08	1.59	3.48	0.55
H-9	0.008	0.228		0.533	1.108	0.233	0.005	0.168	11.10	21.14	53.23	145.26	6.96	6.51	0.49	2.58	2.84	6.14	4.52	10.11
H-10	0.006	0.261		0.327	0.691	0.169	0.006	0.182	9.85	13.77	167.90	131.94	5.47	4.92	0.56	2.13	2.46	4.65	3.64	6.01
H-11	0.003	0.233		0.235	0.704	0.273	0.006	0.118	3.88	6.51	145.98	26.34	1.44	1.20	0.28	1.62	0.83	3.39	3.96	2.20
H-12	0.006	0.204		0.277	0.461	0.117	0.004	0.090	6.00	10.12	40.18	73.04	3.32	3.68	0.49	1.62	1.26	3.26	3.27	5.64
H-13	0.004	0.235		0.067	0.157	0.047	0.004	0.057	3.43	5.18	241.85	22.96	1.00	1.48	0.08	0.57	1.34	1.14	3.55	1.39
B-1	0.018	3.788		0.991	3.418	0.472	0.007	0.390	22.63	53.54	86.79	552.60	16.40	18.67	1.10	4.27	5.23	8.44	5.02	21.38
B-2	0.012	0.766		0.624	1.150	0.297	0.007	0.241	15.19	20.67	60.23	236.80	9.39	8.97	0.80	4.12	3.46	6.08	4.49	13.93
B-3	0.005	0.327		0.242	0.418	0.110	0.006	0.132	7.06	10.02	93.47	63.08	3.59	3.91	0.44	1.74	1.62	3.12	3.60	4.82
B-4	0.015	0.584		0.638	1.342	0.320	0.005	0.234	15.10	46.26	201.39	260.99	9.11	7.17	0.86	2.67	3.13	5.51	4.07	12.11
B-5	0.011	1.035		0.770	1.403	0.347	0.008	0.422	19.63	25.80	273.34	490.08	11.98	9.35	1.57	5.79	5.87	10.73	5.75	13.73
B-6	0.012	0.414		0.715	1.163	0.364	0.006	0.201	13.34	17.29	41.33	193.98	10.00	7.57	0.89	2.25	2.64	5.35	4.56	11.96
J-1	0.034	10.193		0.709	2.346	0.472	0.006	0.309	24.98	123.65	412.04	295.34	9.57	9.64	0.55	2.73	3.97	6.36	2.89	12.94
J-2	1.185	7.595		0.740	5.678	0.457	0.005	0.333	21.86	96.78	663.42	226.40	9.49	14.90	0.69	2.42	7.07	3.65	4.02	12.40
J-3	2.664	4.518		0.803	9.601	0.372	0.004	0.308	16.04	69.99	790.99	200.77	10.31	18.17	0.65	1.70	7.55	2.23	4.16	13.47
J-4	1.183	7.694		0.754	5.363	0.437	0.005	0.340	24.45	101.83	530.02	213.25	10.67	19.71	1.01	4.18	4.98	6.33	4.32	14.85
J-5	0.033	10.019		0.744	2.221	0.368	0.007	0.328	22.74	122.80	377.40	209.82	10.54	16.50	0.89	3.65	4.63	5.74	4.11	14.10
样品	w_B/10^-6
样品	Sr		Y	Zr	Ba	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho	Er	Tm	Yb	Lu	Pb
H-1	188.04		3.68	0.51	5.67	5.70	15.01	1.77	7.38	1.55	0.35	1.18	0.13	0.69	0.12	0.36	0.04	0.28	0.05	2.46
H-2	122.00		2.93	1.09	30.54	5.38	14.00	1.74	6.90	1.11	0.24	0.85	0.10	0.74	0.11	0.26	0.04	0.23	0.04	7.08
H-3	91.46		4.28	4.92	15.61	3.53	8.85	1.05	4.10	0.67	0.17	0.71	0.09	0.71	0.15	0.42	0.06	0.58	0.07	7.51
H-4	113.50		2.98	1.96	11.14	3.20	7.41	0.68	3.03	0.45	0.11	0.48	0.06	0.40	0.09	0.32	0.04	0.36	0.03	3.59
H-5	175.53		3.83	1.42	6.34	3.63	8.07	1.03	4.02	0.92	0.17	0.54	0.13	0.55	0.12	0.33	0.05	0.40	0.05	4.16
H-6	176.03		2.51	0.97	4.34	1.29	2.55	0.33	1.34	0.22	0.06	0.35	0.06	0.30	0.07	0.21	0.01	0.18	0.02	7.93
H-7	107.75		2.66	1.02	5.01	4.34	10.54	1.27	5.18	1.12	0.18	0.69	0.09	0.50	0.08	0.24	0.03	0.31	0.03	11.14
H-8	176.66		4.17	0.39	1.89	4.10	9.45	1.10	5.08	0.89	0.21	0.72	0.11	0.76	0.11	0.33	0.07	0.31	0.05	3.26
H-9	117.10		3.49	2.70	24.64	4.10	9.73	1.28	5.07	1.04	0.18	0.78	0.08	0.47	0.10	0.32	0.05	0.29	0.04	6.99
H-10	280.05		3.21	2.13	14.07	2.55	5.44	0.63	2.30	0.55	0.10	0.40	0.07	0.50	0.11	0.26	0.05	0.32	0.03	13.00
H-11	156.11		3.84	0.14	2.59	3.62	7.95	0.96	3.85	0.91	0.18	0.74	0.11	0.64	0.10	0.33	0.07	0.40	0.05	3.67
H-12	75.89		2.19	1.18	15.43	7.61	18.89	2.31	9.97	1.55	0.33	1.04	0.11	0.45	0.07	0.15	0.02	0.25	0.02	3.07
H-13	131.93		2.62	0.35	2.98	5.79	14.23	1.85	7.49	1.16	0.24	0.84	0.09	0.53	0.07	0.25	0.03	0.18	0.03	3.74
B-1	88.58		3.70	8.87	46.53	4.15	11.26	1.45	5.60	1.03	0.17	0.83	0.11	0.75	0.02	0.36	0.06	0.47	0.07	15.34
B-2	111.50		2.94	4.64	36.16	3.27	7.68	0.89	3.59	0.60	0.15	0.70	0.09	0.49	0.11	0.34	0.04	0.39	0.04	6.38
B-3	191.80		2.22	1.48	13.17	3.21	7.59	0.89	3.75	0.72	0.14	0.36	0.06	0.34	0.06	0.22	0.03	0.20	0.03	7.09
B-4	91.92		3.68	7.77	26.56	5.04	12.96	1.55	6.02	1.00	0.21	0.91	0.11	0.64	0.13	0.35	0.05	0.43	0.06	7.08
B-5	151.38		3.63	5.38	31.43	5.18	14.42	1.83	7.82	1.43	0.29	0.99	0.13	0.80	0.13	0.30	0.04	0.29	0.04	8.90
B-6	171.65		2.25	2.43	67.01	4.77	10.21	1.16	4.53	0.76	0.15	0.63	0.08	0.41	0.05	0.21	0.02	0.20	0.04	4.49
J-1	51.23		1.77	3.88	29.99	1.91	4.14	0.47	1.68	0.42	0.10	0.37	0.04	0.34	0.06	0.20	0.02	0.22	0.02	10.10
J-2	51.30		1.54	11.42	53.31	1.85	3.36	0.37	1.25	0.33	0.09	0.25	0.03	0.29	0.08	0.17	0.02	0.14	0.03	13.17
J-3	55.80		1.45	18.31	85.26	2.95	4.41	0.44	1.91	0.43	0.12	0.26	0.06	0.26	0.05	0.15	0.02	0.12	0.02	12.07
J-4	52.77		1.53	10.57	55.03	1.58	3.09	0.33	1.84	0.38	0.07	0.41	0.06	0.32	0.05	0.14	0.02	0.10	0.01	10.23
J-5	54.62		1.72	3.76	35.89	2.14	5.33	0.62	2.45	0.55	0.10	0.33	0.05	0.31	0.06	0.20	0.02	0.24	0.02	16.69

样品	w_B/%								w_B/10^-6
样品	Na	Mg		Al	Si	K	Mn	Fe	Li	B	P	Ti	V	Cr	Co	Ni	Cu	Zn	As	Rb
H-1	0.006	0.360		0.137	0.335	0.087	0.006	0.096	4.78	6.29	48.83	37.00	2.41	4.03	0.22	0.68	0.92	4.98	3.32	2.66
H-2	0.011	0.308		0.448	0.773	0.236	0.005	0.162	8.00	10.69	41.43	100.02	5.28	4.11	0.70	1.98	1.42	5.26	2.84	8.26
H-3	0.006	0.359		0.328	0.694	0.206	0.006	0.173	9.46	12.23	69.20	104.23	4.60	4.91	0.60	2.15	2.17	4.10	4.22	6.02
H-4	0.008	0.232		0.306	0.601	0.128	0.007	0.216	19.27	12.81	58.98	86.46	4.79	5.53	0.82	3.05	1.94	5.83	4.29	5.65
H-5	0.004	0.264		0.171	0.563	0.089	0.006	0.111	8.09	8.66	56.69	105.40	2.68	3.69	0.20	0.83	0.81	3.08	2.16	3.27
H-6	0.003	0.227		0.121	0.280	0.081	0.008	0.116	8.09	6.52	62.04	89.15	1.83	1.47	0.18	0.86	2.94	4.31	2.74	2.59
H-7	0.005	0.242		0.131	0.360	0.103	0.005	0.256	5.28	4.89	47.73	98.15	1.86	1.60	1.77	2.61	4.11	3.53	6.73	3.42
H-8	0.003	0.162		0.035	0.089	0.029	0.006	0.063	1.99	2.77	50.95	11.45	0.90	0.13	0.09	0.37	0.08	1.59	3.48	0.55
H-9	0.008	0.228		0.533	1.108	0.233	0.005	0.168	11.10	21.14	53.23	145.26	6.96	6.51	0.49	2.58	2.84	6.14	4.52	10.11
H-10	0.006	0.261		0.327	0.691	0.169	0.006	0.182	9.85	13.77	167.90	131.94	5.47	4.92	0.56	2.13	2.46	4.65	3.64	6.01
H-11	0.003	0.233		0.235	0.704	0.273	0.006	0.118	3.88	6.51	145.98	26.34	1.44	1.20	0.28	1.62	0.83	3.39	3.96	2.20
H-12	0.006	0.204		0.277	0.461	0.117	0.004	0.090	6.00	10.12	40.18	73.04	3.32	3.68	0.49	1.62	1.26	3.26	3.27	5.64
H-13	0.004	0.235		0.067	0.157	0.047	0.004	0.057	3.43	5.18	241.85	22.96	1.00	1.48	0.08	0.57	1.34	1.14	3.55	1.39
B-1	0.018	3.788		0.991	3.418	0.472	0.007	0.390	22.63	53.54	86.79	552.60	16.40	18.67	1.10	4.27	5.23	8.44	5.02	21.38
B-2	0.012	0.766		0.624	1.150	0.297	0.007	0.241	15.19	20.67	60.23	236.80	9.39	8.97	0.80	4.12	3.46	6.08	4.49	13.93
B-3	0.005	0.327		0.242	0.418	0.110	0.006	0.132	7.06	10.02	93.47	63.08	3.59	3.91	0.44	1.74	1.62	3.12	3.60	4.82
B-4	0.015	0.584		0.638	1.342	0.320	0.005	0.234	15.10	46.26	201.39	260.99	9.11	7.17	0.86	2.67	3.13	5.51	4.07	12.11
B-5	0.011	1.035		0.770	1.403	0.347	0.008	0.422	19.63	25.80	273.34	490.08	11.98	9.35	1.57	5.79	5.87	10.73	5.75	13.73
B-6	0.012	0.414		0.715	1.163	0.364	0.006	0.201	13.34	17.29	41.33	193.98	10.00	7.57	0.89	2.25	2.64	5.35	4.56	11.96
J-1	0.034	10.193		0.709	2.346	0.472	0.006	0.309	24.98	123.65	412.04	295.34	9.57	9.64	0.55	2.73	3.97	6.36	2.89	12.94
J-2	1.185	7.595		0.740	5.678	0.457	0.005	0.333	21.86	96.78	663.42	226.40	9.49	14.90	0.69	2.42	7.07	3.65	4.02	12.40
J-3	2.664	4.518		0.803	9.601	0.372	0.004	0.308	16.04	69.99	790.99	200.77	10.31	18.17	0.65	1.70	7.55	2.23	4.16	13.47
J-4	1.183	7.694		0.754	5.363	0.437	0.005	0.340	24.45	101.83	530.02	213.25	10.67	19.71	1.01	4.18	4.98	6.33	4.32	14.85
J-5	0.033	10.019		0.744	2.221	0.368	0.007	0.328	22.74	122.80	377.40	209.82	10.54	16.50	0.89	3.65	4.63	5.74	4.11	14.10
样品	w_B/10^-6
样品	Sr		Y	Zr	Ba	La	Ce	Pr	Nd	Sm	Eu	Gd	Tb	Dy	Ho	Er	Tm	Yb	Lu	Pb
H-1	188.04		3.68	0.51	5.67	5.70	15.01	1.77	7.38	1.55	0.35	1.18	0.13	0.69	0.12	0.36	0.04	0.28	0.05	2.46
H-2	122.00		2.93	1.09	30.54	5.38	14.00	1.74	6.90	1.11	0.24	0.85	0.10	0.74	0.11	0.26	0.04	0.23	0.04	7.08
H-3	91.46		4.28	4.92	15.61	3.53	8.85	1.05	4.10	0.67	0.17	0.71	0.09	0.71	0.15	0.42	0.06	0.58	0.07	7.51
H-4	113.50		2.98	1.96	11.14	3.20	7.41	0.68	3.03	0.45	0.11	0.48	0.06	0.40	0.09	0.32	0.04	0.36	0.03	3.59
H-5	175.53		3.83	1.42	6.34	3.63	8.07	1.03	4.02	0.92	0.17	0.54	0.13	0.55	0.12	0.33	0.05	0.40	0.05	4.16
H-6	176.03		2.51	0.97	4.34	1.29	2.55	0.33	1.34	0.22	0.06	0.35	0.06	0.30	0.07	0.21	0.01	0.18	0.02	7.93
H-7	107.75		2.66	1.02	5.01	4.34	10.54	1.27	5.18	1.12	0.18	0.69	0.09	0.50	0.08	0.24	0.03	0.31	0.03	11.14
H-8	176.66		4.17	0.39	1.89	4.10	9.45	1.10	5.08	0.89	0.21	0.72	0.11	0.76	0.11	0.33	0.07	0.31	0.05	3.26
H-9	117.10		3.49	2.70	24.64	4.10	9.73	1.28	5.07	1.04	0.18	0.78	0.08	0.47	0.10	0.32	0.05	0.29	0.04	6.99
H-10	280.05		3.21	2.13	14.07	2.55	5.44	0.63	2.30	0.55	0.10	0.40	0.07	0.50	0.11	0.26	0.05	0.32	0.03	13.00
H-11	156.11		3.84	0.14	2.59	3.62	7.95	0.96	3.85	0.91	0.18	0.74	0.11	0.64	0.10	0.33	0.07	0.40	0.05	3.67
H-12	75.89		2.19	1.18	15.43	7.61	18.89	2.31	9.97	1.55	0.33	1.04	0.11	0.45	0.07	0.15	0.02	0.25	0.02	3.07
H-13	131.93		2.62	0.35	2.98	5.79	14.23	1.85	7.49	1.16	0.24	0.84	0.09	0.53	0.07	0.25	0.03	0.18	0.03	3.74
B-1	88.58		3.70	8.87	46.53	4.15	11.26	1.45	5.60	1.03	0.17	0.83	0.11	0.75	0.02	0.36	0.06	0.47	0.07	15.34
B-2	111.50		2.94	4.64	36.16	3.27	7.68	0.89	3.59	0.60	0.15	0.70	0.09	0.49	0.11	0.34	0.04	0.39	0.04	6.38
B-3	191.80		2.22	1.48	13.17	3.21	7.59	0.89	3.75	0.72	0.14	0.36	0.06	0.34	0.06	0.22	0.03	0.20	0.03	7.09
B-4	91.92		3.68	7.77	26.56	5.04	12.96	1.55	6.02	1.00	0.21	0.91	0.11	0.64	0.13	0.35	0.05	0.43	0.06	7.08
B-5	151.38		3.63	5.38	31.43	5.18	14.42	1.83	7.82	1.43	0.29	0.99	0.13	0.80	0.13	0.30	0.04	0.29	0.04	8.90
B-6	171.65		2.25	2.43	67.01	4.77	10.21	1.16	4.53	0.76	0.15	0.63	0.08	0.41	0.05	0.21	0.02	0.20	0.04	4.49
J-1	51.23		1.77	3.88	29.99	1.91	4.14	0.47	1.68	0.42	0.10	0.37	0.04	0.34	0.06	0.20	0.02	0.22	0.02	10.10
J-2	51.30		1.54	11.42	53.31	1.85	3.36	0.37	1.25	0.33	0.09	0.25	0.03	0.29	0.08	0.17	0.02	0.14	0.03	13.17
J-3	55.80		1.45	18.31	85.26	2.95	4.41	0.44	1.91	0.43	0.12	0.26	0.06	0.26	0.05	0.15	0.02	0.12	0.02	12.07
J-4	52.77		1.53	10.57	55.03	1.58	3.09	0.33	1.84	0.38	0.07	0.41	0.06	0.32	0.05	0.14	0.02	0.10	0.01	10.23
J-5	54.62		1.72	3.76	35.89	2.14	5.33	0.62	2.45	0.55	0.10	0.33	0.05	0.31	0.06	0.20	0.02	0.24	0.02	16.69
