湖南水口山铅锌多金属矿田成矿岩体花岗闪长岩锆石U-Pb年龄、Hf同位素及地质意义

doi:10.13745/j.esf.sf.2020.3.25

摘要/Abstract

摘要：

水口山铅锌多金属矿田是我国南岭地区重要的有色金属和贵金属生产基地之一。矿田内中酸性岩体发育,研究这些岩体的地质地球化学特征对理清区内成岩成矿演化谱系和指导找矿勘探均具有重要意义。该矿田内,老鸦巢4号和鸭公塘3号花岗闪长岩岩体的主微量元素组成相似,都具有高钾钙碱-钾玄及准铝质的特点。岩石微量元素配分呈平滑的右倾,轻稀土元素富集,重稀土元素分布平滑,具有弱的负铕异常。LA-ICP-MS锆石U-Pb定年表明,老鸦巢花岗闪长岩的年龄为(162.9±0.7) Ma,鸭公塘花岗闪长岩的年龄为(156.3±0.6) Ma。年龄结果表明水口山矿田花岗闪长岩岩体主要形成于燕山早期,经历了多期多阶段侵位过程。锆石原位Lu-Hf同位素分析结果显示,老鸦巢花岗闪长岩ε_Hf(t)值为-11.2~-8.24,二阶段模式年龄(T_DM2)为1 920~1 734 Ma;鸭公塘花岗闪长岩ε_Hf(t)值为-13.51~-6.23,二阶段模式年龄为2 063~1 601 Ma,显示鸭公塘岩体壳幔混合作用强于老鸦巢岩体。结合岩石地球化学特征及前人对矿田内仙人岩二长岩等岩体的研究结果,文章认为形成老鸦巢和鸭公塘岩体的岩浆主要起源于古老下地壳玄武岩-火成岩的部分熔融。该矿田在165~155 Ma处于中晚侏罗世地壳拉张减薄的构造背景中,岩浆岩锆石的ε_Hf(t)值急剧增加,幔源岩浆底侵作用增强。水口山铅锌多金属矿田与鸭公塘及仙人岩的岩体形成时代一致,三者具有成因联系,壳幔岩浆混合为成矿提供了大量金属物质,是区内形成众多铜铅锌金矿床的重要因素。

关键词: 水口山矿田, 花岗闪长岩, 锆石U-Pb定年, Hf同位素, 地质意义

Abstract:

The Shuikoushan Pb-Zn polymetallic ore-field is an important nonferrous and precious metal-producing area in Nanling, China. Many intermediate-acidic igneous rocks occur in this area, and studying their geological and geochemical characteristics is critical for clarifying their diagenetic magmatic-metallogenic evolution and guiding ore exploration. The Laoyachao No. 4 and Yagongtang No. 3 grano-diorites have similar major and trace elemental compositions and have metaluminous and high-K calc-alkaline characteristics of shoshonitic series. The rocks display generally flat, right-dipping rare earth element patterns with enriched light rare earth elements, relatively flat high rare earth element patterns, and slightly negative Eu anomalies. Zircon laser ablation inductively coupled plasma mass spectrometry U-Pb dating showed that the Laoyachao granodiorite formed at 162.9±0.7 Ma, and the Yagongtang granodiorite intruded at 156.3±0.6 Ma. This suggests that igneous rocks in the Shuikoushan ore field mainly formed during the early Yanshanian and underwent multiple emplacement stages. In situ Hf isotope analyses revealed ε_Hf(t) values ranging from -11.2 to -8.24 and two-stage Hf model ages (T_DM2) of 1920-1734 Ma for the Laoyachao granodiorite as well as ε_Hf(t) values of -13.51 to -6.23 and T_DM2 ages of 2063-1601 Ma for the Yagongtang granodiorite. This showed that more mantle material was added to the Yagongtang magma. Based on geochemical compositions and previous studies of the Xianrenyan monzonite in the study area, we argue that the Laoyachao and Yagongtang granodiorites were mainly derived from the partial melting of basaltic rocks in the Mesoproterozoic lower crust. From 165 to 155 Ma, the Shuikoushan ore field was in an extensional-thinning setting, and the ε_Hf(t) values of igneous rocks increased rapidly, indicating enhanced underplating of mantle magmas. Mineralization ages of the Shuikoushan Pb-Zn deposits were coeval with the formation of the Yagongtang and Xianrenyan plutons, indicating genetic relationships. Co-contribution of crustal and mantle ore-forming metals was critical to the formation of numerous Cu-Pb-Zn-Au deposits in the Shuikoushan area ore field.

Key words: Shuikoushan ore-field, granodiorite, zircon U-Pb geochronology, Hf isotope, geological significance

中图分类号:

李永胜, 甄世民, 于晓飞, 公凡影, 杜泽忠. 湖南水口山铅锌多金属矿田成矿岩体花岗闪长岩锆石U-Pb年龄、Hf同位素及地质意义[J]. 地学前缘, 2020, 27(2): 332-352.

LI Yongsheng, ZHEN Shimin, YU Xiaofei, GONG Fanying, DU Zezhong. Zircon U-Pb geochronology and Hf isotopic compositions of igneous rocks from the Shuikoushan Pb-Zn deposit, Hunan Province, and their geological significance[J]. Earth Science Frontiers, 2020, 27(2): 332-352.

图/表 15

参考文献 91

[1]	李仕能. 水口山矿田成因机制新探: 介绍水口山浅成低温热液金矿成矿模式[J]. 矿产与地质, 1988, 2(2): 16-19.
[2]	刘伟. 水口山Pb-Zn-Au矿田含矿流体的性质、来源及其环流历程[J]. 大地构造与成矿学, 1994, 18(3): 209-218.
[3]	刘顺生, 谭凯旋. 湖南水口山矿田开放体系构造成矿动力学[J]. 大地构造与成矿学, 1996, 20(1): 1-9.
[4]	张庆华. 湖南水口山铅锌矿田地质特征及找矿思路[J]. 有色金属矿产与勘查, 1999, 8(3): 141-146.
[5]	李永胜, 巩小栋, 祝新友, 等. 湖南水口山铅锌金银矿田典型矿床成因分析[J]. 矿床地质, 2014, 33(增刊1): 219-220.
[6]	周新鹏, 李倩, 王登红, 等. 南岭东段典型矿区岩浆岩物性特征研究[J]. 地学前缘, 2017, 24(5): 131-137.
[7]	周永章, 郑义, 曾长育, 等. 关于钦-杭成矿带的若干认识[J]. 地学前缘, 2015, 22(2): 1-6.
[8]	喻亨祥, 刘家远. 水口山矿田花岗质潜火山杂岩的成因特征[J]. 大地构造与成矿学, 1997, 21(1): 32-40.
[9]	王岳军, 范蔚茗, 郭锋, 等. 湘东南中生代花岗闪长岩锆石U-Pb法定年及其成因指示[J]. 中国科学:D辑, 2001, 31(9): 745-751.
[10]	马丽艳, 路远发, 梅玉萍, 等. 湖南水口山矿区花岗闪长岩中的锆石SHRIMP U-Pb定年及其地质意义[J]. 岩石学报, 2006, 22(10): 2475-2482.
[11]	左昌虎, 路睿, 赵增霞, 等. 湖南常宁水口山Pb-Zn矿区花岗闪长岩元素地球化学, LA-ICP-MS锆石U-Pb年龄和Hf同位素特征[J]. 地质论评, 2014, 60(4): 811-823.
[12]	甄世民, 祝新友, 李永胜, 等. 湖南仙人岩与金矿床有关的二长岩锆石U-Pb年龄、Hf同位素及地质意义[J]. 吉林大学学报(地球科学版), 2012, 42(6): 1740-1756.
[13]	毛景文, 陈懋弘, 袁顺达, 等. 华南地区钦杭成矿带地质特征和矿床时空分布规律[J]. 地质学报, 2011, 85(5): 636-658.
[14]	杨传益. 康家湾铅锌矿床的发现及成因[J]. 地质与勘探, 1985, 21(5): 1-7.
[15]	郑伟, 毛景文, 欧阳志侠, 等. 阳春盆地陂头面铜多金属矿床成岩成矿年代学、锆石微量元素及地质意义[J]. 岩石学报, 2018, 34(9): 2671-2686.
[16]	薛建玲, 宛克勇. 湖南水口山铅锌矿发现厚层铜硫矿体和铁铜矿体[J]. 中国地质调查成果快讯, 2015(7): 11-12.
[17]	LIU Y S, GAO S, KELEMEN P B, et al. Recycled crust controls contrasting source compositions of Mesozoic and Cenozoic basalts in the North China Craton[J]. Geochimica et Cosmochimica Acta, 2008, 72(9): 2349-2376. DOI URL
[18]	侯可军, 李延河, 田有荣. LA-MC-ICP-MS锆石微区原位U-Pb定年技术[J]. 矿床地质, 2009, 28(4): 481-492.
[19]	侯可军, 李延河, 邹天人, 等. LA-MC-ICP-MS锆石Hf同位素的分析方法及地质应用[J]. 岩石学报, 2007, 23(10): 2595-2604.
[20]	CHU N C, TAYLOR R N, CHAVAGNAC V R, et al. Hf isotope ratio analysis using multi-collector inductively coupled plasma mass spectrometry: an evaluation of isobaric interference corrections[J]. Journal of Analytical Atomic Spectrometry, 2002, 17(12): 1567-1574. DOI URL
[21]	ELHLOU S, BELOUSOVA E, GRIFFIN W L, et al. Trace element and isotopic composition of GJ-red zircon standard by laser ablation[J]. Geochimica et Cosmochimica Acta, 2006, 70(18): A158.
[22]	BELOUSOVA E, GRIFFIN W L, O’REILLY S Y, et al. Igneous zircon: trace element composition as an indicator of source rock type[J]. Contributions to Mineralogy and Petrology, 2002, 143(5): 602-622. DOI URL
[23]	WU Y B, ZHENG Y F. Genesis of zircon and its constraints on interpretation of U-Pb age[J]. Chinese Science Bulletin, 2004, 49(15): 1554-1569. DOI URL
[24]	MIDDLEMOST E A K. Naming materials in the magma/igneous rock system[J]. Earth-Science Reviews, 1994, 37(3/4): 215-224. DOI URL
[25]	PECCERILLO A, TAYLOR S R. Geochemistry of Eocene calc-alkaline volcanic rocks from the kastamonu area, Northern Turkey[J]. Contributions to Mineralogy and Petrology, 1976, 58(1): 63-81. DOI URL
[26]	MANIAR P D, PICCOLI P M. Tectonic discrimination of granitoids[J]. Geological Society of America Bulletin, 1989, 101(5): 635-643. DOI URL
[27]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society London Special Publications, 1989, 42(1): 313-345. DOI URL
[28]	BLICHERT-TOFT J, ALBARÈDE F. The Lu-Hf isotope geochemistry of chondrites and the evolution of the mantle-crust system[J]. Earth and Planetary Science Letters, 1997, 148(1/2): 243-258. DOI URL
[29]	GRIFFIN W L, PEARSON N J, BELOUSOVA E, et al. The Hf isotope composition of cratonic mantle: LAM-MC-ICPMS analysis of zircon megacrysts in kimberlites[J]. Geochimica et Cosmochimica Acta, 2000, 64(1): 133-147. DOI URL
[30]	SÖDERLUND U, PATCHETT P J, VERVOORT J D, et al. The ¹⁷⁶Lu decay constant determined by Lu-Hf and U-Pb isotope systematics of Precambrian mafic intrusions[J]. Earth and Planetary Science Letters, 2004, 219(3/4): 311-324. DOI URL
[31]	VERVOORT J D, JONATHAN PATCHETT P. Behavior of hafnium and neodymium isotopes in the crust: constraints from Precambrian crustally derived granites[J]. Geochimica et Cosmochimica Acta, 1996, 60(19): 3717-3733. DOI URL
[32]	HUANG J C, PENG J T, YANG J H, et al. Precise zircon U-Pb and molybdenite Re-Os dating of the Shuikoushan granodiorite-related Pb-Zn mineralization, southern Hunan, South China[J]. Ore Geology Reviews, 2015, 71: 305-317. DOI URL
[33]	YANG J H, PENG J T, ZHENG Y F, et al. Petrogenesis of the Mesozoic Shuikoushan peraluminous I-type granodioritic intrusion in Hunan Province, South China: middle-lower crustal reworking in an extensional tectonic setting[J]. Journal of Asian Earth Sciences, 2016, 123: 224-242. DOI URL
[34]	郭剑豪, 邹海洋. 鸭公塘铁铜矿床相关花岗闪长岩锆石U-Pb年龄、地球化学特征及地质意义[J]. 南方金属, 2019(4): 20-25.
[35]	陈志刚, 李献华, 李武显, 等. 赣南全南正长岩的SHRIMP锆石U-Pb年龄及其对华南燕山早期构造背景的制约[J]. 地球化学, 2003, 32(3): 223-229.
[36]	付建明, 马昌前, 谢才富, 等. 湖南骑田岭岩体东缘菜岭岩体的锆石SHRIMP定年及其意义[J]. 中国地质, 2004, 31(1): 96-100.
[37]	付建明, 马昌前, 谢才富, 等. 湘南西山铝质A型花岗质火山-侵入杂岩的地球化学及其形成环境[J]. 地球科学与环境学报, 2004, 26(4): 15-23.
[38]	朱金初, 黄革非, 张佩华, 等. 湘南骑田岭岩体菜岭超单元花岗岩侵位年龄和物质来源研究[J]. 地质论评, 2003, 49(3): 245-252.
[39]	李华芹, 路远发, 王登红, 等. 湖南骑田岭芙蓉矿田成岩成矿时代的厘定及其地质意义[J]. 地质论评, 2006, 52(1): 113-121.
[40]	赵葵东, 蒋少涌, 姜耀辉, 等. 湘南骑田岭岩体芙蓉超单元的锆石SHRIMP U-Pb年龄及其地质意义[J]. 岩石学报, 2006, 22(10): 2611-2616.
[41]	刘义茂, 戴橦谟, 卢焕章, 等. 千里山花岗岩成岩成矿的⁴⁰Ar-³⁹Ar和Sm-Nd同位素年龄[J]. 中国科学: D辑, 1997, 27(5): 425-430.
[42]	LI X H, CHUNG S L, ZHOU H W, et al. Jurassic intraplate magmatism in southern Hunan-eastern Guangxi: ⁴⁰Ar/³⁹Ar dating, geochemistry, Sr-Nd isotopes and implications for the tectonic evolution of SE China[J]. Geological Society of London, Special Publications, 2004, 226(1): 193-215. DOI URL
[43]	朱金初, 谢才富, 张佩华, 等. 桂东北牛庙闪长岩和同安石英二长岩:岩石学、锆石SHRIMP U-Pb年代学和地球化学[J]. 岩石学报, 2005, 21(3): 665-676.
[44]	徐夕生, 邓平, O’REILLY S Y, 等. 华南贵东杂岩体单颗粒锆石激光探针ICPMS U-Pb定年及其成岩意义[J]. 科学通报, 2003, 48(12): 1328-1334.
[45]	路远发, 马丽艳, 屈文俊, 等. 湖南宝山铜-钼多金属矿床成岩成矿的U-Pb和Re-Os同位素定年研究[J]. 岩石学报, 2006, 22(10): 2483-2492.
[46]	姚军明, 华仁民, 林锦富. 湘东南黄沙坪花岗岩LA-ICPMS锆石U-Pb定年及岩石地球化学特征[J]. 岩石学报, 2005, 21(3): 688-696.
[47]	付建明, 马昌前, 谢才富, 等. 湖南九嶷山复式花岗岩体SHRIMP锆石定年及其地质意义[J]. 大地构造与成矿学, 2004, 28(4): 370-378.
[48]	章荣清, 陆建军, 朱金初, 等. 湘南荷花坪花岗斑岩锆石LA-MC-ICP-MS U-Pb年龄、Hf同位素制约及地质意义[J]. 高校地质学报, 2010, 16(4): 436-447.
[49]	KEMP A I S, HAWKESWORTH C J, FOSTER G L, et al. Magmatic and crustal differentiation history of granitic rocks from Hf-O isotopes in zircon[J]. Science, 2007, 315: 980-983. DOI URL
[50]	XIA Y, XU X S, ZOU H B, et al. Early Paleozoic crust-mantle interaction and lithosphere delamination in South China Block: evidence from geochronology, geochemistry, and Sr-Nd-Hf isotopes of granites[J]. Lithos, 2014, 184/185/186/187: 416-435.
[51]	GRAY C M. An isotopic mixing model for the origin of granitic rocks in southeastern Australia[J]. Earth and Planetary Science Letters, 1984, 70(1): 47-60. DOI URL
[52]	COLLINS W J. S- and I-type granitoids of the eastern La-chlan fold belt: products of three-component mixing[J]. Transactions of the Royal Society of Edinburgh, Earth Sciences, 1996, 88: 171-179.
[53]	WEYER S, MÜNKER C, MEZGER K. Nb/Ta, Zr/Hf and REE in the depleted mantle: implications for the differentiation history of the crust-mantle system[J]. Earth and Planetary Science Letters, 2003, 205(3/4): 309-324. DOI URL
[54]	赵振华, 熊小林, 王强, 等. 铌与钽的某些地球化学问题[J]. 地球化学, 2008, 37(4): 304-320.
[55]	BARTH M G, MCDONOUGH W F, RUDNICK R L. Tracking the budget of Nb and Ta in the continental crust[J]. Chemical Geology, 2000, 165(3/4): 197-213. DOI URL
[56]	BEARD J S, LOFGREN G E. Dehydration melting and water-saturated melting of basaltic and andesitic greenstones and amphibolites at 1, 3, and 6.9 kbar[J]. Journal of Petrology, 1991, 32(2): 365-401. DOI URL
[57]	RAPP R P. Amphibole-out phase boundary in partially melted metabasalt, its control over liquid fraction and composition, and source permeability[J]. Journal of Geophysical Research: Solid Earth, 1995, 100(B8): 15601-15610.
[58]	JOHANNES W, HOLTZ F. Petrogenesis and experimental petrology of granitic rocks[M]. Berlin, Heidelberg: Springer, 1996.
[59]	SISSON T W, RATAJESKI K, HANKINS W B, et al. Voluminous granitic magmas from common basaltic sources[J]. Contributions to Mineralogy and Petrology, 2005, 148(6): 635-661. DOI URL
[60]	DOUCE A E P, MCCARTHY T C. Melting of crustal rocks during continental collision and subduction[M]// HACKER B R, LIOU J G. When continents collide: geodynamics and geochemistry of ultrahigh-pressure rocks. Dordrecht: Springer Netherlands, 1998: 27-55.
[61]	PATIÑO DOUCE A E. What do experiments tell us about the relative contributions of crust and mantle to the origin of granitic magmas?[J]. Geological Society of London, Special Publications, 1999, 168(1): 55-75. DOI URL
[62]	STERN C R, KILIAN R. Role of the subducted slab, mantle wedge and continental crust in the generation of Adakites from the Andean Austral volcanic zone[J]. Contributions to Mineralogy and Petrology, 1996, 123(3): 263-281. DOI URL
[63]	ALTHERR R, SIEBEL W. I-type plutonism in a continental back-arc setting: Miocene granitoids and monzonites from the central Aegean Sea, Greece[J]. Contributions to Mineralogy and Petrology, 2002, 143(4): 397-415. DOI URL
[64]	周新民. 对华南花岗岩研究的若干思考[J]. 高校地质学报, 2003, 9(4): 556-565.
[65]	李兴远, 周永章, 安燕飞, 等. 钦-杭成矿带南段丰村铅锌矿区下园垌矿段围岩微量元素的地球化学特征及其意义[J]. 地学前缘, 2015, 22(2): 131-143.
[66]	徐德明, 蔺志永, 骆学全, 等. 钦-杭成矿带主要金属矿床成矿系列[J]. 地学前缘, 2015, 22(2): 7-24.
[67]	王少轶, 赵正, 方贵聪, 等. 赣南樟(东坑)—九(龙脑)钨多金属矿床矿物学、年代学特征及其地质意义[J]. 地学前缘, 2017, 24(5): 120-130.
[68]	许德如, 邓腾, 董国军, 等. 湘东北连云山二云母二长花岗岩的年代学和地球化学特征:对岩浆成因和成矿地球动力学背景的启示[J]. 地学前缘, 2017, 24(2): 104-122.
[69]	余盼, 郑义, 王岳军, 等. 湖南新宁星子岩锑矿流体包裹体特征及矿床成因[J]. 地学前缘, 2018, 25(5): 266-276.
[70]	ZHOU X M, LI W X. Origin of Late Mesozoic igneous rocks in Southeastern China: implications for lithosphere subduction and underplating of mafic magmas[J]. Tectonophysics, 2000, 326(3/4): 269-287. DOI URL
[71]	LI Z X, LI X H, CHUNG S L, et al. Magmatic switch-on and switch-off along the South China continental margin since the Permian: transition from an Andean-type to a Western Pacific-type plate boundary[J]. Tectonophysics, 2012, 532/533/534/535: 271-290.
[72]	王强, 赵振华, 简平, 等. 德兴花岗闪长斑岩SHRIMP锆石U-Pb年代学和Nd-Sr同位素地球化学[J]. 岩石学报, 2004, 20(2): 315-324.
[73]	董树文, 吴锡浩, 吴珍汉, 等. 论东亚大陆的构造翘变: 燕山运动的全球意义[J]. 地质论评, 2000, 46(1): 8-13.
[74]	周新民. 南岭地区晚中生代花岗岩成因与岩石圈动力学演化[M]. 北京: 科学出版社, 2007.
[75]	李晓峰, WATANABE Y, 华仁民, 等. 华南地区中生代Cu-(Mo)-W-Sn矿床成矿作用与洋岭/转换断层俯冲[J]. 地质学报, 2008, 82(5): 625-640.
[76]	华仁民, 陈培荣, 张文兰, 等. 论华南地区中生代3次大规模成矿作用[J]. 矿床地质, 2005, 24(2): 99-107.
[77]	毛景文, 谢桂青, 郭春丽, 等. 华南地区中生代主要金属矿床时空分布规律和成矿环境[J]. 高校地质学报, 2008, 14(4): 510-526.
[78]	YAO J M, HUA R M, QU W J, et al. Re-Os isotope dating of molybdenites in the Huangshaping Pb-Zn-W-Mo polymetallic deposit, Hunan Province, South China and its geological significance[J]. Science in China Series D: Earth Sciences, 2007, 50(4): 519-526.
[79]	马丽艳, 路远发, 屈文俊, 等. 湖南黄沙坪铅锌多金属矿床的Re-Os同位素等时线年龄及其地质意义[J]. 矿床地质, 2007, 26(4): 425-431.
[80]	雷泽恒, 陈富文, 陈郑辉, 等. 黄沙坪铅锌多金属矿成岩成矿年龄测定及地质意义[J]. 地球学报, 2010, 31(4): 532-540.
[81]	YANG J H, KANG L F, PENG J T, et al. In-situ elemental and isotopic compositions of apatite and zircon from the Shuikoushan and Xihuashan granitic plutons: implication for Jurassic granitoid-related Cu-Pb-Zn and W mineralization in the Nanling Range, South China[J]. Ore Geology Reviews, 2018, 93: 382-403. DOI URL
[82]	卢友月, 付建明, 程顺波, 等. 湘南铜山岭铜多金属矿田成岩成矿作用年代学研究[J]. 大地构造与成矿学, 2015, 39(6): 1061-1071.
[83]	ZHAO P L, YUAN S D, MAO J W, et al. Geochronological and petrogeochemical constraints on the skarn deposits in Tongshanling ore district, southern Hunan Province: implications for Jurassic Cu and W metallogenic events in South China[J]. Ore Geology Reviews, 2016, 78: 120-137. DOI URL
[84]	叶天竺, 吕志成, 庞振山, 等. 勘查区找矿预测理论与方法(总论)[M]. 北京: 地质出版社, 2014.
[85]	CATHLES L M, ERENDI A H J, BARRIE T. How long can a hydrothermal system be sustained by a single intrusive event?[J]. Economic Geology, 1997, 92(7/8): 766-771. DOI URL
[86]	杜保峰, 魏俊浩, 王启, 等. 中国东部钼矿成矿背景与成岩-成矿时差讨论[J]. 矿床地质, 2010, 29(6): 935-955.
[87]	MAO J W, ZHANG Z C, ZHANG Z H, et al. Re-Os isotopic dating of molybdenites in the Xiaoliugou W(Mo)deposit in the northern Qilian Mountains and its geological significance[J]. Geochimica et Cosmochimica Acta, 1999, 63(11/12): 1815-1818. DOI URL
[88]	STEIN H J, MARKEY R J, MORGAN J W, et al. The remarkable Re-Os chronometer in molybdenite: how and why it works[J]. Terra Nova, 2001, 13(6): 479-486. DOI URL
[89]	JENNER F E. Cumulate causes for the low contents of sulfide-loving elements in the continental crust[J]. Nature Geoscience, 2017, 10(7): 524-529. DOI URL
[90]	CHERNIAK D J. Diffusion in carbonates, fluorite, sulfide minerals, and diamond[J]. Reviews in Mineralogy and Geochemistry, 2010, 72(1): 871-897. DOI URL
[91]	HOU Z Q, ZHOU Y, WANG R, et al. Recycling of metal-fertilized lower continental crust: origin of non-arc Au-rich porphyry deposits at cratonic edges[J]. Geology, 2017, 45(6): 563-566. DOI URL

测点编号	元素含量/10^-6			同位素比值							年龄/Ma
测点编号	²⁰⁶Pb	²³²Th	²³⁸U	²³²Th/²³⁸U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
SKC-5-1	5.63	120.87	231.98	0.52	0.047 1	0.00	0.172 5	0.00	0.025 4	0.00	52.0	13.0	162.0	2.0	162.0	1.0
SKC-5-2	4.73	93.88	190.15	0.49	0.046 9	0.00	0.174 3	0.00	0.025 8	0.00	44.0	14.0	163.0	2.0	164.2	1.0
SKC-5-3	6.53	98.23	265.51	0.37	0.047 6	0.00	0.173 5	0.00	0.025 3	0.00	77.0	12.0	162.0	1.0	161.2	0.9
SKC-5-4	3.71	84.78	150.46	0.56	0.047 0	0.00	0.172 4	0.00	0.025 5	0.00	50.0	14.0	162.0	2.0	162.0	1.0
SKC-5-6	5.03	106.68	205.31	0.52	0.046 9	0.00	0.170 5	0.00	0.025 2	0.00	46.0	12.0	160.0	1.0	160.5	1.0
SKC-5-7	5.14	93.99	207.28	0.45	0.047 1	0.00	0.172 8	0.00	0.025 5	0.00	56.0	12.0	162.0	2.0	162.0	1.0
SKC-5-8	3.59	70.20	145.59	0.48	0.049 2	0.00	0.180 3	0.00	0.025 4	0.00	157.0	21.0	168.0	2.0	162.0	1.0
SKC-5-9	8.05	132.21	325.67	0.41	0.048 0	0.00	0.175 5	0.00	0.025 4	0.00	100.0	14.0	164.0	2.0	162.0	1.0
SKC-5-10	4.84	127.53	200.27	0.64	0.049 5	0.00	0.181 2	0.00	0.025 4	0.00	171.0	16.0	169.0	2.0	162.0	2.0
SKC-5-11	6.80	139.53	273.60	0.51	0.047 9	0.00	0.172 9	0.00	0.025 8	0.00	93.0	12.0	162.0	2.0	164.0	2.0
SKC-5-12	5.56	117.00	224.15	0.52	0.047 1	0.00	0.169 3	0.00	0.025 7	0.00	56.0	15.0	159.0	2.0	163.0	1.0
SKC-5-13	6.68	183.19	269.70	0.68	0.048 0	0.00	0.174 6	0.00	0.026 0	0.00	98.0	15.0	163.0	2.0	165.0	2.0
SKC-5-14	7.30	198.29	295.68	0.67	0.049 3	0.00	0.176 0	0.00	0.025 5	0.00	161.0	12.0	165.0	2.0	163.0	1.0
SKC-5-15	7.04	166.20	280.12	0.59	0.048 2	0.00	0.175 4	0.00	0.026 0	0.00	110.0	12.0	164.0	2.0	165.0	1.0
SKC-5-16	6.36	140.55	253.76	0.55	0.047 7	0.00	0.173 0	0.00	0.026 0	0.00	82.0	12.0	162.0	2.0	165.0	1.0
SKC-5-17	6.11	137.03	248.71	0.55	0.047 7	0.00	0.171 1	0.00	0.025 6	0.00	86.0	11.0	160.0	1.0	163.0	1.0
SKC-5-18	8.64	168.49	347.55	0.48	0.047 4	0.00	0.169 9	0.00	0.025 6	0.00	69.0	11.0	159.0	1.0	163.0	1.0
SKC-5-19	5.98	158.51	237.47	0.67	0.047 3	0.00	0.171 6	0.00	0.025 9	0.00	65.0	14.0	161.0	2.0	165.0	1.0
SKC-4-1	8.26	362.00	346.85	1.04	0.047 7	0.00	0.173 5	0.00	0.024 9	0.00	84.0	10.0	162.0	1.0	158.5	1.0
SKC-4-2	6.45	181.83	280.59	0.65	0.047 9	0.00	0.169 7	0.00	0.024 2	0.00	93.0	11.0	159.0	1.0	154.4	0.9
SKC-4-3	6.05	137.12	258.10	0.53	0.046 7	0.00	0.169 6	0.00	0.024 8	0.00	36.0	10.0	159.0	1.0	158.0	1.0
SKC-4-4	4.89	146.97	208.03	0.71	0.047 9	0.00	0.173 7	0.00	0.024 7	0.00	93.0	24.0	163.0	2.0	158.0	1.0
SKC-4-5	6.66	111.07	283.48	0.39	0.047 0	0.00	0.170 2	0.00	0.024 7	0.00	51.0	12.0	160.0	2.0	158.0	1.0
SKC-4-6	4.57	126.63	195.96	0.65	0.047 4	0.00	0.170 3	0.00	0.024 6	0.00	72.0	13.0	160.0	2.0	156.0	1.0
SKC-4-7	4.09	93.62	175.43	0.53	0.046 7	0.00	0.168 7	0.00	0.024 7	0.00	32.0	13.0	158.0	2.0	157.0	1.0
SKC-4-8	7.54	137.37	327.21	0.42	0.047 7	0.00	0.169 7	0.00	0.024 4	0.00	84.0	9.0	159.0	1.0	155.0	1.0
SKC-4-9	3.48	85.91	150.59	0.57	0.047 3	0.00	0.169 6	0.00	0.024 6	0.00	62.0	14.0	159.0	2.0	156.0	1.0
SKC-4-10	6.25	121.29	271.77	0.45	0.047 7	0.00	0.169 2	0.00	0.024 7	0.00	86.0	13.0	159.0	1.0	157.5	1.0
SKC-4-11	7.67	183.40	327.68	0.56	0.047 5	0.00	0.177 0	0.00	0.024 8	0.00	73.0	9.0	166.0	1.0	158.0	1.0
SKC-4-12	5.05	80.55	213.60	0.38	0.047 0	0.00	0.175 0	0.00	0.024 7	0.00	51.0	11.0	164.0	1.0	157.4	1.0
SKC-4-13	4.91	84.25	209.23	0.40	0.047 5	0.00	0.177 8	0.00	0.024 9	0.00	74.0	11.0	166.0	1.0	158.0	1.0
测点编号	元素含量/10^-6			同位素比值							年龄/Ma
测点编号	²⁰⁶Pb	²³²Th	²³⁸U	²³²Th/²³⁸U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
SKC-4-14	9.18	239.73	397.65	0.60	0.047 3	0.00	0.173 1	0.00	0.024 3	0.00	65.0	9.0	162.0	1.0	155.0	1.0
SKC-4-15	5.18	93.07	224.58	0.41	0.048 5	0.00	0.182 9	0.01	0.024 6	0.00	126.0	98.0	171.0	8.0	157.0	1.0
SKC-4-16	3.66	91.03	158.86	0.57	0.047 4	0.00	0.171 7	0.00	0.024 1	0.00	70.0	12.0	161.0	1.0	153.4	0.9
SKC-4-17	5.50	149.79	240.87	0.62	0.047 2	0.00	0.171 0	0.00	0.024 1	0.00	59.0	11.0	160.0	1.0	153.3	0.9
SKC-4-20	4.94	127.20	207.89	0.61	0.047 6	0.00	0.178 5	0.00	0.024 9	0.00	81.0	11.0	167.0	2.0	159.0	1.0
SKC-4-21	5.71	178.30	244.08	0.73	0.047 1	0.00	0.169 0	0.00	0.024 6	0.00	52.0	10.0	159.0	1.0	156.5	0.9
SKC-4-22	3.64	104.32	156.36	0.67	0.046 7	0.00	0.159 7	0.00	0.024 6	0.00	35.0	15.0	150.0	2.0	157.0	1.0
SKC-4-23	5.16	152.47	223.85	0.68	0.047 1	0.00	0.160 1	0.00	0.024 4	0.00	56.0	13.0	151.0	1.0	155.0	1.0
SKC-4-24	8.56	317.81	363.86	0.87	0.046 6	0.00	0.160 0	0.00	0.024 7	0.00	31.0	10.0	151.0	1.0	157.0	0.9
SKC-4-25	4.39	74.40	189.10	0.39	0.047 7	0.00	0.162 8	0.00	0.024 5	0.00	82.0	15.0	153.0	2.0	156.0	1.0
SKC-4-26	4.68	82.39	202.70	0.41	0.047 4	0.00	0.163 0	0.00	0.024 7	0.00	71.0	13.0	153.0	2.0	157.0	1.0
SKC-4-27	4.31	82.38	187.82	0.44	0.047 2	0.00	0.159 9	0.00	0.024 4	0.00	62.0	12.0	151.0	1.0	155.0	1.0
SKC-4-28	3.61	112.13	157.55	0.71	0.047 5	0.00	0.162 0	0.00	0.024 5	0.00	74.0	17.0	152.0	2.0	156.0	1.0
SKC-4-29	7.76	211.75	344.34	0.61	0.047 1	0.00	0.157 7	0.00	0.024 0	0.00	56.0	13.0	149.0	1.0	153.0	1.0
SKC-4-30	4.72	94.25	201.64	0.47	0.046 7	0.00	0.160 4	0.00	0.024 7	0.00	32.0	13.0	151.0	2.0	157.0	1.0

测点编号	元素含量/10^-6			同位素比值							年龄/Ma
测点编号	²⁰⁶Pb	²³²Th	²³⁸U	²³²Th/²³⁸U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
SKC-5-1	5.63	120.87	231.98	0.52	0.047 1	0.00	0.172 5	0.00	0.025 4	0.00	52.0	13.0	162.0	2.0	162.0	1.0
SKC-5-2	4.73	93.88	190.15	0.49	0.046 9	0.00	0.174 3	0.00	0.025 8	0.00	44.0	14.0	163.0	2.0	164.2	1.0
SKC-5-3	6.53	98.23	265.51	0.37	0.047 6	0.00	0.173 5	0.00	0.025 3	0.00	77.0	12.0	162.0	1.0	161.2	0.9
SKC-5-4	3.71	84.78	150.46	0.56	0.047 0	0.00	0.172 4	0.00	0.025 5	0.00	50.0	14.0	162.0	2.0	162.0	1.0
SKC-5-6	5.03	106.68	205.31	0.52	0.046 9	0.00	0.170 5	0.00	0.025 2	0.00	46.0	12.0	160.0	1.0	160.5	1.0
SKC-5-7	5.14	93.99	207.28	0.45	0.047 1	0.00	0.172 8	0.00	0.025 5	0.00	56.0	12.0	162.0	2.0	162.0	1.0
SKC-5-8	3.59	70.20	145.59	0.48	0.049 2	0.00	0.180 3	0.00	0.025 4	0.00	157.0	21.0	168.0	2.0	162.0	1.0
SKC-5-9	8.05	132.21	325.67	0.41	0.048 0	0.00	0.175 5	0.00	0.025 4	0.00	100.0	14.0	164.0	2.0	162.0	1.0
SKC-5-10	4.84	127.53	200.27	0.64	0.049 5	0.00	0.181 2	0.00	0.025 4	0.00	171.0	16.0	169.0	2.0	162.0	2.0
SKC-5-11	6.80	139.53	273.60	0.51	0.047 9	0.00	0.172 9	0.00	0.025 8	0.00	93.0	12.0	162.0	2.0	164.0	2.0
SKC-5-12	5.56	117.00	224.15	0.52	0.047 1	0.00	0.169 3	0.00	0.025 7	0.00	56.0	15.0	159.0	2.0	163.0	1.0
SKC-5-13	6.68	183.19	269.70	0.68	0.048 0	0.00	0.174 6	0.00	0.026 0	0.00	98.0	15.0	163.0	2.0	165.0	2.0
SKC-5-14	7.30	198.29	295.68	0.67	0.049 3	0.00	0.176 0	0.00	0.025 5	0.00	161.0	12.0	165.0	2.0	163.0	1.0
SKC-5-15	7.04	166.20	280.12	0.59	0.048 2	0.00	0.175 4	0.00	0.026 0	0.00	110.0	12.0	164.0	2.0	165.0	1.0
SKC-5-16	6.36	140.55	253.76	0.55	0.047 7	0.00	0.173 0	0.00	0.026 0	0.00	82.0	12.0	162.0	2.0	165.0	1.0
SKC-5-17	6.11	137.03	248.71	0.55	0.047 7	0.00	0.171 1	0.00	0.025 6	0.00	86.0	11.0	160.0	1.0	163.0	1.0
SKC-5-18	8.64	168.49	347.55	0.48	0.047 4	0.00	0.169 9	0.00	0.025 6	0.00	69.0	11.0	159.0	1.0	163.0	1.0
SKC-5-19	5.98	158.51	237.47	0.67	0.047 3	0.00	0.171 6	0.00	0.025 9	0.00	65.0	14.0	161.0	2.0	165.0	1.0
SKC-4-1	8.26	362.00	346.85	1.04	0.047 7	0.00	0.173 5	0.00	0.024 9	0.00	84.0	10.0	162.0	1.0	158.5	1.0
SKC-4-2	6.45	181.83	280.59	0.65	0.047 9	0.00	0.169 7	0.00	0.024 2	0.00	93.0	11.0	159.0	1.0	154.4	0.9
SKC-4-3	6.05	137.12	258.10	0.53	0.046 7	0.00	0.169 6	0.00	0.024 8	0.00	36.0	10.0	159.0	1.0	158.0	1.0
SKC-4-4	4.89	146.97	208.03	0.71	0.047 9	0.00	0.173 7	0.00	0.024 7	0.00	93.0	24.0	163.0	2.0	158.0	1.0
SKC-4-5	6.66	111.07	283.48	0.39	0.047 0	0.00	0.170 2	0.00	0.024 7	0.00	51.0	12.0	160.0	2.0	158.0	1.0
SKC-4-6	4.57	126.63	195.96	0.65	0.047 4	0.00	0.170 3	0.00	0.024 6	0.00	72.0	13.0	160.0	2.0	156.0	1.0
SKC-4-7	4.09	93.62	175.43	0.53	0.046 7	0.00	0.168 7	0.00	0.024 7	0.00	32.0	13.0	158.0	2.0	157.0	1.0
SKC-4-8	7.54	137.37	327.21	0.42	0.047 7	0.00	0.169 7	0.00	0.024 4	0.00	84.0	9.0	159.0	1.0	155.0	1.0
SKC-4-9	3.48	85.91	150.59	0.57	0.047 3	0.00	0.169 6	0.00	0.024 6	0.00	62.0	14.0	159.0	2.0	156.0	1.0
SKC-4-10	6.25	121.29	271.77	0.45	0.047 7	0.00	0.169 2	0.00	0.024 7	0.00	86.0	13.0	159.0	1.0	157.5	1.0
SKC-4-11	7.67	183.40	327.68	0.56	0.047 5	0.00	0.177 0	0.00	0.024 8	0.00	73.0	9.0	166.0	1.0	158.0	1.0
SKC-4-12	5.05	80.55	213.60	0.38	0.047 0	0.00	0.175 0	0.00	0.024 7	0.00	51.0	11.0	164.0	1.0	157.4	1.0
SKC-4-13	4.91	84.25	209.23	0.40	0.047 5	0.00	0.177 8	0.00	0.024 9	0.00	74.0	11.0	166.0	1.0	158.0	1.0
测点编号	元素含量/10^-6			同位素比值							年龄/Ma
测点编号	²⁰⁶Pb	²³²Th	²³⁸U	²³²Th/²³⁸U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁷Pb/²³⁵U	1σ	²⁰⁶Pb/²³⁸U	1σ
SKC-4-14	9.18	239.73	397.65	0.60	0.047 3	0.00	0.173 1	0.00	0.024 3	0.00	65.0	9.0	162.0	1.0	155.0	1.0
SKC-4-15	5.18	93.07	224.58	0.41	0.048 5	0.00	0.182 9	0.01	0.024 6	0.00	126.0	98.0	171.0	8.0	157.0	1.0
SKC-4-16	3.66	91.03	158.86	0.57	0.047 4	0.00	0.171 7	0.00	0.024 1	0.00	70.0	12.0	161.0	1.0	153.4	0.9
SKC-4-17	5.50	149.79	240.87	0.62	0.047 2	0.00	0.171 0	0.00	0.024 1	0.00	59.0	11.0	160.0	1.0	153.3	0.9
SKC-4-20	4.94	127.20	207.89	0.61	0.047 6	0.00	0.178 5	0.00	0.024 9	0.00	81.0	11.0	167.0	2.0	159.0	1.0
SKC-4-21	5.71	178.30	244.08	0.73	0.047 1	0.00	0.169 0	0.00	0.024 6	0.00	52.0	10.0	159.0	1.0	156.5	0.9
SKC-4-22	3.64	104.32	156.36	0.67	0.046 7	0.00	0.159 7	0.00	0.024 6	0.00	35.0	15.0	150.0	2.0	157.0	1.0
SKC-4-23	5.16	152.47	223.85	0.68	0.047 1	0.00	0.160 1	0.00	0.024 4	0.00	56.0	13.0	151.0	1.0	155.0	1.0
SKC-4-24	8.56	317.81	363.86	0.87	0.046 6	0.00	0.160 0	0.00	0.024 7	0.00	31.0	10.0	151.0	1.0	157.0	0.9
SKC-4-25	4.39	74.40	189.10	0.39	0.047 7	0.00	0.162 8	0.00	0.024 5	0.00	82.0	15.0	153.0	2.0	156.0	1.0
SKC-4-26	4.68	82.39	202.70	0.41	0.047 4	0.00	0.163 0	0.00	0.024 7	0.00	71.0	13.0	153.0	2.0	157.0	1.0
SKC-4-27	4.31	82.38	187.82	0.44	0.047 2	0.00	0.159 9	0.00	0.024 4	0.00	62.0	12.0	151.0	1.0	155.0	1.0
SKC-4-28	3.61	112.13	157.55	0.71	0.047 5	0.00	0.162 0	0.00	0.024 5	0.00	74.0	17.0	152.0	2.0	156.0	1.0
SKC-4-29	7.76	211.75	344.34	0.61	0.047 1	0.00	0.157 7	0.00	0.024 0	0.00	56.0	13.0	149.0	1.0	153.0	1.0
SKC-4-30	4.72	94.25	201.64	0.47	0.046 7	0.00	0.160 4	0.00	0.024 7	0.00	32.0	13.0	151.0	2.0	157.0	1.0

成分			老鸭巢花岗闪长岩
成分			SKC2-3			SKC2-4		SKC2-5	SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4			喻亨祥-1			喻亨祥-2			喻亨祥-3					喻亨祥-4			喻亨祥-5
SiO₂			55.44			59.45		57.56	55.17			51.79			60.39			53.10			50.11			58.91			60.21			59.52			55.61			51.34					57.01			59.31
Al₂O₃			17.63			16.60		15.63	19.51			14.96			16.57			17.84			12.62			13.93			19.84			14.29			14.65			14.25					14.69			15.10
Fe₂O_3T			3.56			6.36		4.81	3.72			4.58			5.45			4.89			5.88			7.89			3.55			1.66			3.27			3.57					2.66			3.68
MgO			3.13			2.85		1.28	1.32			1.32			1.88			1.35			1.26			1.91			0.48			1.72			2.43			2.43					2.58			2.25
CaO			6.40			4.03		6.55	4.60			8.76			3.42			9.16			15.58			6.34			5.88			5.54			6.83			10.59					5.37			3.88
Na₂O			1.08			2.57		2.72	0.51			1.50			2.18			0.19			0.20			0.12			0.07			2.09			2.12			3.49					4.24			3.26
K₂O			4.67			2.21		4.96	7.02			7.77			4.73			3.53			1.96			2.72			1.25			2.67			3.70			1.57					1.93			3.06
MnO			0.09			0.08		0.13	0.07			0.14			0.07			0.12			0.18			0.25			0.07			0.09			0.14			0.23					0.11			0.08
TiO₂			0.68			0.86		0.80	0.86			0.72			0.81			0.72			0.41			0.31			0.66			0.50			0.64			0.64					0.62			0.51
P₂O₅			0.34			0.41		0.37	0.35			0.34			0.37			0.29			0.14			0.13			0.33			0.28			0.22			0.19					0.20			0.30
烧失量			6.91			4.30		5.13	6.63			7.84			4.05			8.79			11.16			7.23			7.35			6.68			6.69			8.28					6.26			5.21
成分		老鸭巢花岗闪长岩																														鸭公塘花岗闪长岩
成分		SKC2-3			SKC2-4			SKC2-5			SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4						喻亨祥-1			喻亨祥-2		喻亨祥-3			喻亨祥-4		喻亨祥-5
Li		32.6			23.5			15.7			9.97			11.9			22.5			37.1			31.2			133			92.8
Be		2.39			2.26			1.29			2.32			1.97			2.07			2.22			1.33			2			1.66
Sc		15.4			16.4			17.8			20.7			19.2			19.2			18.3			12.3			5.44			17.4
V		117			134			145			162			162			135			137			85.2			56			126
Cr		105			150			133			155			97.9			203			203			179			13.3			32.6
Co		15.5			13			12			12.8			12			16.3			16.3			15.4			5.07			9.94
Ni		8.74			11.8			15.3			19.7			11.8			12.8			11.5			16			7.15			7.98
Cu		33.2			37.5			53.4			48.2			59.8			139			48.3			174			78.5			203
Zn		61			96.8			688			857			278			603			1 604			3 326			288			87.1
Ga		17.6			17.9			16.9			21.5			18.7			18.6			19.3			12.3			18.5			20.3
Rb		173			97.8			185			240			258			173			209			66.2			106			47.1
Sr		205			246			217			152			451			247			46.5			50.7			40.6			27.3
Y		26.4			17			20			17.9			33.6			22.5			22.8			21.3			16			22.6
Nb		13.4			14.7			14.3			15.7			14.1			15			13.8			10.3			11.2			14.6
Mo		2.26			1.94			3.24			3.54			3.28			3.49			3.55			18.3			15.9			37
Cd		0.237			0.086			1.91			2.68			0.55			0.651			6.84			13.8			0.554			0.225
In		0.117			0.064			0.148			0.473			0.077			0.052			0.145			1.83			0.247			0.053
Sb		4.88			2.68			7.7			6.07			25.5			18.6			5.9			30			18.7			3.66
Cs		32.3			14.3			7.88			17.9			15.7			15.8			14.8			11.7			13.7			9.73
Ba		546			241			542			591			1202			611			45.5			44.9			30.5			78.5
La		41.5			34.9			41.1			36.9			46			44.4			66.9			35.6			35.2			40
Ce		79.3			64.5			76.9			69.7			86.4			83.1			124			67.3			53.4			77.2
Pr		9.51			7.23			8.86			8.09			10.3			9.76			14.6			7.72			5.78			9.1
Nd		37.7			27.6			34			30			40.7			37			58			29.3			19.7			34.9
Sm		7.2			5.15			6.39			5.35			7.91			6.74			9.95			5.4			3.51			6.57
Eu		1.82			1.73			1.43			1.09			2.18			1.69			2.54			1.4			1.06			1.41
Gd		6.19			4.23			5.08			4.63			6.92			5.43			7.42			4.74			3.23			5.75
Tb		1.01			0.68			0.795			0.721			1.16			0.866			1.05			0.749			0.54			0.976
Dy		5.47			3.85			4.13			3.73			6.41			4.91			5.33			4.36			3.24			4.89
Ho		0.948			0.64			0.762			0.646			1.21			0.82			0.888			0.786			0.588			0.882
Er		2.81			1.95			2.37			2.02			3.6			2.56			2.46			2.37			1.83			2.56
Tm		0.483			0.302			0.364			0.299			0.588			0.395			0.372			0.383			0.295			0.422
Yb		3.21			1.92			2.52			2.03			4.12			2.44			2.46			2.93			1.79			2.49
Lu		0.475			0.272			0.375			0.311			0.607			0.408			0.373			0.423			0.294			0.385
成分	老鸭巢花岗闪长岩																														鸭公塘花岗闪长岩
成分	SKC2-3			SKC2-4			SKC2-5			SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4						喻亨祥-1			喻亨祥-2		喻亨祥-3			喻亨祥-4				喻亨祥-5
Ta	1.21			1.17			1.18			1.21			1.27			1.25			1.06			1.28			1.22			1.15
W	7.8			9.65			11.8			19.7			7.28			15.8			27.5			20.3			56.5			5.73
Re	0.017			0.022			0.02			0.038			0.015			0.026			0.038			0.052			0.011			0.015
Tl	1.36			0.738			0.889			1.45			0.876			0.764			1.62			0.686
Pb	23.8			12.4			29.4			145			47.6			21.9			246			710			37.4			34.2
Bi	1.18			0.601			1			1.16			0.657			0.553			2.5			62.7
Th	12.6			16.8			18.2			15.6			20.2			16.5			12.2			18.4			26.3			15
U	2.81			3.43			3.84			14.8			4.13			3.61			4.98			4.24			2.04			1.99
Zr	120			94.9			98.3			93.2			126			96.7			92.1			117			104			80.8
Hf	6.03			4.38			5.03			4.32			5.35			4.2			4.14			5.27			3.58			2.66

成分			老鸭巢花岗闪长岩
成分			SKC2-3			SKC2-4		SKC2-5	SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4			喻亨祥-1			喻亨祥-2			喻亨祥-3					喻亨祥-4			喻亨祥-5
SiO₂			55.44			59.45		57.56	55.17			51.79			60.39			53.10			50.11			58.91			60.21			59.52			55.61			51.34					57.01			59.31
Al₂O₃			17.63			16.60		15.63	19.51			14.96			16.57			17.84			12.62			13.93			19.84			14.29			14.65			14.25					14.69			15.10
Fe₂O_3T			3.56			6.36		4.81	3.72			4.58			5.45			4.89			5.88			7.89			3.55			1.66			3.27			3.57					2.66			3.68
MgO			3.13			2.85		1.28	1.32			1.32			1.88			1.35			1.26			1.91			0.48			1.72			2.43			2.43					2.58			2.25
CaO			6.40			4.03		6.55	4.60			8.76			3.42			9.16			15.58			6.34			5.88			5.54			6.83			10.59					5.37			3.88
Na₂O			1.08			2.57		2.72	0.51			1.50			2.18			0.19			0.20			0.12			0.07			2.09			2.12			3.49					4.24			3.26
K₂O			4.67			2.21		4.96	7.02			7.77			4.73			3.53			1.96			2.72			1.25			2.67			3.70			1.57					1.93			3.06
MnO			0.09			0.08		0.13	0.07			0.14			0.07			0.12			0.18			0.25			0.07			0.09			0.14			0.23					0.11			0.08
TiO₂			0.68			0.86		0.80	0.86			0.72			0.81			0.72			0.41			0.31			0.66			0.50			0.64			0.64					0.62			0.51
P₂O₅			0.34			0.41		0.37	0.35			0.34			0.37			0.29			0.14			0.13			0.33			0.28			0.22			0.19					0.20			0.30
烧失量			6.91			4.30		5.13	6.63			7.84			4.05			8.79			11.16			7.23			7.35			6.68			6.69			8.28					6.26			5.21
成分		老鸭巢花岗闪长岩																														鸭公塘花岗闪长岩
成分		SKC2-3			SKC2-4			SKC2-5			SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4						喻亨祥-1			喻亨祥-2		喻亨祥-3			喻亨祥-4		喻亨祥-5
Li		32.6			23.5			15.7			9.97			11.9			22.5			37.1			31.2			133			92.8
Be		2.39			2.26			1.29			2.32			1.97			2.07			2.22			1.33			2			1.66
Sc		15.4			16.4			17.8			20.7			19.2			19.2			18.3			12.3			5.44			17.4
V		117			134			145			162			162			135			137			85.2			56			126
Cr		105			150			133			155			97.9			203			203			179			13.3			32.6
Co		15.5			13			12			12.8			12			16.3			16.3			15.4			5.07			9.94
Ni		8.74			11.8			15.3			19.7			11.8			12.8			11.5			16			7.15			7.98
Cu		33.2			37.5			53.4			48.2			59.8			139			48.3			174			78.5			203
Zn		61			96.8			688			857			278			603			1 604			3 326			288			87.1
Ga		17.6			17.9			16.9			21.5			18.7			18.6			19.3			12.3			18.5			20.3
Rb		173			97.8			185			240			258			173			209			66.2			106			47.1
Sr		205			246			217			152			451			247			46.5			50.7			40.6			27.3
Y		26.4			17			20			17.9			33.6			22.5			22.8			21.3			16			22.6
Nb		13.4			14.7			14.3			15.7			14.1			15			13.8			10.3			11.2			14.6
Mo		2.26			1.94			3.24			3.54			3.28			3.49			3.55			18.3			15.9			37
Cd		0.237			0.086			1.91			2.68			0.55			0.651			6.84			13.8			0.554			0.225
In		0.117			0.064			0.148			0.473			0.077			0.052			0.145			1.83			0.247			0.053
Sb		4.88			2.68			7.7			6.07			25.5			18.6			5.9			30			18.7			3.66
Cs		32.3			14.3			7.88			17.9			15.7			15.8			14.8			11.7			13.7			9.73
Ba		546			241			542			591			1202			611			45.5			44.9			30.5			78.5
La		41.5			34.9			41.1			36.9			46			44.4			66.9			35.6			35.2			40
Ce		79.3			64.5			76.9			69.7			86.4			83.1			124			67.3			53.4			77.2
Pr		9.51			7.23			8.86			8.09			10.3			9.76			14.6			7.72			5.78			9.1
Nd		37.7			27.6			34			30			40.7			37			58			29.3			19.7			34.9
Sm		7.2			5.15			6.39			5.35			7.91			6.74			9.95			5.4			3.51			6.57
Eu		1.82			1.73			1.43			1.09			2.18			1.69			2.54			1.4			1.06			1.41
Gd		6.19			4.23			5.08			4.63			6.92			5.43			7.42			4.74			3.23			5.75
Tb		1.01			0.68			0.795			0.721			1.16			0.866			1.05			0.749			0.54			0.976
Dy		5.47			3.85			4.13			3.73			6.41			4.91			5.33			4.36			3.24			4.89
Ho		0.948			0.64			0.762			0.646			1.21			0.82			0.888			0.786			0.588			0.882
Er		2.81			1.95			2.37			2.02			3.6			2.56			2.46			2.37			1.83			2.56
Tm		0.483			0.302			0.364			0.299			0.588			0.395			0.372			0.383			0.295			0.422
Yb		3.21			1.92			2.52			2.03			4.12			2.44			2.46			2.93			1.79			2.49
Lu		0.475			0.272			0.375			0.311			0.607			0.408			0.373			0.423			0.294			0.385
成分	老鸭巢花岗闪长岩																														鸭公塘花岗闪长岩
成分	SKC2-3			SKC2-4			SKC2-5			SKC2-6			SKC2-7			SKC2-8			SKC2-9			SKC2-10			SKC-B5			SKC-B4						喻亨祥-1			喻亨祥-2		喻亨祥-3			喻亨祥-4				喻亨祥-5
Ta	1.21			1.17			1.18			1.21			1.27			1.25			1.06			1.28			1.22			1.15
W	7.8			9.65			11.8			19.7			7.28			15.8			27.5			20.3			56.5			5.73
Re	0.017			0.022			0.02			0.038			0.015			0.026			0.038			0.052			0.011			0.015
Tl	1.36			0.738			0.889			1.45			0.876			0.764			1.62			0.686
Pb	23.8			12.4			29.4			145			47.6			21.9			246			710			37.4			34.2
Bi	1.18			0.601			1			1.16			0.657			0.553			2.5			62.7
Th	12.6			16.8			18.2			15.6			20.2			16.5			12.2			18.4			26.3			15
U	2.81			3.43			3.84			14.8			4.13			3.61			4.98			4.24			2.04			1.99
Zr	120			94.9			98.3			93.2			126			96.7			92.1			117			104			80.8
Hf	6.03			4.38			5.03			4.32			5.35			4.2			4.14			5.27			3.58			2.66

Sample	t/Ma	¹⁷⁶Yb/¹⁷⁷Hf	2σ	¹⁷⁶Lu/¹⁷⁷Hf	2σ	¹⁷⁶Hf/¹⁷⁷Hf	2σ	ε_Hf(0)	ε_Hf(t)	T_DM1/Ma	T_DM2/Ma	f_Lu/Hf
SKC-5-1	162.0	0.060 150	0.000 308	0.001 486	0.000 010	0.282 433	0.000 014	-12.00	-8.61	1 173	1 756	-0.96
SKC-5-2	164.2	0.076 536	0.002 270	0.001 707	0.000 044	0.282 388	0.000 014	-13.57	-10.15	1 243	1 855	-0.95
SKC-5-3	161.2	0.068 491	0.000 573	0.001 696	0.000 013	0.282 429	0.000 016	-12.12	-8.77	1 184	1 765	-0.95
SKC-5-4	162.0	0.070 266	0.000 567	0.001 754	0.000 013	0.282 415	0.000 016	-12.61	-9.25	1 206	1 796	-0.95
SKC-5-6	160.5	0.073 243	0.000 156	0.001 864	0.000 009	0.282 430	0.000 015	-12.10	-8.78	1 189	1 765	-0.94
SKC-5-7	162.0	0.056 802	0.000 432	0.001 510	0.000 010	0.282 400	0.000 016	-13.16	-9.77	1 220	1 829	-0.95
SKC-5-8	162.0	0.041 586	0.000 271	0.001 088	0.000 003	0.282 409	0.000 014	-12.85	-9.41	1 194	1 807	-0.97
SKC-5-9	162.0	0.057 031	0.001 164	0.001 608	0.000 029	0.282 395	0.000 015	-13.33	-9.95	1 230	1 840	-0.95
SKC-5-10	162.0	0.060 815	0.001 016	0.001 638	0.000 026	0.282 396	0.000 016	-13.29	-9.91	1 229	1 838	-0.95
SKC-5-11	164.0	0.046 765	0.001 636	0.001 438	0.000 071	0.282 397	0.000 022	-13.26	-9.82	1 222	1 834	-0.96
SKC-5-12	163.0	0.044 994	0.000 482	0.001 224	0.000 019	0.282 426	0.000 015	-12.22	-8.78	1 173	1 767	-0.96
SKC-5-13	165.0	0.042 951	0.000 596	0.001 176	0.000 024	0.282 433	0.000 019	-11.99	-8.50	1 162	1 751	-0.96
SKC-5-14	163.0	0.058 611	0.000 706	0.001 594	0.000 018	0.282 407	0.000 017	-12.91	-9.51	1 212	1 813	-0.95
SKC-5-15	165.0	0.054 375	0.000 489	0.001 462	0.000 007	0.282 391	0.000 014	-13.47	-10.01	1 230	1 846	-0.96
SKC-5-16	165.0	0.060 732	0.000 571	0.001 651	0.000 013	0.282 410	0.000 015	-12.79	-9.35	1 209	1 804	-0.95
SKC-5-17	163.0	0.056 307	0.001 360	0.001 516	0.000 029	0.282 359	0.000 017	-14.61	-11.20	1 278	1 920	-0.95
SKC-5-18	163.0	0.060 284	0.000 698	0.001 682	0.000 028	0.282 425	0.000 021	-12.26	-8.87	1 189	1 773	-0.95
SKC-5-19	165.0	0.057 023	0.001 358	0.001 623	0.000 061	0.282 442	0.000 017	-11.68	-8.24	1 164	1 734	-0.95
Sample	t/Ma	¹⁷⁶Yb/¹⁷⁷Hf	2σ	¹⁷⁶Lu/¹⁷⁷Hf	2σ	¹⁷⁶Hf/¹⁷⁷Hf	2σ	ε_Hf(0)	ε_Hf(t)	T_DM1/Ma	T_DM2/Ma	f_Lu/Hf
SKC-4-1	158.5	0.048 149	0.000 824	0.001 222	0.000 022	0.282 425	0.000 017	-12.28	-8.94	1 175	1 774	-0.96
SKC-4-2	154.4	0.043 035	0.000 219	0.001 082	0.000 004	0.282 431	0.000 016	-12.06	-8.79	1 162	1 761	-0.97
SKC-4-3	158.0	0.054 419	0.000 975	0.001 437	0.000 011	0.282 397	0.000 015	-13.26	-9.95	1 221	1 837	-0.96
SKC-4-4	158.0	0.052 119	0.000 697	0.001 336	0.000 013	0.282 398	0.000 015	-13.22	-9.89	1 216	1 834	-0.96
SKC-4-5	158.0	0.068 126	0.000 879	0.001 627	0.000 018	0.282 408	0.000 015	-12.89	-9.59	1 213	1 815	-0.95
SKC-4-6	156.0	0.056 267	0.000 225	0.001 406	0.000 007	0.282 417	0.000 016	-12.56	-9.29	1 192	1 794	-0.96
SKC-4-7	157.0	0.064 913	0.001 252	0.001 608	0.000 032	0.282 421	0.000 016	-12.42	-9.14	1 193	1 786	-0.95
SKC-4-8	155.0	0.087 113	0.001 206	0.002 440	0.000 056	0.282 505	0.000 118	-9.43	-6.27	1 097	1 602	-0.93
SKC-4-9	156.0	0.059 965	0.000 464	0.001 493	0.000 016	0.282 442	0.000 017	-11.67	-8.40	1 159	1 738	-0.96
SKC-4-10	157.5	0.051 321	0.000 882	0.001 323	0.000 039	0.282 410	0.000 018	-12.81	-9.49	1 200	1 808	-0.96
SKC-4-11	158.0	0.024 387	0.001 077	0.000 569	0.000 028	0.282 294	0.000 014	-16.92	-13.51	1 337	2 063	-0.98
SKC-4-12	157.4	0.041 567	0.000 644	0.001 153	0.000 030	0.282 406	0.000 037	-12.95	-9.62	1 200	1 816	-0.97
SKC-4-13	158.0	0.060 840	0.001 203	0.001 482	0.000 021	0.282 395	0.000 018	-13.34	-10.03	1 226	1 842	-0.96
SKC-4-14	155.0	0.060 400	0.000 708	0.001 527	0.000 013	0.282 421	0.000 015	-12.41	-9.16	1 190	1 785	-0.95
SKC-4-15	157.0	0.076 601	0.000 580	0.001 875	0.000 016	0.282 397	0.000 017	-13.25	-10.00	1 235	1 839	-0.94
SKC-4-16	153.4	0.049 778	0.000 670	0.001 379	0.000 033	0.282 406	0.000 020	-12.94	-9.71	1 206	1 819	-0.96
SKC-4-17	153.3	0.056 876	0.000 438	0.001 469	0.000 010	0.282 433	0.000 019	-11.98	-8.77	1 171	1 759	-0.96
SKC-4-20	159.0	0.032 239	0.000 303	0.000 887	0.000 011	0.282 441	0.000 014	-11.69	-8.29	1 142	1 734	-0.97
SKC-4-21	156.5	0.043 889	0.000 452	0.001 147	0.000 007	0.282 444	0.000 018	-11.60	-8.28	1 146	1 731	-0.97
SKC-4-22	157.0	0.031 698	0.000 278	0.000 865	0.000 006	0.282 417	0.000 014	-12.55	-9.19	1 175	1 789	-0.97
SKC-4-23	155.0	0.057 053	0.000 323	0.001 563	0.000 019	0.282 457	0.000 014	-11.13	-7.89	1 140	1 705	-0.95
SKC-4-24	157.0	0.068 774	0.000 715	0.001 802	0.000 014	0.282 355	0.000 016	-14.74	-11.48	1 293	1 933	-0.95
SKC-4-25	156.0	0.045 155	0.000 487	0.001 273	0.000 011	0.282 434	0.000 017	-11.96	-8.67	1 164	1 755	-0.96
SKC-4-26	157.0	0.043 342	0.000 368	0.001 239	0.000 010	0.282 420	0.000 017	-12.44	-9.12	1 182	1 785	-0.96
SKC-4-27	155.0	0.065 170	0.001 949	0.002 261	0.000 059	0.282 366	0.000 024	-14.36	-11.19	1 294	1 913	-0.93
SKC-4-28	156.0	0.043 650	0.000 230	0.001 196	0.000 011	0.282 503	0.000 027	-9.53	-6.23	1 065	1 601	-0.96
SKC-4-29	153.0	0.055 429	0.000 533	0.001 452	0.000 015	0.282 416	0.000 015	-12.60	-9.39	1 195	1 798	-0.96
SKC-4-30	157.0	0.049 419	0.000 471	0.001 432	0.000 018	0.282 347	0.000 016	-15.01	-11.72	1 291	1 948	-0.96
