Late Triassic magmatic activity in Duobaoshan area, Heilongjiang Province: Response to the southward subduction of the Mongol-Okhotsk Ocean

doi:10.13745/j.esf.sf.2021.7.15

Abstract

Abstract:

Late-Triassic magmatic rocks have been discovered in recent years in the Duobaoshan area of Nenjiang. So far, the tectonic setting, genesis and metallogeny of the magmatic activity have not been well understood, which significantly hindered our understanding of the regional tectonic evolution and prospecting for polymetallic deposits in this area. In this paper, we conducted systematic petrological, geochemical and geochronological studies of tonalite in the Duobaoshan deposit and diorite in the Zhengguang deposit. LA-ICP-MS zircon U-Pb dating yielded an age of (226.3±2.3) Ma for the Duobaoshan tonalite and (229.3±3.1) Ma for the Zhengguang diorite, indicating the two minerals, with similar formation age, are probably derived from the same magma chamber. The tonalite had elevated SiO₂ (64.25%-66.44%), Al₂O₃ (16.54%-17.21%), (K₂O+Na₂O) (8.15%-8.50%) and low CaO (2.27%-2.95%), MgO (0.99%-1.16%), TiO₂ (0.31%-0.36%) and P₅O₂ (0.16%-0.17%) contents comparable with the diorite whose major element contents were SiO₂ (57.12%-58.5%), Al₂O₃ (14.59%-15.26%), Na₂O+K₂O (5.34%-6.16%), TiO₂ (0.83%-0.97%), and P₂O₅ (0.15%-0.27%), with similar FeO/MgO (1.12-1.25) ratio. The Duobaoshan tonalite is characterized by depletions of Rb, Nb, and Sm, enrichments of Ba, U, Zr and Sr, and obvious positive Eu anomaly (δEu, 1.21-1.57). The Zhengguang diorite is characterized by depletion of Rb, Nb and Sm, enrichment of Ba, Th, Sr, Hf, and weak positive Eu anomaly (δEu, 0.93-1.22). Both tonalite and diorite are rich in light rare earth elements (LREE) and depleted in heavy rare earth elements (HREE), and have similar curve pattern on REE or trace element diagrams suggesting a common magmatic source. The magma probably derived from the partial melting of the mantle wedge metasomatized by the subduction fluid dehydrated from the downward moving Mongol-Okhotsk plate. The confirmation of the calc-alkaline magmatism in the Duobaoshan district indicates the subduction of the Mongol-Okhotsk oceanic plate can have remote influence, reaching as far as the eastern margin of the Xing’an Block. By compiling the metallogenic ages and background of the Late Triassic deposits in the study area, we can show that the Late Triassic magmatic activity in Duobaoshan area has great Ag-Cu-Mo mineralization ability and the study area has high exploration potential.

Key words: Duobaoshan area, Late Triassic, magmatism, mineraliation, Mongol-Okhotsk ocean

CLC Number:

LIU Baoshan, CHENG Zhaoxun, KOU Linlin, DENG Changzhou, YANG Xiaoping, ZHANG Chunpeng, LI Chenglu, HAN Renping. Late Triassic magmatic activity in Duobaoshan area, Heilongjiang Province: Response to the southward subduction of the Mongol-Okhotsk Ocean[J]. Earth Science Frontiers, 2022, 29(2): 132-145.

Figures/Tables 14

References 45

[1]	刘军, 武广, 钟伟, 等. 黑龙江省多宝山斑岩型铜(钼)矿床成矿流体特征及演化[J]. 岩石学报, 2010, 26(5):1450-1464.
[2]	王喜臣, 王训练, 王琳, 等. 黑龙江多宝山超大型斑岩铜矿的成矿作用和后期改造[J]. 地质科学, 2007, 42(1):124-133.
[3]	唐杰, 许文良, 王枫. 东北亚早中生代火成岩组合的时空变异:对古太平洋板块俯冲开始时间的制约[J]. 矿物岩石地球化学通报, 2016, 35(6):1181-1194, 1347.
[4]	郝宇杰. 黑龙江省多宝山矿集区成矿作用与成矿规律研究[D]. 长春: 吉林大学, 2015.
[5]	WANG L, QIN K Z, SONG G X, et al. Geology and genesis of the Early Paleozoic Zhengguang intermediate-sulfidation epithermal Au-Zn deposit, northeast China[J]. Ore Geology Reviews, 2020, 124:103602. DOI URL
[6]	ZHAO C, QIN K Z, SONG G X, et al. Switch of geodynamic setting from the Paleo-Asian Ocean to the Mongol-Okhotsk Ocean: evidence from granitoids in the Duobaoshan ore field, Heilongjiang Province, Northeast China[J]. Lithos, 2019, 336/337:202-220. DOI URL
[7]	葛文春, 吴福元, 周长勇, 等. 兴蒙造山带东段斑岩型Cu、 Mo矿床成矿时代及其地球动力学意义[J]. 科学通报, 2007, 52(20):2407-2417.
[8]	陈志广, 张连昌, 卢百志, 等. 内蒙古太平川铜钼矿成矿斑岩时代、地球化学及地质意义[J]. 岩石学报, 2010, 26(5):1437-1449.
[9]	阮诗昆. 黑龙江嫩江三矿沟—多宝山—争光成矿带地质特征与成矿规律[J]. 地质学刊, 2019, 43(1):50-56.
[10]	李成禄. 黑龙江省嫩江—黑河构造混杂岩带金矿成矿作用及找矿预测[M]. 北京: 地质出版社, 2018.
[11]	徐文喜, 李成禄, 鲍希波, 等. 大兴安岭东北部首个三叠纪银矿床地质特征及矿床成因分析[J]. 矿产与地质, 2019, 33(3):434-441.
[12]	LI C L, LI L, YUAN M W, et al. Study on pyrite thermoelectricity, ore-forming fluids and H-O-Rb-Sr isotopes of the Yongxin gold deposit, Central Asian Orogenic Belt: implications for ore genesis and exploration[J]. Ore Geology Reviews, 2020, 121:103568. DOI URL
[13]	石国明, 符安宗, 万太平. 一六九幅、多宝山铜矿幅,星火公社幅、一五三幅区域地质矿产调查报告[R]. 沈阳: 沈阳地质调查研究中心, 2018.
[14]	武广, 刘军, 钟伟, 等. 黑龙江省铜山斑岩铜矿床流体包裹体研究[J]. 岩石学报, 2009, 25(11):2995-3006.
[15]	LIU Y S, HU Z C, GAO S, et al. In-situ analysis of major and trace elements of anhydrous minerals by LA-ICP-MS without applying an internal standard[J]. Chemical Geology, 2008, 257(1/2):34-43. DOI URL
[16]	ZHOU K, CHEN Y X, ZHANG S B, et al. Zircon evidence for the Eoarchean (~3.7 Ga) crustal remnant in the Sulu Orogen, Eastern China[J]. Precambrian Research, 2020, 337:105529. DOI URL
[17]	吴荣新. 锆石阴极发光和U-Pb年龄特征研究[J]. 安徽理工大学学报(自然科学版), 2008, 28(4):1-7.
[18]	MANIAR P D, PICCOLI P M. Tectonic discrimination of granitoids[J]. Geological Society of America Bulletin, 1989, 101(5):635-643. DOI URL
[19]	PECCERILLO A, TAYLOR S R. Geochemistry of Eocene calc-alkaline volcanic rocks from the Kastamonu area, Northern Turkey[J]. Contributions to Mineralogy and Petrology, 1976, 58(1):63-81. DOI URL
[20]	IRVINE T N, BARAGAR W R A. A guide to the chemical classification of the common volcanic rocks[J]. Canadian Journal of Earth Sciences, 1971, 8(5):523-548. DOI URL
[21]	WHALEN J B, CURRIE K L, CHAPPELL B W. A-type granites: geochemical characteristics, discrimination and petrogenesis[J]. Contributions to Mineralogy and Petrology, 1987, 95(4):407-419. DOI URL
[22]	EBY G N. The A-type granitoids: a review of their occurrence and chemical characteristics and speculations on their petrogenesis[J]. Lithos, 1990, 26(1/2):115-134. DOI URL
[23]	侯增谦, 孟祥金, 曲晓明, 等. 西藏冈底斯斑岩铜矿带埃达克质斑岩含矿性:源岩相变及深部过程约束[J]. 矿床地质, 2005, 24(2):108-121.
[24]	李昌年. 火成岩微量元素岩石学[M]. 武汉: 中国地质大学出版社, 1992.
[25]	FITTON J G, JAMES D, LEEMAN W P. Basic magmatism associated with late Cenozoic extension in the western United States: compositional variations in space and time[J]. Journal of Geophysical Research: Solid Earth, 1991, 96(B8):13693-13711.
[26]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society of London, Special Publications, 1989, 42(1):313-345. DOI URL
[27]	WEAVER B L. The origin of ocean island basalt end-member compositions: trace element and isotopic constraints[J]. Earth and Planetary Science Letters, 1991, 104(2/3/4):381-397. DOI URL
[28]	TAYLOR S R, MCLENNAN S M. The geochemical evolution of the continental crust[J]. Reviews of Geophysics, 1995, 33(2):241-265. DOI URL
[29]	YAN J, CHEN J F, XU X S. Geochemistry of Cretaceous mafic rocks from the Lower Yangtze region, Eastern China: characteristics and evolution of the lithospheric mantle[J]. Journal of Asian Earth Sciences, 2008, 33(3/4):177-193. DOI URL
[30]	HOFFER G, EISSEN J P, BEATE B, et al. Geochemical and petrological constraints on rear-arc magma genesis processes in Ecuador: the Puyo cones and Mera lavas volcanic formations[J]. Journal of Volcanology and Geothermal Research, 2008, 176(1):107-118. DOI URL
[31]	CHEN B, JAHN B M, TIAN W. Evolution of the Solonker suture zone: constraints from zircon U-Pb ages,Hf isotopic ratios and whole-rock Nd-Sr isotope compositions of subduction-and collision-related magmas and forearc sediments[J]. Journal of Asian Earth Sciences, 2009, 34(3):245-257. DOI URL
[32]	刘永江, 张兴洲, 金巍, 等. 东北地区晚古生代区域构造演化[J]. 中国地质, 2010, 37(4):943-951.
[33]	WU F Y, YANG J H, LO C H. The Jiamusi Massif: a Jurassic accretionary terrane along the western Pacific margin of NE China[J]. Island Arc, 2007, 16:156-172. DOI URL
[34]	许文良, 王枫, 裴福萍, 等. 中国东北中生代构造体制与区域成矿背景: 来自中生代火山岩组合时空变化的制约[J]. 岩石学报, 2013, 29(2):339-353.
[35]	黄始琪, 董树文, 胡健民, 等. 蒙古—鄂霍次克构造带的形成与演化[J]. 地质学报, 2016, 90(9):2192-2205.
[36]	赵院冬, 车继英, 许逢明, 等. 兴安地块东北部晚侏罗世C型埃达克质花岗岩年代学、地球化学特征及构造环境意义[J]. 地学前缘, 2018, 25(6):240-253.
[37]	佘宏全, 李进文, 向安平, 等. 大兴安岭中北段原岩锆石U-Pb测年及其与区域构造演化关系[J]. 岩石学报, 2012, 28(2):571-594.
[38]	PITCHER W S. The nature and origin of granite[M]. London: Blackie Academic & Professional, 1993: 1-377.
[39]	ROTTURA A, BARGOSSI G M, CAGGIANELLI A, et al. Origin and significance of the Permian high-K calc-alkaline magmatism in the central-eastern Southern Alps, Italy[J]. Lithos, 1988, 45(1/2/3/4):329-348. DOI URL
[40]	蔡文艳. 黑龙江省多宝山矿集区铜-钼-金多金属成矿作用研究[D]. 长春: 吉林大学, 2020.
[41]	TANG J, XU W L, WANG F, et al. Geochronology and geochemistry of Early-Middle Triassic magmatism in the Erguna Massif, NE China: constraints on the tectonic evolution of the Mongol-Okhotsk Ocean[D]. Lithos, 2014,184/185/186/187:1-16.
[42]	WANG F, XU W L, XU Y G, et al. Late Triassic bimodal igneous rocks in eastern Heilongjiang Province, NE China: implications for the initiation of subduction of the Paleo-Pacific Plate beneath Eurasia[J]. Journal of Asian Earth Sciences, 2015, 97:406-423. DOI URL
[43]	刘宝山, 张春鹏, 宋万兵, 等. 黑龙江多宝山斑岩铜矿床叠加改造地质特征及成因[J]. 大地构造与成矿学, 2020, 44(6):1076-1095.
[44]	刘东园. 黑龙江省黑河市孟德河金矿黄铁矿标型特征及成矿预测[D]. 北京: 中国地质大学(北京), 2018.
[45]	CAI W Y, WANG K, LI J, et al. Geology,geochronology and geochemistry of large Duobaoshan Cu-Mo-Au orefield in NE China: magma genesis and regional tectonic implications[J]. Geoscience Frontiers, 2021, 12(1):265-292. DOI URL

岩石名称	分析点号	分析元素 w_B/10^-6		Th/U	同位素比值				表面年龄/Ma
岩石名称	分析点号	Th	U	Th/U	²⁰⁷Pb /²⁰⁶Pb	1σ	²⁰⁷Pb /²³⁵U	1σ	²⁰⁶Pb /²³⁸Pb	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
多宝山英云闪长岩 (DBS01)	DBS01-1	67.7	98.5	0.7	0.055 5	0.003 5	0.260 8	0.015 7	0.034 2	0.000 5	217.1	2.9	431.5	140.7
	DBS01-2	112	142	0.8	0.052 6	0.002 8	0.253 6	0.013 2	0.035 5	0.000 5	224.7	2.8	309.3	122.2
	DBS01-3	55.4	78.5	0.7	0.052 5	0.003 4	0.265 6	0.016 1	0.037 1	0.000 6	235.0	3.6	309.3	148.1
	DBS01-4	65.6	110	0.6	0.055 7	0.002 7	0.267 4	0.013 0	0.034 9	0.000 4	221.1	2.8	442.6	109.2
	DBS01-5	118	145	0.8	0.056 0	0.002 8	0.270 4	0.013 0	0.035 3	0.000 4	223.4	2.4	450.0	111.1
	DBS01-6	125	152	0.8	0.053 3	0.002 5	0.264 7	0.012 8	0.036 2	0.000 5	229.1	2.9	342.7	112.0
	DBS01-7	109	156	0.7	0.050 4	0.002 6	0.247 8	0.012 0	0.036 2	0.000 5	229.4	3.0	213.0	120.4
	DBS01-8	94.2	136	0.7	0.056 0	0.002 7	0.273 7	0.013 5	0.035 6	0.000 5	225.4	2.9	453.8	113.9
	DBS01-9	75.0	122	0.6	0.052 7	0.002 5	0.259 5	0.011 8	0.035 9	0.000 4	227.1	2.7	322.3	102.8
	DBS01-10	77.5	122	0.6	0.050 8	0.002 8	0.244 9	0.012 4	0.035 0	0.000 4	222.0	2.4	235.3	134.2
	DBS01-11	239	248	1.0	0.051 2	0.001 9	0.259 6	0.009 8	0.036 7	0.000 4	232.2	2.5	250.1	83.3
	DBS01-12	80.6	117	0.7	0.055 9	0.003 5	0.262 7	0.016 8	0.034 4	0.000 5	218.0	2.9	450.0	138.9
	DBS01-13	107	139	0.8	0.050 3	0.002 5	0.246 1	0.012 1	0.035 6	0.000 4	225.6	2.7	209.3	110.2
	DBS01-14	93.2	121	0.8	0.051 5	0.002 6	0.249 5	0.013 4	0.034 9	0.000 4	221.1	2.5	264.9	116.7
	DBS01-15	100.0	147	0.7	0.052 4	0.002 4	0.260 6	0.011 9	0.036 1	0.000 4	228.4	2.8	301.9	137.9
	DBS01-16	64.5	106	0.6	0.053 5	0.002 6	0.272 9	0.012 8	0.037 1	0.000 5	235.0	3.1	350.1	109.2
	DBS01-17	80.0	119	0.7	0.053 1	0.002 8	0.262 9	0.012 5	0.036 3	0.000 5	230.0	2.9	344.5	118.5
	DBS01-18	96.6	135	0.7	0.054 6	0.002 6	0.269 5	0.012 1	0.036 1	0.000 4	228.7	2.7	394.5	105.5
	DBS01-19	89.6	116	0.8	0.050 3	0.003 4	0.243 0	0.016 2	0.035 3	0.000 4	223.7	2.8	209.3	155.5
	DBS01-20	88.3	145	0.6	0.050 9	0.002 6	0.261 1	0.013 1	0.037 3	0.000 4	235.8	2.5	235.3	113.9
	DBS01-21	107	153	0.7	0.055 4	0.002 3	0.283 3	0.011 3	0.037 3	0.000 4	236.2	2.7	427.8	94.4
	DBS01-22	266	242	1.1	0.052 1	0.0022	0.249 4	0.010 0	0.034 9	0.000 3	220.9	2.1	287.1	99.1
	DBS01-23	128	149	0.9	0.055 0	0.002 4	0.263 9	0.011 8	0.034 9	0.000 4	221.2	2.6	409.3	98.1
	DBS01-24	50.1	89.3	0.6	0.051 3	0.003 3	0.252 6	0.015 5	0.035 7	0.000 5	226.1	3.0	253.8	151.8
	DBS01-25	74.5	139	0.5	0.050 3	0.002 6	0.249 4	0.012 5	0.036 4	0.000 5	230.5	3.1	209.3	122.2
争光闪长岩 (ZG01)	ZG01-01	1 289	902	1.4	0.056 9	0.002 0	0.299 0	0.010 3	0.038 1	0.000 4	241	2.737 28	487	79.622 5
	ZG01-02	1 921	1 010	1.9	0.050 7	0.001 5	0.251 5	0.007 5	0.035 9	0.000 3	227	2.164 81	233	70.357 5
	ZG01-03	1 962	1 019	1.9	0.051 8	0.001 5	0.255 9	0.007 4	0.035 8	0.000 4	227	2.340 53	276	68.51
	ZG01-04	767	758	1.0	0.050 8	0.001 6	0.265 7	0.008 9	0.037 8	0.000 5	239	3.020 16	232	67.58
	ZG01-05	2 070	1 045	2.0	0.051 9	0.001 6	0.256 8	0.007 8	0.035 8	0.000 4	227	2.284 59	283	68.51
	ZG01-06	1 774	939	1.9	0.050 9	0.001 8	0.249 0	0.008 7	0.035 5	0.000 4	225	2.428	239	81.467 5
	ZG01-07	1 904	1 114	1.7	0.050 7	0.001 6	0.244 8	0.007 7	0.035 1	0.000 4	222	2.294 65	233	74.062 5
	ZG01-08	1 712	935	1.8	0.050 7	0.001 6	0.247 8	0.007 7	0.035 4	0.000 4	224	2.193 36	228	72.21
	ZG01-09	2 254	1 263	1.8	0.050 3	0.001 3	0.262 0	0.007 3	0.037 6	0.000 5	238	2.828 32	209	93.505
	ZG01-10	2 673	1 278	2.1	0.054 2	0.001 6	0.282 0	0.008 3	0.037 5	0.000 4	237	2.463 02	389	60.18
	ZG01-11	2 246	1 120	2.0	0.053 3	0.001 7	0.263 3	0.008 6	0.035 6	0.000 4	225	2.405 73	343	39.81
	ZG01-12	1 915	965	2.0	0.053 6	0.001 8	0.265 6	0.009 1	0.035 7	0.000 4	226	2.553 19	367	75.92
	ZG01-13	1 002	741	1.4	0.046 5	0.004 3	0.231 8	0.026 0	0.034 3	0.000 5	218	2.908 19	33.4	198.12
	ZG01-14	1 810	972	1.9	0.052 1	0.001 7	0.269 1	0.008 5	0.037 3	0.000 5	236	2.81508	300	74.065
	ZG01-15	902	643	1.4	0.052 9	0.002 1	0.268 8	0.010 5	0.036 7	0.000 4	232	2.602 88	324	90.73
	ZG01-16	2 560	1 289	2.0	0.050 9	0.001 4	0.252 7	0.006 9	0.035 8	0.000 4	227	2.340 81	235	62.952 5
	ZG01-17	2 883	1 634	1.8	0.051 0	0.001 3	0.263 0	0.006 8	0.037 1	0.000 4	235	2.235 85	243	54.62
	ZG01-18	1 642	1 207	1.4	0.051 7	0.001 5	0.240 2	0.006 6	0.033 4	0.000 3	212	1.922 73	272	66.657 5
	ZG01-19	2 178	1 152	1.9	0.050 0	0.001 5	0.253 3	0.007 5	0.036 5	0.000 4	231	2.604 17	195	70.357 5

岩石名称	分析点号	分析元素 w_B/10^-6		Th/U	同位素比值				表面年龄/Ma
岩石名称	分析点号	Th	U	Th/U	²⁰⁷Pb /²⁰⁶Pb	1σ	²⁰⁷Pb /²³⁵U	1σ	²⁰⁶Pb /²³⁸Pb	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ
多宝山英云闪长岩 (DBS01)	DBS01-1	67.7	98.5	0.7	0.055 5	0.003 5	0.260 8	0.015 7	0.034 2	0.000 5	217.1	2.9	431.5	140.7
	DBS01-2	112	142	0.8	0.052 6	0.002 8	0.253 6	0.013 2	0.035 5	0.000 5	224.7	2.8	309.3	122.2
	DBS01-3	55.4	78.5	0.7	0.052 5	0.003 4	0.265 6	0.016 1	0.037 1	0.000 6	235.0	3.6	309.3	148.1
	DBS01-4	65.6	110	0.6	0.055 7	0.002 7	0.267 4	0.013 0	0.034 9	0.000 4	221.1	2.8	442.6	109.2
	DBS01-5	118	145	0.8	0.056 0	0.002 8	0.270 4	0.013 0	0.035 3	0.000 4	223.4	2.4	450.0	111.1
	DBS01-6	125	152	0.8	0.053 3	0.002 5	0.264 7	0.012 8	0.036 2	0.000 5	229.1	2.9	342.7	112.0
	DBS01-7	109	156	0.7	0.050 4	0.002 6	0.247 8	0.012 0	0.036 2	0.000 5	229.4	3.0	213.0	120.4
	DBS01-8	94.2	136	0.7	0.056 0	0.002 7	0.273 7	0.013 5	0.035 6	0.000 5	225.4	2.9	453.8	113.9
	DBS01-9	75.0	122	0.6	0.052 7	0.002 5	0.259 5	0.011 8	0.035 9	0.000 4	227.1	2.7	322.3	102.8
	DBS01-10	77.5	122	0.6	0.050 8	0.002 8	0.244 9	0.012 4	0.035 0	0.000 4	222.0	2.4	235.3	134.2
	DBS01-11	239	248	1.0	0.051 2	0.001 9	0.259 6	0.009 8	0.036 7	0.000 4	232.2	2.5	250.1	83.3
	DBS01-12	80.6	117	0.7	0.055 9	0.003 5	0.262 7	0.016 8	0.034 4	0.000 5	218.0	2.9	450.0	138.9
	DBS01-13	107	139	0.8	0.050 3	0.002 5	0.246 1	0.012 1	0.035 6	0.000 4	225.6	2.7	209.3	110.2
	DBS01-14	93.2	121	0.8	0.051 5	0.002 6	0.249 5	0.013 4	0.034 9	0.000 4	221.1	2.5	264.9	116.7
	DBS01-15	100.0	147	0.7	0.052 4	0.002 4	0.260 6	0.011 9	0.036 1	0.000 4	228.4	2.8	301.9	137.9
	DBS01-16	64.5	106	0.6	0.053 5	0.002 6	0.272 9	0.012 8	0.037 1	0.000 5	235.0	3.1	350.1	109.2
	DBS01-17	80.0	119	0.7	0.053 1	0.002 8	0.262 9	0.012 5	0.036 3	0.000 5	230.0	2.9	344.5	118.5
	DBS01-18	96.6	135	0.7	0.054 6	0.002 6	0.269 5	0.012 1	0.036 1	0.000 4	228.7	2.7	394.5	105.5
	DBS01-19	89.6	116	0.8	0.050 3	0.003 4	0.243 0	0.016 2	0.035 3	0.000 4	223.7	2.8	209.3	155.5
	DBS01-20	88.3	145	0.6	0.050 9	0.002 6	0.261 1	0.013 1	0.037 3	0.000 4	235.8	2.5	235.3	113.9
	DBS01-21	107	153	0.7	0.055 4	0.002 3	0.283 3	0.011 3	0.037 3	0.000 4	236.2	2.7	427.8	94.4
	DBS01-22	266	242	1.1	0.052 1	0.0022	0.249 4	0.010 0	0.034 9	0.000 3	220.9	2.1	287.1	99.1
	DBS01-23	128	149	0.9	0.055 0	0.002 4	0.263 9	0.011 8	0.034 9	0.000 4	221.2	2.6	409.3	98.1
	DBS01-24	50.1	89.3	0.6	0.051 3	0.003 3	0.252 6	0.015 5	0.035 7	0.000 5	226.1	3.0	253.8	151.8
	DBS01-25	74.5	139	0.5	0.050 3	0.002 6	0.249 4	0.012 5	0.036 4	0.000 5	230.5	3.1	209.3	122.2
争光闪长岩 (ZG01)	ZG01-01	1 289	902	1.4	0.056 9	0.002 0	0.299 0	0.010 3	0.038 1	0.000 4	241	2.737 28	487	79.622 5
	ZG01-02	1 921	1 010	1.9	0.050 7	0.001 5	0.251 5	0.007 5	0.035 9	0.000 3	227	2.164 81	233	70.357 5
	ZG01-03	1 962	1 019	1.9	0.051 8	0.001 5	0.255 9	0.007 4	0.035 8	0.000 4	227	2.340 53	276	68.51
	ZG01-04	767	758	1.0	0.050 8	0.001 6	0.265 7	0.008 9	0.037 8	0.000 5	239	3.020 16	232	67.58
	ZG01-05	2 070	1 045	2.0	0.051 9	0.001 6	0.256 8	0.007 8	0.035 8	0.000 4	227	2.284 59	283	68.51
	ZG01-06	1 774	939	1.9	0.050 9	0.001 8	0.249 0	0.008 7	0.035 5	0.000 4	225	2.428	239	81.467 5
	ZG01-07	1 904	1 114	1.7	0.050 7	0.001 6	0.244 8	0.007 7	0.035 1	0.000 4	222	2.294 65	233	74.062 5
	ZG01-08	1 712	935	1.8	0.050 7	0.001 6	0.247 8	0.007 7	0.035 4	0.000 4	224	2.193 36	228	72.21
	ZG01-09	2 254	1 263	1.8	0.050 3	0.001 3	0.262 0	0.007 3	0.037 6	0.000 5	238	2.828 32	209	93.505
	ZG01-10	2 673	1 278	2.1	0.054 2	0.001 6	0.282 0	0.008 3	0.037 5	0.000 4	237	2.463 02	389	60.18
	ZG01-11	2 246	1 120	2.0	0.053 3	0.001 7	0.263 3	0.008 6	0.035 6	0.000 4	225	2.405 73	343	39.81
	ZG01-12	1 915	965	2.0	0.053 6	0.001 8	0.265 6	0.009 1	0.035 7	0.000 4	226	2.553 19	367	75.92
	ZG01-13	1 002	741	1.4	0.046 5	0.004 3	0.231 8	0.026 0	0.034 3	0.000 5	218	2.908 19	33.4	198.12
	ZG01-14	1 810	972	1.9	0.052 1	0.001 7	0.269 1	0.008 5	0.037 3	0.000 5	236	2.81508	300	74.065
	ZG01-15	902	643	1.4	0.052 9	0.002 1	0.268 8	0.010 5	0.036 7	0.000 4	232	2.602 88	324	90.73
	ZG01-16	2 560	1 289	2.0	0.050 9	0.001 4	0.252 7	0.006 9	0.035 8	0.000 4	227	2.340 81	235	62.952 5
	ZG01-17	2 883	1 634	1.8	0.051 0	0.001 3	0.263 0	0.006 8	0.037 1	0.000 4	235	2.235 85	243	54.62
	ZG01-18	1 642	1 207	1.4	0.051 7	0.001 5	0.240 2	0.006 6	0.033 4	0.000 3	212	1.922 73	272	66.657 5
	ZG01-19	2 178	1 152	1.9	0.050 0	0.001 5	0.253 3	0.007 5	0.036 5	0.000 4	231	2.604 17	195	70.357 5
