The Upper-Lower Cretaceous boundary in the southern Songliao Basin: A case study of ICDP borehole SK-3

doi:10.13745/j.esf.sf.2023.1.28

Abstract

Abstract:

The internationally recognized absolute isotopic age of the Upper-Lower Cretaceous stratigraphic boundary is 100.5 Ma, and the Global Boundary Stratotype Section and Points (GSSP) for the boundary is placed in marine strata; however, there have been no reports of GSSP (“golden spikes”) for terrestrial boundaries anywhere in the world. The terrestrial Upper-Lower Cretaceous stratigraphic boundary is of great value in understanding the evolution of paleogeography, paleoenvironment and paleoclimate on land under the greenhouse conditions in the Middle Cretaceous, and the ideal geological records for studying this boundary may be found in the Songliao Basin, northeastern China, where a complete set of Cretaceous continental strata are developed. Here, we investigated the rock types, lithologic sequence and sedimentary facies in the core section of International Continental Scientific Drilling Program (ICDP) borehole SK-3, southern Songliao Basin. Based on the core description, gray and gray-green rhyolitic lithic crystalline tuffite deposit is found in the coastal-shallow lacustrine sedimentary sequences of the upper part of the second member of the Quantou Formation at 1191.6 m depth. The tuffite deposit, according to zircon U-Pb dating of its syndepositional magmatic components, has an zircon age of (96.8±2.9) Ma and belongs to the Middle-Cenomanian period. Combined with previous data, the deposition rate for the Quantou-Denglouku Formations in the study area is 90.54-110 m/Ma, and we conclude accordingly that the Upper-Lower Cretaceous stratigraphic boundary is located in the middle of the first member of the Quantou Formation in borehole SK-3 (at 1526.6-1598.6 m depth). Considering analytical errors in the age-dating results, the Upper-Lower Cretaceous stratigraphic boundary in borehole SK-3 is independently calculated to be between the middle of the second member of the Quantou Formation and the upper part of the fourth member of the Denglouku Formation (at 1279.6-1917.6 m depth). Other researchers have tentatively placed the boundary in the Denglouku Formation based on the chronological data of ICDP borehole SK-1 and SK-2, northern Songliao Basin. The continuous coring data reveal continuous fluvial-lacustrine sedimentary sequences in the Denglouku-Quantou Formations in borehole SK-3; while results of seismic horizon matching further suggest the Denglouku-Quantou Formations are widely developed across the Songliao Basin and sedimentary records of continuous deposition are widespread. Therefore, the Denglouku-Quantou Formations across the basin should provide the geological record of continuous deposition of the Upper-Lower Cretaceous stratigraphic boundary. And this paper provides the basic dataset and exploration direction to find the “golden spikes” for the Upper and Lower Cretaceous continental stratigraphic boundary in the Songliao Basin and adjacent areas.

Key words: Songliao Basin, International Continental Scientific Drilling Program Borehole SK-3, Upper and Lower Cretaceous stratigraphic boundary, potential GSSP golden spikes in terrestrial strata, Cretaceous Denglouku-Quantou Formations

CLC Number:

GAO Hang, WANG Pujun, GAO Youfeng, WAN Xiaoqiao, YANG Guang, HU Jingsong, WU Huaichun. The Upper-Lower Cretaceous boundary in the southern Songliao Basin: A case study of ICDP borehole SK-3[J]. Earth Science Frontiers, 2023, 30(3): 425-440.

Figures/Tables 9

References 46

[1]	ZHONG Y, WANG Y, JIA B, et al. A potential terrestrial Albian-Cenomanian boundary in the Yanji Basin, Northeast China[J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 2021, 562: 110088. DOI URL
[2]	GALE A S, KENNEDY W J, BURNETT J A, et al. The Late Albian to Early Cenomanian succession at Mont Risou near Rosans (Drôme, SE France): an integrated study (ammonites, inoceramids, planktonic foraminifera, nannofossils, oxygen and carbon isotopes)[J]. Cretaceous Research, 1996, 17(5): 515-606. DOI URL
[3]	KENNEDY W J, GALE A S, LEES J A, et al. The Global Boundary Stratotype Section and Point (GSSP) for the base of the Cenomanian Stage, Mont Risou, Hautes-Alpes, France[J]. Episodes, 2004, 27(1): 21-32. DOI URL
[4]	COHEN K M, FINNEY S C, GIBBARD P L, et al. The ICS international chronostratigraphic chart[J]. Episodes: Journal of International Geoscience, 2013, 36(3): 199-204.
[5]	CRAMPTON J S, TULLOCH A J, WILSON G J, et al. Definition, age, and correlation of the Clarence Series stages in New Zealand (late Early to early Late Cretaceous)[J]. New Zealand Journal of Geology and Geophysics, 2004, 47(1): 1-19. DOI URL
[6]	ANDO A. Recent contributions to the standard Albian/Cenomanian boundary chronology from Hokkaido, Japan:a review for data reintegration and numerical age recalibration[J]. Cretaceous Research, 2016, 64: 50-58. DOI URL
[7]	SAMES B, HORNE D J. 侏罗纪末至白垩纪非海相介形类生物地层学: 回顾与展望 ①[J]. 地层学杂志, 2012, 36(2): 266-268.
[8]	HAQ B U. Cretaceous eustasy revisited[J]. Global and Planetary Change, 2014, 113: 44-58. DOI URL
[9]	李东津, 王光奇, 李春田. 试论松辽盆地白垩系上下统的分界[J]. 吉林地质, 1986(3): 22-29.
[10]	高瑞祺, 赵传本, 郑玉龙, 等. 松辽盆地深层早白垩世孢粉组合研究[J]. 古生物学报, 1994(6): 659- 675, 785-787.
[11]	于文卿, 孙希, 于恩君, 等. 松辽盆地白垩纪地层时代划分[J]. 铀矿地质, 1999(5): 2-10.
[12]	黎文本. 从孢粉组合论证松辽盆地泉头组的地质时代及上、下白垩统界线[J]. 古生物学报, 2001(2): 153-176.
[13]	黄清华, 张文婧, 贾琼, 等. 松辽盆地上、下白垩统界线划分[J]. 地学前缘, 2009, 16(6): 77-84.
[14]	黄清华, 吴怀春, 万晓樵, 等. 松辽盆地白垩系综合年代地层学研究新进展[J]. 地层学杂志, 2011, 35(3): 250-257.
[15]	万晓樵, 李罡, 黄清华, 等. 中国白垩纪陆相阶的划分与对比[J]. 地层学杂志, 2013, 37(4): 457-471.
[16]	席党鹏, 万晓樵, 李国彪, 等. 中国白垩纪综合地层和时间框架[J]. 中国科学: 地球科学, 2019, 49(1): 257-288.
[17]	王燕. 辽西-内蒙古东部地区阜新组、孙家湾组生物地层与上、下白垩统界线研究[D]. 北京: 中国地质大学(北京), 2020.
[18]	席党鹏, 孙立新, 覃祚焕, 等. 中国白垩纪岩石地层划分和对比[J]. 地层学杂志, 2021, 45(3): 375-401.
[19]	瞿雪姣, 高有峰, 林志成, 等. 松辽盆地及周缘地区侏罗系/白垩系界线区域对比特征探讨[J]. 地学前缘, 2021, 28(4): 299-315. DOI
[20]	FENG Z Q, JIA C Z, XIE X N, et al. Tectonostratigraphic units and stratigraphic sequences of the nonmarine Songliao Basin, Northeast China[J]. Basin Research, 2010, 22(1): 79-55. DOI URL
[21]	瞿雪姣, 王璞珺, 高有峰, 等. 松辽盆地断陷期火石岭组时代归属探讨[J]. 地学前缘, 2014, 21(2): 234-250. DOI
[22]	王璞珺, 赵然磊, 蒙启安, 等. 白垩纪松辽盆地: 从火山裂谷到陆内拗陷的动力学环境[J]. 地学前缘, 2015, 22(3): 99-117 DOI
[23]	WANG P J, MATTERN F, DIDENKO N A, et al. Tectonics and cycle system of the Cretaceous Songliao Basin: an inverted active continental margin basin[J]. Earth-Science Reviews, 2016, 159: 82-102. DOI URL
[24]	王璞珺, 刘海波, 任延广, 等. 松辽盆地白垩系大陆科学钻探 “松科2井” 选址[J]. 地学前缘, 2017, 24(1): 216-228.
[25]	王成善, 冯志强, 吴河勇, 等. 中国白垩纪大陆科学钻探工程: 松科1井科学钻探工程的实施与初步进展[J]. 地质学报, 2008(1): 9-20.
[26]	高有峰, 王璞珺, 程日辉, 等. 松科1井南孔白垩系青山口组一段沉积序列精细描述: 岩石地层、沉积相与旋回地层[J]. 地学前缘, 2009, 16(2): 314-323.
[27]	刘硕, 高有峰, 尹永康, 等. 松辽盆地大陆科学钻探 “松科2井” 登娄库组二段沉积序列精细刻画及时代归属[J]. 世界地质, 2019, 38(4): 1032-1043.
[28]	国家质量技术监督局. GB/T 17412.2—1998 沉积岩岩石分类和命名方案[S]. 北京: 中国标准出版社, 2000: 5-6.
[29]	曾允孚, 夏文杰. 沉积岩石学[M]. 北京: 地质出版社, 1986: 219-240.
[30]	冯增昭. 沉积岩石学[M]. 北京: 石油工业出版社, 1993.
[31]	赵澄林, 朱筱敏. 沉积岩石学[M]. 北京: 石油工业出版社, 2001.
[32]	姜在兴. 沉积学[M]. 北京: 石油工业出版社, 2003: 257-403.
[33]	《地球科学大辞典》编委会. 基础科学卷: 地球科学大辞典[M]. 北京: 地质出版社, 2006.
[34]	杨伟东, 关平, 李建明. 英汉沉积学解释辞典[M]. 北京: 北京大学出版社, 1991.
[35]	READING H G. Sedimentary environments and facies[M]. Oxford: Blackwell Scientific Publications, 1978.
[36]	ANDERSON T. Correction of common lead in U-Pb analyses that do not report ²⁰⁴Pb[J]. Chemical Geology, 2002, 192(1): 59-79. DOI URL
[37]	LUDWIG K R. Isoplot 3.00: a geochronological toolkit for Microsoft Excel[J]. Berkeley Geochronology Center Special Publication, 2003, 4: 70.
[38]	PUPIN J P. Zircon and granite petrology[J]. Contributions to Mineralogy and Petrology, 1980, 73(3): 207-220. DOI URL
[39]	YUAN H, GAO S, LIU X, et al. Accurate U-Pb age and trace element determinations of zircon by laser ablation-inductively coupled plasma-mass spectrometry[J]. Geostandards and Geoanalytical Research, 2004, 28(3): 353-370. DOI URL
[40]	HE H, DENG C, WANG P, et al. Toward age determination of the termination of the Cretaceous Normal Superchron[J]. Geochemistry, Geophysics, Geosystems, 2012, 13(2): 1-20. DOI URL
[41]	WANG T, RAMEZANI J, WANG C, et al. High-precision U-Pb geochronologic constraints on the Late Cretaceous terrestrial cyclostratigraphy and geomagnetic polarity from the Songliao Basin, Northeast China[J]. Earth and Planetary Science Letters, 2016, 446: 37-44. DOI URL
[42]	WU H, HINNOV L A, ZHANG S, et al. Continental geological evidence for solar system chaotic behavior in the Late Cretaceous[J/OL]. GSA Bulletin, 2022. (2022-07-06) [2023-01-10]. https://doi.org/10.1130/B36340.1
[43]	WANG T, WANG C, RAMEZANI J, et al. High-precision geochronology of the Early Cretaceous Yingcheng Formation and its stratigraphic implications for Songliao Basin, China[J]. Geoscience Frontiers, 2022, 13(4): 101386. DOI URL
[44]	MA X, WU H, FANG Q, et al. A floating astronomical time scale for the early Late Cretaceous continental strata in the Songliao Basin, northeastern China[J]. Acta Geologica Sinica (English Edition), 2020, 94(1): 27-37. DOI URL
[45]	WAN X Q, ZHAO J, SCOTT R W, et al. Late Cretaceous stratigraphy, Songliao Basin, NE China: SK1 cores[J]. Palaeogeography, Palaeoclimatology, Palaeoecology, 2013, 385: 31-43. DOI URL
[46]	WANG P, CHEN S. Cretaceous volcanic reservoirs and their exploration in the Songliao Basin, Northeast China[J]. AAPG Bulletin, 2015, 99(3): 499-523. DOI URL

取心次数	层位	井段/m	进尺/m	心长/m	收获率/%
1	泉四段	839.75~848.51	8.76	8.76	100
2	泉四段、泉三段	848.51~857.64	9.13	9.13	100
3	泉三段	857.64~866.97	9.33	9.28	99.46
4	泉三段	866.97~870.10	3.13	3.13	100
5	泉三段	870.10~879.71	9.61	9.41	97.91
6	泉三段	879.71~888.92	9.21	9.17	99.56
7	泉三段	888.92~898.09	9.17	9.09	99.12
8	泉三段	898.09~907.16	9.07	8.9	98.12
9	泉三段	907.16~925.23	18.07	17.2	95.18
10	泉三段	925.23~943.31	18.08	17.74	98.11
11	泉三段	943.31~961.49	18.18	18.06	99.33
12	泉三段	961.49~979.86	18.37	18.05	98.25
13	泉三段	979.86~998.09	18.23	17.82	97.75
14	泉三段	998.09~1 016.18	18.09	17.8	98.39
15	泉三段	1 016.18~1 034.16	17.98	17.6	97.88
16	泉三段	1 034.16~1 052.05	17.89	17.7	98.93
17	泉三段	1 052.05~1 070.50	18.45	17.73	96.09
18	泉三段	1 070.50~1 088.00	17.5	17.36	99.2
19	泉三段	1 088.00~1 112.67	24.67	23.99	97.24
20	泉三段	1 112.67~1 135.60	22.93	22.65	98.77
21	泉三段、泉二段	1 135.60~1 161.75	26.15	24.85	95.02
22	泉二段	1 161.75~1 184.24	22.49	21.37	95.02
23	泉二段	1 184.24~1 211.57	27.33	26.76	97.91
24	泉二段	1 211.57~1 237.23	25.66	25.38	98.9
25	泉二段	1 237.23~1 261.52	24.29	24.1	99.21
26	泉二段	1 261.52~1 284.99	23.47	23.15	98.63
27	泉二段	1 284.99~1 309.69	24.7	24.52	99.27
28	泉二段	1 309.69~1 336.50	26.81	26.7	99.58
29	泉二段	1 336.50~1 363.56	27.06	26.93	99.51
30	泉二段、泉一段	1 363.56~1 386.57	23.01	23.01	100
31	泉一段	1 386.57~1 413.57	27	26.93	99.74
32	泉一段	1 413.57~1 434.57	21	21	100
33	泉一段	1 434.57~1 461.87	27.3	27.16	99.48
34	泉一段	1 461.87~1 483.08	21.21	20.98	98.91
35	泉一段	1 483.08~1 509.45	26.37	26.22	99.43
36	泉一段	1 509.45~1 531.41	21.96	21.88	99.63
37	泉一段	1 531.41~1 558.77	27.36	27.03	98.79
38	泉一段	1 558.77~1 585.94	27.17	26.53	97.64
39	泉一段	1 585.94~1 609.07	23.13	22.87	98.87
40	泉一段	1 609.07~1 636.11	27.04	26.73	98.85
41	泉一段	1 636.11~1 663.09	26.98	26.78	99.25
42	泉一段	1 663.09~1 690.09	27	26.75	99.07
43	泉一段	1 690.09~1 717.01	26.92	26.7	99.18
44	泉一段、登娄库组	1 717.01~1 744.13	27.12	26.86	99.04
45	登娄库组	1 744.13~1 771.22	27.09	26.85	99.11
46	登娄库组	1 771.22~1 798.46	27.24	26.1	95.81
47	登娄库组	1 798.46~1 825.52	27.06	26.79	99
48	登娄库组	1 825.52~1 844.32	18.8	18.61	98.98
49	登娄库组	1 844.32~1 845.34	1.02	0.95	93.13
50	登娄库组	1 845.34~1 872.42	27.08	27.08	100
51	登娄库组	1 872.42~1 899.30	26.88	26.87	99.96
52	登娄库组	1 899.30~1 926.19	26.89	26.78	99.59
53	登娄库组	1 926.19~1 952.87	26.68	26.55	99.51
54	登娄库组	1 952.87~1 980.26	27.39	27.25	99.48
55	登娄库组	1 980.26~2 007.70	27.44	27.38	99.78
56	登娄库组	2 007.70~2 032.31	24.61	24.3	98.74
57	登娄库组	2 032.31~2 059.36	27.05	27.05	100
58	登娄库组	2 059.36~2 086.45	27.09	27	99.66
59	登娄库组	2 086.45~2 113.71	27.26	27.24	99.92
60	登娄库组	2 113.71~2 139.94	26.23	25.85	98.55
61	登娄库组	2 139.94~2 167.35	27.41	27.24	99.37
62	登娄库组	2 167.35~2 194.44	27.09	27.03	99.77
63	登娄库组	2 194.44~2 221.56	27.12	27.08	99.85
64	登娄库组	2 221.56~2 248.95	27.39	27.34	99.81
65	登娄库组	2 248.95~2 274.76	25.81	25.7	99.57
66	登娄库组	2 274.76~2 301.94	27.18	27.1	99.7
67	登娄库组	2 301.94~2 328.75	26.81	26.4	98.47
68	登娄库组	2 328.75~2 355.85	27.1	26.98	99.55
69	登娄库组	2 355.85~2 378.99	23.14	23.02	99.48
70	登娄库组、沙河子组	2 378.99~2 406.04	27.05	26.8	99.07
71	沙河子组	2 406.04~2 420.09	14.05	13.92	99.07
72	火石岭组	2 884.00~2 893.02	9.02	8.57	95.01
73	火石岭组	2 893.02~2 911.05	18.03	17.52	97.17

取心次数	层位	井段/m	进尺/m	心长/m	收获率/%
1	泉四段	839.75~848.51	8.76	8.76	100
2	泉四段、泉三段	848.51~857.64	9.13	9.13	100
3	泉三段	857.64~866.97	9.33	9.28	99.46
4	泉三段	866.97~870.10	3.13	3.13	100
5	泉三段	870.10~879.71	9.61	9.41	97.91
6	泉三段	879.71~888.92	9.21	9.17	99.56
7	泉三段	888.92~898.09	9.17	9.09	99.12
8	泉三段	898.09~907.16	9.07	8.9	98.12
9	泉三段	907.16~925.23	18.07	17.2	95.18
10	泉三段	925.23~943.31	18.08	17.74	98.11
11	泉三段	943.31~961.49	18.18	18.06	99.33
12	泉三段	961.49~979.86	18.37	18.05	98.25
13	泉三段	979.86~998.09	18.23	17.82	97.75
14	泉三段	998.09~1 016.18	18.09	17.8	98.39
15	泉三段	1 016.18~1 034.16	17.98	17.6	97.88
16	泉三段	1 034.16~1 052.05	17.89	17.7	98.93
17	泉三段	1 052.05~1 070.50	18.45	17.73	96.09
18	泉三段	1 070.50~1 088.00	17.5	17.36	99.2
19	泉三段	1 088.00~1 112.67	24.67	23.99	97.24
20	泉三段	1 112.67~1 135.60	22.93	22.65	98.77
21	泉三段、泉二段	1 135.60~1 161.75	26.15	24.85	95.02
22	泉二段	1 161.75~1 184.24	22.49	21.37	95.02
23	泉二段	1 184.24~1 211.57	27.33	26.76	97.91
24	泉二段	1 211.57~1 237.23	25.66	25.38	98.9
25	泉二段	1 237.23~1 261.52	24.29	24.1	99.21
26	泉二段	1 261.52~1 284.99	23.47	23.15	98.63
27	泉二段	1 284.99~1 309.69	24.7	24.52	99.27
28	泉二段	1 309.69~1 336.50	26.81	26.7	99.58
29	泉二段	1 336.50~1 363.56	27.06	26.93	99.51
30	泉二段、泉一段	1 363.56~1 386.57	23.01	23.01	100
31	泉一段	1 386.57~1 413.57	27	26.93	99.74
32	泉一段	1 413.57~1 434.57	21	21	100
33	泉一段	1 434.57~1 461.87	27.3	27.16	99.48
34	泉一段	1 461.87~1 483.08	21.21	20.98	98.91
35	泉一段	1 483.08~1 509.45	26.37	26.22	99.43
36	泉一段	1 509.45~1 531.41	21.96	21.88	99.63
37	泉一段	1 531.41~1 558.77	27.36	27.03	98.79
38	泉一段	1 558.77~1 585.94	27.17	26.53	97.64
39	泉一段	1 585.94~1 609.07	23.13	22.87	98.87
40	泉一段	1 609.07~1 636.11	27.04	26.73	98.85
41	泉一段	1 636.11~1 663.09	26.98	26.78	99.25
42	泉一段	1 663.09~1 690.09	27	26.75	99.07
43	泉一段	1 690.09~1 717.01	26.92	26.7	99.18
44	泉一段、登娄库组	1 717.01~1 744.13	27.12	26.86	99.04
45	登娄库组	1 744.13~1 771.22	27.09	26.85	99.11
46	登娄库组	1 771.22~1 798.46	27.24	26.1	95.81
47	登娄库组	1 798.46~1 825.52	27.06	26.79	99
48	登娄库组	1 825.52~1 844.32	18.8	18.61	98.98
49	登娄库组	1 844.32~1 845.34	1.02	0.95	93.13
50	登娄库组	1 845.34~1 872.42	27.08	27.08	100
51	登娄库组	1 872.42~1 899.30	26.88	26.87	99.96
52	登娄库组	1 899.30~1 926.19	26.89	26.78	99.59
53	登娄库组	1 926.19~1 952.87	26.68	26.55	99.51
54	登娄库组	1 952.87~1 980.26	27.39	27.25	99.48
55	登娄库组	1 980.26~2 007.70	27.44	27.38	99.78
56	登娄库组	2 007.70~2 032.31	24.61	24.3	98.74
57	登娄库组	2 032.31~2 059.36	27.05	27.05	100
58	登娄库组	2 059.36~2 086.45	27.09	27	99.66
59	登娄库组	2 086.45~2 113.71	27.26	27.24	99.92
60	登娄库组	2 113.71~2 139.94	26.23	25.85	98.55
61	登娄库组	2 139.94~2 167.35	27.41	27.24	99.37
62	登娄库组	2 167.35~2 194.44	27.09	27.03	99.77
63	登娄库组	2 194.44~2 221.56	27.12	27.08	99.85
64	登娄库组	2 221.56~2 248.95	27.39	27.34	99.81
65	登娄库组	2 248.95~2 274.76	25.81	25.7	99.57
66	登娄库组	2 274.76~2 301.94	27.18	27.1	99.7
67	登娄库组	2 301.94~2 328.75	26.81	26.4	98.47
68	登娄库组	2 328.75~2 355.85	27.1	26.98	99.55
69	登娄库组	2 355.85~2 378.99	23.14	23.02	99.48
70	登娄库组、沙河子组	2 378.99~2 406.04	27.05	26.8	99.07
71	沙河子组	2 406.04~2 420.09	14.05	13.92	99.07
72	火石岭组	2 884.00~2 893.02	9.02	8.57	95.01
73	火石岭组	2 893.02~2 911.05	18.03	17.52	97.17
