Microvertebrate remains from the Kuanti Formation of the Liujiachong Section in Qujing, Yunnan and their stratigraphic significance

doi:10.13745/j.esf.sf.2020.6.7

Abstract

Abstract:

The Kuanti Formation, with the discovery of the Xiaoxiang Vertebate Fauna in 2007, has become the focus of global research on early vertebrates. However, its stratigraphic subdivision, correlation and age, especially the subdivision and age of its lower part, remain contentious, despite many biostratigraphic attempts made since 1914. In recent years, we conducted a series of extensive geological investigations in the Kuanti Formation near the Xiaoxiang Reservoir in Qujing, Yunnan Province. Based on the recently obtained data from the Liujiachong Section (dominated by the lower part of the Kuanti Formation) and the preliminary study of the newly discovered microvertebrate remains, we documented the sequence of the Kuanti Formation of the Liujiachong Section, and further explored the geological age of the related strata. The Kuanti Formation of the Liujiachong Section can be subdivided into three members, in ascending order according to the main lithological changes: Member Ⅰ (Yuejiashan Member), Member Ⅱ (Chongjiawan Member), and Member Ⅲ (Cailian Member). The lower part of Member Ⅰ is characterized by light yellow and yellow-green gravelly silty mudstones and calcareous siltstones lacking any fossils, while the upper part is composed of dark grey and grey-black carbonaceous shales with rare Lingula sp. and bivalves. Member Ⅱ is dominated by grey-green and purple-red shales, intercalated with light grey thin-bedded or lenticular limestones or bioclastic limestones containing many invertebrate fossils (brachiopods and crinoid stems) and abundant microvertebrate remains. Member Ⅲ, partially exposed in the section, is composed of purple-red and grey-green silty and calcareous mudstones or marls intercalating with minor purple-red or yellow-green shales or siltstones containing brachiopods, fish, and stout tubular trace fossils. A thin layer of medium-thick-bedded fine sandstone is developed on the bottom of the member, which marks the boundary between Members Ⅲ and Ⅱ. The microvertebrate remains from several beds in Member Ⅱ show high diversity, including four early vertebrate groups: agnathans, placoderms, acanthodians, and osteichthyans. They are characterized by the Yangtze Fish Assemblage of the Xiaoxiang Vertebrate Fauna. The discovery of the acanthodians Nostolepis spp. in this section reveals the stratigraphic correlation and the precise geological age of the lower part of the Kuanti Formation. Based on the acanthodians from Member Ⅱ, coupled with previous palaeontological data, we suggest the age of Member Ⅱ to be late Gorstian Stage of the Ludlow, in the Silurian. The upper part of Member I, containing the placoderm ‘Wangolepis’, might be referred to as early Gorstian. However, the age of the lower part of Member I without fossils is uncertain, and the possibility of its base extending down to the Wenlock is not excluded. This study offers new palaeoichthyological evidence for the Silurian biostratigraphy of China and provides a new chronostratigraphic scheme in the study of early vertebrate evolution.

Key words: microvertebrate remains, Kuanti Formation, Liujiachong Section, subdivision and correlation, Qujing, Yunnan

CLC Number:

P52
P534.4

WANG Jianhua, ZHAO Wenjin, ZHU Min, LI Qiang, CAI Jiachen, ZHANG Na, PENG Lijian, LUO Yanchao. Microvertebrate remains from the Kuanti Formation of the Liujiachong Section in Qujing, Yunnan and their stratigraphic significance[J]. Earth Science Frontiers, 2020, 27(6): 329-340.

Figures/Tables 5

Fig.1 Kuanti Formation of the Liujiachong Section in Qujing

Fig.2 Field photos of the Kuanti Formation of the Liujiachong Section in Qujing

Fig.3 Microvertebrate remains from the Kuanti Formation of the Liujiachong Section

Table 1 Evolution of the subdivision of Silurian strata in Qujing, Yunnan

Fig.4 Comprehensive histogram of Silurian strata in Qujing

References 62

[1]	TING V K, WANG Y L. Cambrian and Silurian formations of Malung and Chütsing districts, Yunnan[J]. Bulletin of the Geological Society of China, 1937, 16(1): 1-28.
[2]	SUN Y C, WANG H C. Silurian stratigraphy of the Malung and Kutsing districts, eastern Yunnan[J]. Bulletin of the Geological Society of China, 1946, 26(1): 83-100. DOI URL
[3]	ZHU M, ZHAO W J, JIA L T, et al. The oldest articulated osteichthyan reveals mosaic gnathostome characters[J]. Nature, 2009, 458(7237): 469-474. DOI URL
[4]	ZHU M, YU X B, AHLBERG P E, et al. A Silurian placoderm with osteichthyan-like marginal jaw bones[J]. Nature, 2013, 502(7470): 188-193. DOI URL
[5]	ZHU M, AHLBERG P E, PAN Z H, et al. A Silurian maxillate placoderm illuminates jaw evolution[J]. Science, 2016, 354(6310): 334-336. DOI URL
[6]	蔡家琛, 赵文金, 朱敏. 云南曲靖志留纪含鱼地层关底组的划分与时代[J]. 古脊椎动物学报, 2020, 58(4). DOI: 10.19615/j.cnki.1000-3118.200513 DOI
[7]	GAGNIER P Y, JAHNKE H, SHI Y. A fish fauna of the Lower Yulongsi Formation (Upper Silurian) of Qujing (E. Yunnan, S.W. China) and its depositional environment[J]. Courier Forschungs-Institut Senckenberg, 1989, 110: 123-135.
[8]	王念忠, 董致中. 中国志留纪鱼类微体化石的首次报道[J]. 古生物学报, 1989, 28(2): 192-206.
[9]	BURROW C J. Acanthodian dental elements from the Trundle beds (Lower Devonian) of New South Wales[J]. Records of the Western Australian Museum, 1995, 17(3): 331-341.
[10]	BURROW C J. Acanthodian fishes with dentigerous jaw bones: the Ischnacanthiformes and Acanthodopsis[J]. Fossils and Strata, 2004, 50: 8-22.
[11]	王念忠. 广西中部下泥盆统无颌类和鱼类微体化石[J]. 古生物学报, 1992, 31(3): 280-303.
[12]	BURROW C J. Form and function in scales of Ligulalepis toombsi Schultze, a palaeoniscoid from the Early Devonian of Australia[J]. Records of the South Australian Museum, 1994, 27(2): 175-185.
[13]	QU Q M, ZHU M, WANG W. Scales and dermal skeletal histology of an early bony fish Psarolepis romeri and their bearing on the evolution of rhombic scales and hard tissues[J]. PLoS One, 2013, 8(4): e61485. DOI URL
[14]	BURROW C J. Placoderm scales from the Lower Devonian of New South Wales, Australia[J]. Modern Geology, 1996, 20: 351-369.
[15]	BURROW C J. Devonian microvertebrates from Longmenshan, Sichuan, China: taxonomic assessment[J]. Courier Forschungs-Institut Senckenberg, 2000, 223: 391-451.
[16]	BURROW C J. Earliest Devonian gnathostome microremains from central New South Wales (Australia)[J]. Geodiversitas, 2003, 25(2): 273-288.
[17]	BURROW C J. Placoderm fauna from the Connemarra Formation (? late Lochkovian, Early Devonian), central New South Wales, Australia[J]. Alcheringa, 2006, 30(Special Issue 1): 59-88. DOI URL
[18]	GAI Z K, ZHU M, JIA L T, et al. A streamlined jawless fish (Galeaspida) from the Lower Devonian of Yunnan, China and its taxonomic and paleoecological implications[J]. Vertebrata Palasiatica, 2015, 53(2): 93-109.
[19]	林宝玉. 中国地层6, 中国的志留系[M]. 北京: 地质出版社, 1984.
[20]	方润森, 江能人, 范健才, 等. 云南曲靖地区中志留世—早泥盆世地层及古生物[M]. 昆明: 云南人民出版社, 1985.
[21]	云南省地质矿产局. 云南省区域地质志[M]. 北京: 地质出版社, 1990.
[22]	林宝玉, 黄枝高, 李明, 等. 中国志留系若干问题的探讨[M]. 北京: 科学出版社, 2017.
[23]	云南省地质局第二区域测量大队. 中华人民共和国1/20万曲靖幅区域地质调查报告(G-48-XX, 地质部分)[R]. 昆明: 云南省地质局, 1978.
[24]	丁春鸣. 滇东曲靖地区志留纪四射珊瑚的动物群特征及地层时代讨论[J]. 现代地质, 1988, 2(1): 20-33.
[25]	林宝玉, 苏养正, 朱秀芳, 等. 中国地层典志留系[M]. 北京: 地质出版社, 1998.
[26]	曹仁关. 云南曲靖志留系的划分和对比[J]. 地层学杂志, 1994, 18(2): 149-153.
[27]	黄冰, 戎嘉余, 王怿. 黔西赫章志留纪晚期小莱采贝动物群的发现及其古地理意义[J]. 古地理学报, 2011, 13(1): 31-37.
[28]	周航行, 黄冰. 云南曲靖志留系关底组腕足类无洞贝Atrypoidea foxi Jones居群分析[J]. 古生物学报, 2018, 57(1): 52-65.
[29]	戎嘉余, 王怿, 詹仁斌, 等. 中国志留纪综合地层和时间框架[J]. 中国科学: 地球科学, 2019, 49(1): 93-114.
[30]	WANG H C. The Silurian rugose corals of northern and eastern Yunnan[J]. Bulletin of the Geological Society of China, 1944, 24(1/2): 21-32. DOI URL
[31]	WANG H C. New material of Silurian rugose corals from Yunnan[J]. Bulletin of the Geological Society of China, 1947, 27(1): 171-192. DOI URL
[32]	陈均远, 刘耕武, 陈挺恩. 华中及西南地区志留纪鹦鹉螺动物群[J]. 中国科学院南京地质古生物研究所集刊, 1981, 13: 1-162.
[33]	潘江. 中国志留纪脊椎动物群的初步研究[J]. 中国地质科学院院报, 1986, 15: 161-190.
[34]	PAN J, DINELEY D L. A review of early (Silurian and Devonian) vertebrate biogeography and biostratigraphy of China[J]. Proceedings of the Royal Society of London Series B: Biological Sciences, 1988, 235(1278): 29-61.
[35]	王尚启, 刘正明, 李治本, 等. 云南曲靖晚志留世和早泥盆世介形类[J]. 微体古生物学报, 1992, 9(4): 363-389.
[36]	何心一, 陈建强. 滇东曲靖地区晚志留世四射珊瑚动物群[J]. 古生物学报, 2004, 43(3): 303-324.
[37]	伍鸿基. 西南地区志留—泥盆纪三叶虫的新属种及其地层意义[J]. 古生物学报, 1977, 16(1): 95-117.
[38]	戎嘉余, 杨学长. 西南地区志留系的石燕及其地层意义[J]. 古生物学报, 1978, 17(4): 357-386.
[39]	戎嘉余, 杨学长. 简论滇东的志留纪地层[J]. 地层学杂志, 1981, 5(1): 64-67.
[40]	葛治洲, 戎嘉余, 杨学长, 等. 西南地区的志留系[M]//中国科学院南京地质古生物研究所. 西南地区碳酸盐生物地层. 北京: 科学出版社, 1977: 155-220.
[41]	王成源. 云南曲靖上志留统牙形刺[J]. 古生物学报, 1980, 19(5): 369-378.
[42]	王成源. 华南志留系红层的时代[J]. 地层学杂志, 1998, 22(2): 127-128.
[43]	王成源. 云南曲靖地区关底组的时代[J]. 地层学杂志, 2001, 25(2): 125-127.
[44]	王成源. 中国志留纪牙形刺[M]. 合肥: 中国科学技术大学出版社, 2013.
[45]	WALLISER O H, WANG C Y. Upper Silurian stratigraphy and conodonts from the Qujing District, East Yunnan, China[J]. Courier Forschungs-Institut Senckenberg, 1989, 110: 111-121.
[46]	GENG L Y, QIAN Z S, DING L S, et al. Silurian chitinozoans from the Yangtze Region[J]. Palaeoworld, 1997(8): 1-152.
[47]	戎嘉余, 陈旭, 王成源, 等. 论华南志留系对比的若干问题[J]. 地层学杂志, 1990, 14(3): 161-177.
[48]	ZHAO W J, ZHU M. A review of Silurian fishes from Yunnan, China and related biostratigraphy[J]. Palaeoworld, 2015, 24(1/2): 243-250. DOI URL
[49]	赵文金, 朱敏. 中国志留纪鱼化石及含鱼地层对比研究综述[J]. 地学前缘, 2014, 21(2): 185-202.
[50]	ZHAO W J, ZHU M. Siluro-Devonian vertebrate biostratigraphy and biogeography of China[J]. Palaeoworld, 2010, 19(1/2): 4-26. DOI URL
[51]	WANG N Z. Thelodont, acanthodian, and chondrichthyan fossils from the Lower Devonian of southwest China[J]. Proceedings of the Linnean Society of New South Wales, 1984, 107(3): 419-441.
[52]	王念忠, 王俊卿, 张国瑞, 等. 西秦岭若尔盖、迭部志留纪和早泥盆世棘鱼类的首次报道: 西秦岭志留纪和泥盆纪脊椎动物研究之一[J]. 古脊椎动物学报, 1998, 36(4): 268-281.
[53]	王炜. 云南丽江早泥盆世棘鱼类微体化石的首次报道[J]. 古脊椎动物学报, 2003, 41(1): 1-16.
[54]	ZHAO W J, WANG N Z, ZHU M, et al. The microvertebrate remains and assemblage sequences across the Silurian-Devonian transition in West Qinling, China[J]. Vertebrata Palasiatica, 2012, 50(4): 309-321.
[55]	BURROW C J, YOUNG G C. The acanthodian fauna of the Craven Peaks Beds (Early to Middle Devonian), western Queensland[J]. Memoirs of the Queensland Museum, 2005, 51(1): 3-25.
[56]	BURROW C J, TURNER S, NOWLAN G S, et al. Vertebrate microremains from the Late Silurian of Arisaig, Nova Scotia, Canada[J]. Journal of Paleontology, 2013, 87(6): 1041-1059. DOI URL
[57]	BURROW C J, MURPHY M A. Early Devonian (Pragian) vertebrates from the northern Roberts Mountains, Nevada[J]. Journal of Paleontology, 2016, 90(4): 734-740. DOI URL
[58]	VALIUKEVIĊIUS J. New Silurian nostolepids (Acanthodii, Pisces) of Lithuania[J]. Geologija, 2003, 42: 51-68.
[59]	VALIUKEVIĊIUS J. New Wenlock-Pridoli (Silurian) acanthodian fishes from Lithuania[J]. Acta Palaeontologica Polonica, 2004, 49(1): 147-160.
[60]	VALIUKEVIĊIUS J. Silurian acanthodian succession of the Lūžņi-4 borehole (Latvia)[J]. Acta Universitatis Latviensis, 2004, 679: 119-147.
[61]	VALIUKEVIĊIUS J. Silurian acanthodian biostratigraphy of Lithuania[J]. Geodiversitas, 2005, 27(3): 349-380.
[62]	VIIRA V, ALDRIDGE R J. Upper Wenlock to Lower Pridoli (Silurian) conodont biostratigraphy of Saaremaa, Estonia, and a correlation with Britain[J]. Journal of Micropalaeontology, 1998, 17(1): 33-50. DOI URL
