Cause of helium-poor in Anyue gas field, Sichuan Basin

doi:10.13745/j.esf.sf.2024.11.9

Abstract

Abstract:

The Sichuan Basin serves as a crucial natural gas production base in China. Within the basin, the Weiyuan gas field exhibits a high helium concentration and represents the first natural gas field in China to achieve industrial helium utilization. Both the Anyue and Weiyuan gas fields are situated within the Leshan-Longnvsi paleo-uplift belt, but the helium content of the Anyue field is significantly lower than that of Weiyuan. To investigate the causes of helium deficiency in the Anyue gas field, this study systematically analyzes and compares the gas composition, nitrogen, and noble gas isotope characteristics of natural gas samples from both fields. The constraints on helium accumulation conditions in the Anyue field are also analyzed in conjunction with the regional geological background. The helium concentration in natural gas from the Anyue gas field ranges from 0.012% to 0.089%. Only 10% of the samples contain helium concentrations exceeding 0.05% (He>0.05%), and these are concentrated in the Deng-2 Member of the Sinian Dengying Formation at the western edge of the Gaoshiti block. The helium-containing and helium-poor samples exhibit distinct helium-nitrogen coupling enrichment trends and nitrogen isotope signatures. The former group resembles the characteristics observed in the Weiyuan gas field, suggesting a possible helium source from intermediate-acid metamorphic rocks. In contrast, the helium and nitrogen in the latter group may originate from the mud shales of the Qiongzhusi Formation. The availability of a helium source is identified as the primary factor constraining helium enrichment in the Anyue gas field. Additionally, the Anyue gas field possesses enormous natural gas reserves. The massive influx of hydrocarbon gases into the reservoir significantly dilutes the helium concentration. Noble gas isotope evidence further indicates that gas-water interaction within the Anyue field is considerably weaker than in the Weiyuan field. The combination of gentler structural traps and higher reservoir pressure restricts the exsolution and enrichment of helium via formation water. These two factors are also crucial reasons for the helium deficiency in the Anyue gas field.

Key words: helium, Anyue gas field, helium-poor cause, helium source, charging intensity, gas-water interaction, reservoir pressure

CLC Number:

P593

CHEN Gengrong, LI Jing, SUN Dong, ZHOU Shixin, LIU Liangliang, WANG Hao, PANG Wenjun, WU Yuhang. Cause of helium-poor in Anyue gas field, Sichuan Basin[J]. Earth Science Frontiers, 2025, 32(5): 278-289.

Figures/Tables 9

References 60

[1]	唐金荣, 张宇轩, 周俊林, 等. 全球氦气产业链分析与中国应对策略[J]. 地质通报, 2023, 42(1): 1-13.
[2]	ANDERSON S T. Economics, helium and the U.S. Federal helium reserve: summary and outlook[J]. Nature Resources Research, 2018, 27(4): 455-477.
[3]	USGS. Mineral commodity summaries 2022[R]. Reston: U.S. Geological Survey, 2022.
[4]	陶士振, 杨怡青, 陈悦, 等. 氦气资源地质形成条件、成因机理与富集规律[J]. 石油勘探与开发, 2024, 51(2): 436-452.
[5]	WEINLICH F H, BRÄUER K, KÄMPF H, et al. An active subcontinental mantle volatile system in the western Eger rift, Central Europe: gas flux, isotopic (He, C, and N) and compositional fingerprints[J]. Geochimica et Cosmochimica Acta, 1999, 63(21): 3653-3671.
[6]	LEE H, FISCHER T P, MUIRHEAD J D, et al. Incipient rifting accompanied by the release of subcontinental lithospheric mantle volatiles in the Magadi and Natron basin, East Africa[J]. Journal of Volcanology & Geothermal Research, 2017, 346: 118-133.
[7]	MAMYRIN B A, TOLSTIKHIN I N. Helium Isotopes in Nature[M]//Developments in Geochemistry 3. Amsterdam:Elsevier, 1986.
[8]	OXBURGH E R, O’NIONS R K, HILL R I. Helium isotopes in sedimentary basins[J]. Nature, 1986, 324(6098): 632-635.
[9]	BALLENTINE C J, BURNARD P G. Production, release and transport of noble gases in the continental crust[J]. Reviews in Mineralogy & Geochemistry, 2002, 47(1): 481-538.
[10]	BROWN A. Origin of helium and nitrogen in the Panhandle Hugoton Field of Texas, Oklahoma, and Kansas, United States[J]. AAPG Bulletin, 2019, 103(2): 369-403.
[11]	RAPATSKAYA L A, TONKIKH M E, USTYUZHANIN A O. Natural reservoir as a geological body for storing helium reserves[C]// IOP Conference Series: Earth and Environment Science. Bristol: IOP Publishing, 2020, 408(1): 012060.
[12]	彭威龙, 刘全有, 张英, 等. 中国首个特大致密砂岩型(烃类)富氦气田: 鄂尔多斯盆地东胜气田特征[J]. 中国科学:地球科学, 2022, 52(6): 1078-1085.
[13]	张宝收, 张本健, 汪华, 等. 四川盆地金秋气田:一个典型以中生界沉积岩为氦源岩的含氦-富氦气田[J]. 石油与天然气地质, 2024, 45(1): 185-199.
[14]	BROADHEAD R F. Helium in New Mexico-Geologic distribution, resource demand, and exploration possibilities[J]. New Mexico Geology, 2005, 27(4): 93-101.
[15]	QIN S F, YUAN M, ZHOU Z, et al. Distribution law of helium in Leshan-Longnvsi paleo-uplift in Sichuan Basin, China[C]// IOP Conference Series: Earth and Environmental Science. Bristol: IOP Publishing, 2019, 360: 012031.
[16]	何登发, 李德生, 张国伟, 等. 四川多旋回叠合盆地的形成与演化[J]. 地质科学, 2011, 46(3): 589-606.
[17]	魏国齐. 四川盆地构造特征与油气[M]. 北京: 科学出版社, 2019: 1283.
[18]	汪泽成, 王铜山, 文龙, 等. 四川盆地安岳特大型气田基本地质特征与形成条件[J]. 中国海上油气, 2016, 28(2): 45-52.
[19]	CHEN Z, YANG Y, WANG T G, et al. Dibenzothiophenes in solid bitumens: use of molecular markers to trace paleo-oil filling orientations in the Lower Cambrian reservoir of the Moxi-Gaoshiti Bulge, Sichuan Basin, southern China[J]. Organic Geochemistry, 2017, 108: 94-112.
[20]	魏国齐, 谢增业, 宋家荣, 等. 四川盆地川中古隆起震旦系—寒武系天然气特征及成因[J]. 石油勘探与开发, 2015, 42(6): 702-711.
[21]	YUAN H F, LIANG J J, GONG D Y, et al. Formation and evolution of Sinian oil and gas pools in typical structures, Sichuan Basin, China[J]. Petroleum Science, 2012, 9(2): 129-140.
[22]	CAO C H, ZHANG M, TANG Q, et al. Noble gas isotopic variations and geological implication of Longmaxi shale gas in Sichuan Basin, China[J]. Marine and Petroleum Geology, 2018, 89(10): 38-46.
[23]	刘强, 鲁雪松, 范俊佳, 等. 四川盆地震旦系气藏TSR证据及控制因素[J]. 天然气地球科学, 2022, 33(6): 929-943.
[24]	帅燕华, 张水昌, 胡国艺, 等. 四川盆地高石梯-磨溪地区震旦系—寒武系天然气TSR效应及气源启示[J]. 地质学报, 2019, 93(7): 1754-1766.
[25]	SANO Y, WAKITA H, SHENG X. Atmospheric helium isotope ratio[J]. Geochemical Journal, 2008, 22(4): 177.
[26]	CLARKE W B, JENKINS W J, TOP Z. Determination of tritium by mass spectrometric measurement of ³He[J]. International Journal of Applied Radiation & Isotopes, 1976, 27(9): 515-522.
[27]	张文. 关中和柴北缘地区战略性氦气资源成藏机理研究[D]. 北京: 中国矿业大学(北京), 2019.
[28]	BALLENTINE C J, LOLLAR B S. Regional groundwater focusing of nitrogen and noble gases into the Hugoton-Panhandle giant gas field,USA[J]. Geochimica et Cosmochimica Acta, 2002, 66(14): 2483-2497.
[29]	ZHANG W, LI Y H, ZHAO F H, et al. Using noble gases to trace groundwater evolution and assess helium accumulation in Weihe Basin, central China[J]. Geochimica et Cosmochimica Acta, 2019, 251: 229-246.
[30]	ZHANG W, LI Y H, ZHAO F H, et al. Quantifying the helium and hydrocarbon accumulation processes using noble gases in the North Qaidam Basin, China[J]. Chemical Geology, 2019, 525: 368-379.
[31]	LEE J Y, MARTI K, SEVERINGHAUS J P, et al. A redetermination of the isotopic abundances of atmospheric Ar[J]. Geochimica et Cosmochimica Acta, 2006, 70(17): 4507-4512.
[32]	李玉宏, 张文, 王利, 等. 壳源氦气成藏问题及成藏模式[J]. 西安科技大学学报, 2017, 37(4): 565-572.
[33]	DANABALAN D. Helium: exploration methodology for a strategic resource[D]. Durham: Durham University, 2017.
[34]	BROWN A. Formation of high Helium gases: a guide for explorationists[C]// AAPG Convention. New Orleans: AAPG, 2010: 1-14.
[35]	WANG X F, LIU W H, LI X F, et al. Radiogenic helium concentration and isotope variations in crustal gas pools from Sichuan Basin, China[J]. Applied Geochemistry, 2020, 117: 104586.
[36]	张晓宝, 周飞, 曹占元, 等. 柴达木盆地东坪氦工业气田发现及氦气来源和勘探前景[J]. 天然气地球科学, 2020, 31(11): 1585-1592.
[37]	CHENG A R, LOLLAR B S, GLUYAS, J G, et al. Primary N₂-He gas field formation in intracratonic sedimentary basins[J]. Nature, 2023, 615(7950): 94-99.
[38]	BARNARD P C, COOPER B S. A review of geochemical data related to the northwest European gas province[J]. Geological Society, London, Special Publications, 1983, 12(1): 19-33.
[39]	GERLING P, GELUK M C, KOCKEL F, et al. ‘NW European Gas Atlas’: new implications for the Carboniferous gas plays in the western part of the Southern Permian Basin[C]// Petroleum geology of north-west Europe:proceedings of the 5th conference. Bath: The Geological Society of London, 1999, 5(1): 799-808.
[40]	ZHU Y N, SHI B Q, FANG C B. The isotopic compositions of molecular nitrogen: implications on their origins in natural gas accumulations[J]. Chemical Geology, 2000, 164(3-4): 321-330.
[41]	刘全有, 刘文汇, KROOSS B M, 等. 天然气中氮的地球化学研究进展[J]. 天然气地球科学, 2006, 17(1): 119-124.
[42]	CARTIGNY P, MARTY B. Nitrogen isotopes and mantle geodynamics: the emergence of life and the atmosphere-crust-mantle connection[J]. Elements, 2013, 9(5): 359-366.
[43]	HALFORD D T, KAROLYTE R, BARRY P H, et al. High helium reservoirs in the four corners area of the Colorado Plateau, USA[J]. Chemical Geology, 2022, 596: 120790.
[44]	汪泽成, 赵文智, 李宗银, 等. 基底断裂在四川盆地须家河组天然气成藏中的作用[J]. 石油勘探与开发, 2008, 35(5): 541-547.
[45]	李玉宏, 张文, 王利, 等. 亨利定律与壳源氦气弱源成藏: 以渭河盆地为例[J]. 天然气地球科学, 2017, 28(4): 495-501.
[46]	秦胜飞, 李济远, 梁传国, 等. 中国中西部富氦气藏氦气富集机理: 古老地层水脱氦富集[J]. 天然气地球科学, 2022, 33(8): 1203-1217.
[47]	BARRY P H, LAWSON M, MEURER W P, et al. Noble gases solubility models of hydrocarbon charge mechanism in the Sleipner Vest gas field[J]. Geochimica et Cosmochimica Acta, 2016, 194: 291-309.
[48]	ZAIKOWSKI A, SPANGLER R R. Noble gas and methane partitioning from ground water: an aid to natural gas exploration and reservoir evaluation[J]. Geology, 1990, 18(1): 72-74.
[49]	BALLENTINE C J, BURGESS R, MARTY B. Tracing fluid origin, transport and interaction in the crust[J]. Reviews in Mineralogy & Geochemistry, 2002, 47(1): 539-614.
[50]	PRINZHOFER A. Noble gases in oil and gas accumulations[M]//BURNARD P. The noble gases as geochemical tracers. Berlin, Heidelberg: Springer, 2013: 235-257.
[51]	BARRY P H, LAWSON M, MEURER W P, et al. Determining fluid migration and isolation times in multiphase crustal domains using noble gases[J]. Geology, 2017, 45(9): 755-778.
[52]	BYRNE D J, BARRY P H, LAWSON M, et al. The use of noble gas isotopes to constrain subsurface fluid flow and hydrocarbon migration in the East Texas Basin[J]. Geochimica et Cosmochimica Acta, 2020, 268: 186-208.
[53]	SMITH S P, KENNEDY B M. The solubility of noble gases in water and in NaCl brine[J]. Geochimica et Cosmochimica Acta. 1983, 47(3): 503-515.
[54]	PODOSEK F A, BERNATOWICZ T J, KRAMER F E. Adsorption of xenon and krypton on shales[J]. Geochimica et Cosmochimica Acta, 1981, 45(12): 2401-2415.
[55]	MTILI K M, BYRNE D J, TYNE R L, et al. The origin of high helium concentrations in the gas fields of southwestern Tanzania[J]. Chemical Geology, 2021, 585: 120542. DOI: 10.1016/j.chemgeo.2021.120542.
[56]	DANABALAN D, GLUYAS J G, MACPHERSON C G, et al. The principles of helium exploration[J]. Petroleum Geoscience, 2022, 28(2): petgeo 2021-029.
[57]	梁霄, 刘树根, 夏铭, 等. 四川盆地威远构造震旦系灯影组气烟囱特征及其地质意义[J]. 石油与天然气地质, 2016, 37(5): 702-712.
[58]	陶小晚, 李建忠, 赵力彬, 等. 我国氦气资源现状及首个特大型富氦储量的发现:和田河气田[J]. 地球科学, 2019, 44(3): 1024-1041.
[59]	宋鸿彪, 罗志立. 盆地实例分析:四川盆地基底及深部地质结构研究的进展[J]. 地学前缘, 1995, 2(4): 231-237.
[60]	周稳生. 四川盆地重磁异常特征与深部结构[D]. 南京: 南京大学, 2016.

井位	产层	产层压力/ MPa	主要气体组分/%
井位	产层	产层压力/ MPa	CH₄	C₂H₆	C₃H₈	He	CO₂	N₂	H₂S
GS125	灯四段	57.09	90.39	0.04	0.01	0.026	6.45	2.32	0.22
GS018-2-H1	灯四段	—	92.08	0.05	0.00	0.023	6.41	1.07	0.03
GS018-4-H1	灯四段	56.57	91.57	0.05	0.00	0.025	6.59	1.39	0.09
GS103-C1	灯四段	38.82	92.87	0.05	0.01	0.020	5.53	1.13	0.32
GS001-H39	灯四段	56.70	93.16	0.06	0.01	0.017	5.32	0.75	0.58
GS001-X40	灯四段	55.50	91.49	0.04	0.00	0.017	6.22	1.08	0.66
GS3	灯四段	53.39	93.19	0.16	0.06	0.020	4.06	0.81	1.48
MX8	灯四段	56.77	95.90	0.32	0.10	0.013	2.04	0.73	0.34
MX019-H2	灯四段	56.99	92.35	0.07	0.02	0.022	4.96	0.84	1.20
MX022-H33	灯四段	56.44	93.21	0.04	0.00	0.020	5.01	1.62	0.08
MX118	灯四段	59.47	92.55	0.05	0.00	0.021	5.25	1.04	0.95
GS001-X41	灯四段	55.54	92.39	0.04	0.00	0.019	5.50	0.75	1.25
GS001-H26	灯四段	55.74	92.14	0.05	0.00	0.021	4.98	1.04	1.75
GS001-X22	灯四段	56.59	92.68	0.04	0.00	0.025	5.06	1.33	0.82
GS001-X25	灯四段	56.41	92.35	0.04	0.00	0.019	5.86	0.70	1.00
GS001-X29	灯四段	—	92.71	0.04	0.00	0.021	5.53	0.94	0.71
GS001-X3	灯四段	56.47	92.54	0.04	0.00	0.020	6.58	0.17	0.63
GS001-X35	灯四段	56.04	92.82	0.04	0.00	0.019	5.21	0.78	1.10
GS001-X36	灯四段	58.21	93.01	0.04	0.00	0.022	5.37	1.04	0.48
GS001-H15	灯四段	—	92.48	0.04	0.00	0.020	5.20	1.02	1.08
GS135	灯二段	52.95	93.03	0.14	0.04	0.021	4.98	0.77	0.86
GS131X	灯二段	57.18	92.59	0.04	0.00	0.040	5.21	1.55	0.51
GS009-H1	灯二段	56.45	92.32	0.20	0.06	0.036	5.21	1.10	0.54
GS009-H2	灯二段	56.70	92.67	0.12	0.04	0.061	4.87	1.83	0.12
GS009-H3	灯二段	53.20	92.66	0.04	0.00	0.054	4.83	1.98	0.26
GS009-H4	灯二段	57.02	91.50	0.04	0.00	0.057	5.47	2.04	0.46
PT1	灯二段	—	92.76	0.08	0.00	0.016	2.96	1.96	1.90
PT101	灯二段	—	93.86	0.08	0.00	0.016	2.35	1.51	2.06
PT102	灯二段	—	93.43	0.07	0.00	0.017	3.01	1.07	2.37
GS123	灯二段	—	88.56	0.03	0.00	0.089	5.36	4.20	1.67
MX124	灯二段	—	93.07	0.05	0.00	0.019	5.36	1.23	0.26
MX008-H22	龙王庙	75.90	96.27	0.14	0.00	0.012	1.74	1.53	0.30
MX008-H30	龙王庙	75.90	96.80	0.15	0.00	0.012	1.84	0.88	0.29
MX009-3-X1	龙王庙	75.90	96.78	0.15	0.00	0.013	1.87	0.79	0.39
MX009-3-X2	龙王庙	75.90	95.78	0.14	0.00	0.012	1.94	1.64	0.47
MX009-3-X3	龙王庙	75.90	92.87	0.14	0.01	0.014	3.30	3.21	0.42
MX16-C1	龙王庙	76.72	97.48	0.16	0.00	0.013	1.27	0.79	0.27
MX23-C1	龙王庙	78.17	95.72	0.13	0.00	0.014	1.99	1.37	0.76
GS102	龙王庙	68.59	90.74	0.06	0.00	0.019	2.51	1.04	3.74
GS6	龙王庙	68.30	90.49	0.07	0.00	0.021	3.31	1.63	4.45
W112	寒武系	—	88.54	0.09	0.00	0.177	4.16	6.50	0.43
W36-1	寒武系	—	88.77	0.10	0.00	0.172	4.14	6.34	0.37
W42	寒武系	—	86.97	0.08	0.00	0.172	4.35	7.66	0.64
W71	寒武系	—	89.51	0.11	0.00	0.175	3.29	6.66	0.08

井位	产层	产层压力/ MPa	主要气体组分/%
井位	产层	产层压力/ MPa	CH₄	C₂H₆	C₃H₈	He	CO₂	N₂	H₂S
GS125	灯四段	57.09	90.39	0.04	0.01	0.026	6.45	2.32	0.22
GS018-2-H1	灯四段	—	92.08	0.05	0.00	0.023	6.41	1.07	0.03
GS018-4-H1	灯四段	56.57	91.57	0.05	0.00	0.025	6.59	1.39	0.09
GS103-C1	灯四段	38.82	92.87	0.05	0.01	0.020	5.53	1.13	0.32
GS001-H39	灯四段	56.70	93.16	0.06	0.01	0.017	5.32	0.75	0.58
GS001-X40	灯四段	55.50	91.49	0.04	0.00	0.017	6.22	1.08	0.66
GS3	灯四段	53.39	93.19	0.16	0.06	0.020	4.06	0.81	1.48
MX8	灯四段	56.77	95.90	0.32	0.10	0.013	2.04	0.73	0.34
MX019-H2	灯四段	56.99	92.35	0.07	0.02	0.022	4.96	0.84	1.20
MX022-H33	灯四段	56.44	93.21	0.04	0.00	0.020	5.01	1.62	0.08
MX118	灯四段	59.47	92.55	0.05	0.00	0.021	5.25	1.04	0.95
GS001-X41	灯四段	55.54	92.39	0.04	0.00	0.019	5.50	0.75	1.25
GS001-H26	灯四段	55.74	92.14	0.05	0.00	0.021	4.98	1.04	1.75
GS001-X22	灯四段	56.59	92.68	0.04	0.00	0.025	5.06	1.33	0.82
GS001-X25	灯四段	56.41	92.35	0.04	0.00	0.019	5.86	0.70	1.00
GS001-X29	灯四段	—	92.71	0.04	0.00	0.021	5.53	0.94	0.71
GS001-X3	灯四段	56.47	92.54	0.04	0.00	0.020	6.58	0.17	0.63
GS001-X35	灯四段	56.04	92.82	0.04	0.00	0.019	5.21	0.78	1.10
GS001-X36	灯四段	58.21	93.01	0.04	0.00	0.022	5.37	1.04	0.48
GS001-H15	灯四段	—	92.48	0.04	0.00	0.020	5.20	1.02	1.08
GS135	灯二段	52.95	93.03	0.14	0.04	0.021	4.98	0.77	0.86
GS131X	灯二段	57.18	92.59	0.04	0.00	0.040	5.21	1.55	0.51
GS009-H1	灯二段	56.45	92.32	0.20	0.06	0.036	5.21	1.10	0.54
GS009-H2	灯二段	56.70	92.67	0.12	0.04	0.061	4.87	1.83	0.12
GS009-H3	灯二段	53.20	92.66	0.04	0.00	0.054	4.83	1.98	0.26
GS009-H4	灯二段	57.02	91.50	0.04	0.00	0.057	5.47	2.04	0.46
PT1	灯二段	—	92.76	0.08	0.00	0.016	2.96	1.96	1.90
PT101	灯二段	—	93.86	0.08	0.00	0.016	2.35	1.51	2.06
PT102	灯二段	—	93.43	0.07	0.00	0.017	3.01	1.07	2.37
GS123	灯二段	—	88.56	0.03	0.00	0.089	5.36	4.20	1.67
MX124	灯二段	—	93.07	0.05	0.00	0.019	5.36	1.23	0.26
MX008-H22	龙王庙	75.90	96.27	0.14	0.00	0.012	1.74	1.53	0.30
MX008-H30	龙王庙	75.90	96.80	0.15	0.00	0.012	1.84	0.88	0.29
MX009-3-X1	龙王庙	75.90	96.78	0.15	0.00	0.013	1.87	0.79	0.39
MX009-3-X2	龙王庙	75.90	95.78	0.14	0.00	0.012	1.94	1.64	0.47
MX009-3-X3	龙王庙	75.90	92.87	0.14	0.01	0.014	3.30	3.21	0.42
MX16-C1	龙王庙	76.72	97.48	0.16	0.00	0.013	1.27	0.79	0.27
MX23-C1	龙王庙	78.17	95.72	0.13	0.00	0.014	1.99	1.37	0.76
GS102	龙王庙	68.59	90.74	0.06	0.00	0.019	2.51	1.04	3.74
GS6	龙王庙	68.30	90.49	0.07	0.00	0.021	3.31	1.63	4.45
W112	寒武系	—	88.54	0.09	0.00	0.177	4.16	6.50	0.43
W36-1	寒武系	—	88.77	0.10	0.00	0.172	4.14	6.34	0.37
W42	寒武系	—	86.97	0.08	0.00	0.172	4.35	7.66	0.64
W71	寒武系	—	89.51	0.11	0.00	0.175	3.29	6.66	0.08

井位	(³He/⁴He)/10^-8	⁴He/²⁰Ne	⁴⁰Ar/³⁶Ar	³⁸Ar/³⁶Ar	R/Ra	V_g/V_w(³⁶Ar)	V_g/V_w(²⁰Ne)
MX022-H33	5.69	6 538	748.30	0.19	0.041	7.00	4.93
MX118	3.73	11 976	785.90	0.18	0.027	6.42	8.57
GS001-X41	5.57	4 408	946.57	0.19	0.040	7.60	3.79
GS001-H26	6.44	10 088	761.80	0.18	0.046	6.13	7.09
GS001-X22	4.42	6 092	1 019.30	0.20	0.032	8.47	3.63
GS001-X25	4.70	9 166	768.30	0.19	0.034	7.55	7.09
GS001-X29	5.10	7 575	636.30	0.19	0.036	4.65	5.28
GS001-X3	6.24	11 882	684.80	0.18	0.045	5.90	9.09
GS001-X35	7.74	8 748	699.80	0.19	0.055	3.84	6.79
GS001-X36	3.45	7 622	663.40	0.18	0.025	5.29	5.29
GS001-H15	6.54	13 471	642.60	0.19	0.047	4.64	10.33
GS131X	5.42	11 145	1 373.80	0.19	0.039	5.58	2.89
GS009-H1	2.82	13 937	1 807.20	0.19	0.020	11.00	4.70
GS009-H2	4.37	12 951	2 662.30	0.19	0.031	8.73	2.60
GS009-H3	4.50	9 207	996.30	0.20	0.032	3.60	1.72
GS009-H4	3.53	6 297	1 067.30	0.19	0.025	3.27	1.27
PT1	9.79	60 486	660.20	0.18	0.070	6.50	55.19
PT101	7.94	11 997	678.30	0.19	0.057	6.58	10.96
PT102	6.74	21 146	857.50	0.18	0.048	9.18	18.28
GS123	3.80	37 600	2 000.60	0.17	0.027	4.50	6.28
MX124	2.54	26 481	787.80	0.17	0.018	6.77	20.62
MX008-H22	2.40	3 580	521.50	0.19	0.017	5.12	4.28
MX008-H30	1.64	16 787	602.60	0.18	0.012	7.52	20.58
MX009-3-X1	1.39	5 908	462.80	0.19	0.010	3.82	6.81
MX009-3-X2	1.79	3 439	514.70	0.18	0.013	4.97	4.32
MX009-3-X3	1.73	16 428	690.20	0.18	0.012	8.62	18.14
MX16-C1	7.35	11 412	538.70	0.18	0.005	5.76	13.65
MX23-C1	1.24	17 030	954.30	0.18	0.009	13.58	18.16
GS102	2.01	11 753	613.90	0.19	0.014	4.29	9.10
GS6	2.50	8 433	778.20	0.18	0.018	6.28	6.07
W112	3.30	43 862	3 015.60	0.17	0.020	3.35	3.63
W36-1	2.74	32 420	2 532.00	0.17	0.022	2.35	2.53
W42	3.05	41 906	3 628.30	0.17	0.024	3.67	3.12
W71	3.01	15 121	2 013.20	0.18	0.022	4.68	1.23

井位	(³He/⁴He)/10^-8	⁴He/²⁰Ne	⁴⁰Ar/³⁶Ar	³⁸Ar/³⁶Ar	R/Ra	V_g/V_w(³⁶Ar)	V_g/V_w(²⁰Ne)
MX022-H33	5.69	6 538	748.30	0.19	0.041	7.00	4.93
MX118	3.73	11 976	785.90	0.18	0.027	6.42	8.57
GS001-X41	5.57	4 408	946.57	0.19	0.040	7.60	3.79
GS001-H26	6.44	10 088	761.80	0.18	0.046	6.13	7.09
GS001-X22	4.42	6 092	1 019.30	0.20	0.032	8.47	3.63
GS001-X25	4.70	9 166	768.30	0.19	0.034	7.55	7.09
GS001-X29	5.10	7 575	636.30	0.19	0.036	4.65	5.28
GS001-X3	6.24	11 882	684.80	0.18	0.045	5.90	9.09
GS001-X35	7.74	8 748	699.80	0.19	0.055	3.84	6.79
GS001-X36	3.45	7 622	663.40	0.18	0.025	5.29	5.29
GS001-H15	6.54	13 471	642.60	0.19	0.047	4.64	10.33
GS131X	5.42	11 145	1 373.80	0.19	0.039	5.58	2.89
GS009-H1	2.82	13 937	1 807.20	0.19	0.020	11.00	4.70
GS009-H2	4.37	12 951	2 662.30	0.19	0.031	8.73	2.60
GS009-H3	4.50	9 207	996.30	0.20	0.032	3.60	1.72
GS009-H4	3.53	6 297	1 067.30	0.19	0.025	3.27	1.27
PT1	9.79	60 486	660.20	0.18	0.070	6.50	55.19
PT101	7.94	11 997	678.30	0.19	0.057	6.58	10.96
PT102	6.74	21 146	857.50	0.18	0.048	9.18	18.28
GS123	3.80	37 600	2 000.60	0.17	0.027	4.50	6.28
MX124	2.54	26 481	787.80	0.17	0.018	6.77	20.62
MX008-H22	2.40	3 580	521.50	0.19	0.017	5.12	4.28
MX008-H30	1.64	16 787	602.60	0.18	0.012	7.52	20.58
MX009-3-X1	1.39	5 908	462.80	0.19	0.010	3.82	6.81
MX009-3-X2	1.79	3 439	514.70	0.18	0.013	4.97	4.32
MX009-3-X3	1.73	16 428	690.20	0.18	0.012	8.62	18.14
MX16-C1	7.35	11 412	538.70	0.18	0.005	5.76	13.65
MX23-C1	1.24	17 030	954.30	0.18	0.009	13.58	18.16
GS102	2.01	11 753	613.90	0.19	0.014	4.29	9.10
GS6	2.50	8 433	778.20	0.18	0.018	6.28	6.07
W112	3.30	43 862	3 015.60	0.17	0.020	3.35	3.63
W36-1	2.74	32 420	2 532.00	0.17	0.022	2.35	2.53
W42	3.05	41 906	3 628.30	0.17	0.024	3.67	3.12
W71	3.01	15 121	2 013.20	0.18	0.022	4.68	1.23
