Mineral surface reaction constraints on the formation of ion-adsorption rare earth element deposits

doi:10.13745/j.esf.sf.2021.8.8

Abstract

Abstract:

The ion-adsorption rare earth element (IAR) deposits in South China produce more than 90% of the world’s heavy rare earth elements (HREEs). They are a key strategic metal resource of China. Thus, a better understanding of the metallogenic mechanism and resource characteristics of IAR deposits can provide a theoretical basis for increasing REE reserves and better utilization of REE resources. The IAR deposits are mainly developed in the weathering crusts of REE-rich granite, epimetamorphic and volcanic rocks. The REE-bearing minerals in protolith are the main sources of REE cations in weathering crust, where mineral association greatly determines the concentration and fractionation characteristics of REEs. Under physical/chemical weathering and microbial action, the dissolution of rock-forming minerals, REE-bearing minerals and REE minerals results in the activation and re-enrichment of REEs. On one hand, weathering of protolith produces clay minerals and Fe-Mn (hydr)oxides with a large specific surface area and high surface charge density. On the other hand, these secondary minerals can adsorb REE cations via ion exchange, surface adsorption/complexation or formation of secondary REE minerals. The adsorption mechanism, enrichment-fractionation characteristics and occurrence state of REEs are affected by mineral types, pH and microbial activity. By using high-resolution transmission electron microscopy (HRTEM) coupled with selected area electron diffraction (SAED) and electron energy loss spectroscopy (EELS) and synchrotron radiation X-ray absorption fine structure spectroscopy (XAFS), the atomic occurrence state of REEs can be determined. In the future, more attention should be paid to research areas including the association of REE-bearing minerals in protoliths and its evolutionary pathway and mechanism, the constraints of microbial weathering on the formation of IAR deposits, and the microscopic occurrence state of REEs.

Key words: ion-adsorption type rare earth element deposit, mineral dissolution, mineral evolution, enrichment and fractionation of rare earth elements, microbial weathering, mineral surface reaction

CLC Number:

P618.7
P595

LIANG Xiaoliang, TAN Wei, MA Lingya, ZHU Jianxi, HE Hongping. Mineral surface reaction constraints on the formation of ion-adsorption rare earth element deposits[J]. Earth Science Frontiers, 2022, 29(1): 29-41.

Figures/Tables 8

References 103

[1]	KYNICKY J, SMITH M P, XU C. Diversity of rare earth deposits: the key example of China[J]. Elements, 2012, 8(5):361-367. DOI URL
[2]	翟明国, 吴福元, 胡瑞忠, 等. 战略性关键金属矿产资源:现状与问题[J]. 中国科学基金, 2019, 33(2):106-111.
[3]	LIU R S, LI Q, GONG M, et al. The new resources prospect of ion adsorption type rare earth resources in metamorphic rock’s weathering crust, South Jiangxi[J]. Advances in Geosciences, 2014, 4(6):419-425. DOI URL
[4]	XU C, KYNICKÝ J, SMITH M P, et al. Origin of heavy rare earth mineralization in South China[J]. Nature Communications, 2017, 8:14598. DOI URL
[5]	BAO Z W, ZHAO Z H. Geochemistry of mineralization with exchangeable REY in the weathering crusts of granitic rocks in South China[J]. Ore Geology Reviews, 2008, 33(3/4):519-535. DOI URL
[6]	HE C, XU C, ZHAO Z, et al. Petrogenesis and mineralization of REE-rich granites in Qingxi and Guanxi, Nanling Region, South China[J]. Ore Geology Reviews, 2017, 81:309-325. DOI URL
[7]	LI Y H M, ZHAO W W, ZHOU M F. Nature of parent rocks, mineralization styles and ore genesis of regolith-hosted REE deposits in South China: an integrated genetic model[J]. Journal of Asian Earth Sciences, 2017, 148:65-95. DOI URL
[8]	郭威, 付伟, 黄小荣, 等. 广西富稀土风化壳的矿物学特征初步探讨[J]. 矿物学报, 2013, 33(增刊2):209.
[9]	FU W, LI X T, FENG Y Y, et al. Chemical weathering of S-type granite and formation of Rare Earth Element (REE)-rich regolith in South China:critical control of lithology[J]. Chemical Geology, 2019, 520:33-51. DOI URL
[10]	LI M Y H, ZHOU M F. The role of clay minerals in formation of the regolith-hosted heavy rare earth element deposits[J]. American Mineralogist, 2020, 105(1):92-108. DOI URL
[11]	MIDDELBURG J J, VAN DER WEIJDEN C H, WOITTIEZ J R W. Chemical processes affecting the mobility of major, minor and trace-elements during weathering of granitic rocks[J]. Chemical Geology, 1988, 68(3/4):253-273. DOI URL
[12]	张培善, 陶克捷, 杨主明, 等. 中国稀土矿物学[M]. 北京: 科学出版社, 1998: 37-44.
[13]	杨学明, 张培善. 花岗岩中稀土元素的赋存状态及质量平衡研究[J]. 稀土, 1992, 13(5):6-11.
[14]	陈斌锋, 邹新勇, 彭琳琳, 等. 清溪岩体稀土矿床地质特征及重稀土找矿潜力[J]. 稀土, 2019, 40(4):20-31.
[15]	张颐, 丘文, 王文亮. 福建龙岩万安稀土矿床地质特征及成因探讨[J]. 福建地质, 2014, 33(3):185-191.
[16]	陈炳辉, 俞受鋆. 广东平远仁居—黄畲地区燕山晚期花岗岩类的地质地球化学特征[J]. 中山大学学报(自然科学版), 1994, 33:130-133.
[17]	王臻, 陈振宇, 赵芝, 等. 赣南新元古代变质岩稀土矿物及其地球化学特征[J]. 矿床地质, 2019, 38(4):837-850.
[18]	王臻, 赵芝, 邹新勇, 等. 赣南浅变质岩岩石地球化学特征及稀土成矿潜力研究[J]. 岩矿测试, 2018, 37(1):96-107.
[19]	李维亚. 江西省花岗岩型稀土矿床初步研究[R]. 南昌:江西省地质局中心实验室, 1975: 173.
[20]	李余华, 张子军, 龙庆兵, 等. 云南建水普雄铌稀土矿床微量和稀土元素地球化学特征[J]. 矿物学报, 2019, 39(4):474-483.
[21]	王庆权, 王联魁. 大容山花岗岩带中石榴子石、堇青石的成因研究[J]. 矿物学报, 1989, 9(1):42-50, 102.
[22]	包志伟, 赵振华. 佛冈铝质A型花岗岩的地球化学及其形成环境初探[J]. 地质地球化学, 2003, 31(1):52-61.
[23]	李献华, 李武显, 李正祥. 再论南岭燕山早期花岗岩的成因类型与构造意义[J]. 科学通报, 2007, 52(9):981-991.
[24]	白鸽. 足洞花岗岩风化壳离子吸附型重稀土矿[R]. 赣州: 江西省地质矿产局赣南地质调查大队, 1987: 31.
[25]	郜兆典, 张忠伟, 黄方方. 广西风化矿床[M]. 北京: 地质出版社, 2013: 168-169.
[26]	GOLDICH S S. A study in rock-weathering[J]. The Journal of Geology, 1938, 46(1):17-58. DOI URL
[27]	BROSKA I, WILLIAMS C T, JANÁK M, et al. Alteration and breakdown of xenotime-(Y) and monazite-(Ce) in granitic rocks of the Western Carpathians, Slovakia[J]. Lithos, 2005, 82(1/2):71-83. DOI URL
[28]	TROMANS D. Solubility of crystalline and metamict zircon: a thermodynamic analysis[J]. Journal of Nuclear Materials, 2006, 357(1/2/3):221-233. DOI URL
[29]	王登红, 赵芝, 于扬, 等. 离子吸附型稀土资源研究进展、存在问题及今后研究方向[J]. 岩矿测试, 2013, 32(5):796-802.
[30]	莫彬彬, 连宾. 长石风化作用及影响因素分析[J]. 地学前缘, 2010, 17(3):281-289.
[31]	LI M Y H, ZHOU M F, WILLIAMS-JONES A E. The genesis of regolith-hosted heavy rare earth element deposits: insights from the world-class Zudong deposit in Jiangxi Province, South China[J]. Economic Geology, 2019, 114(3):541-568. DOI URL
[32]	BRAY A W, OELKERS E H, BONNEVILLE S, et al. The effect of pH, grain size, and organic ligands on biotite weathering rates[J]. Geochimica et Cosmochimica Acta, 2015, 164:127-145. DOI URL
[33]	CHAÏRAT C, SCHOTT J, OELKERS E H, et al. Kinetics and mechanism of natural fluorapatite dissolution at 25 ℃ and pH from 3 to 12[J]. Geochimica et Cosmochimica Acta, 2007, 71(24):5901-5912. DOI URL
[34]	MAES S, ZHUANG W Q, RABAEY K, et al. Concomitant leaching and electrochemical extraction of rare earth elements from monazite[J]. Environmental Science & Technology, 2017, 51:1654-1661. https://pubs.acs.org/doi/10.1021/acs.est.6b03675. DOI URL
[35]	陈炳辉, 刘琥琥, 毋福海. 花岗岩风化壳中的微生物及其对稀土元素的浸出作用[J]. 地质论评, 2001, 47(1):88-94.
[36]	IBRAHIM H, EL-SHEIKH E M. Bioleaching treatment of Abu Zeneima uraniferous gibbsite ore material for recovering U, REEs, Al and Zn[J]. Research Journal of Chemical Science, 2011, 1:55-66.
[37]	ZHANG L M, DONG H L, LIU Y, et al. Bioleaching of rare earth elements from bastnaesite-bearing rock by actinobacteria[J]. Chemical Geology, 2018, 483:544-557. DOI URL
[38]	KEEKAN K K, JALONDHARA J C, ABHILAS H. Extraction of Ce and Th from monazite using REE tolerant Aspergillus niger[J]. Mineral Processing and Extractive Metallurgy Review, 2017, 38(5):312-320. DOI URL
[39]	SHIN D, KIM J, KIM B S, et al. Use of phosphate solubilizing bacteria to leach rare earth elements from monazite-bearing ore[J]. Minerals, 2015, 5(2):189-202. DOI URL
[40]	FATHOLLAHZADEH H, BECKER T, EKSTEEN J J, et al. Microbial contact enhances bioleaching of rare earth elements[J]. Biotechnology Reports, 2018, 3:102-108.
[41]	BRISSON V L, ZHUANG W Q, ALVAREZ-COHEN L. Bioleaching of rare earth elements from monazite sand[J]. Biotechnology and Bioengineering, 2016, 113(2):339-348. DOI URL
[42]	FATHOLLAHZADEH H, HACKETT M J, KHALEQUE H N, et al. Better together: potential of co-culture microorganisms to enhance bioleaching of rare earth elements from monazite[J]. Biotechnology Reports, 2018, 3:109-118.
[43]	FATHOLLAHZADEH H, EKSTEEN J J, KAKSONEN A H, et al. Role of microorganisms in bioleaching of rare earth elements from primary and secondary resources[J]. Applied Microbiology and Biotechnology, 2019, 103:1043-1057. https://link.springer.com/article/10.1007%2Fs00253-018-9526-z. DOI URL
[44]	ISKE U, BULLMANN M, GLOMBITZA F. Organoheterotrophe laugung resistenter materialien[J]. Acta Biotechnologica, 1987, 7(5):401-407. DOI URL
[45]	BRANDL H. Microbial leaching of metals[M]// Biotechnology. Weinheim: Wiley-VCH, 2008: 191-224.
[46]	RODRIGUEZ-LEIVA M, TRIBUTSCH H. Morphology of bacterial leaching patterns by Thiobacillus ferrooxidans on synthetic pyrite[J]. Archives of Microbiology, 1988, 149(5):401-405. DOI URL
[47]	LI Z B, LIU L W, CHEN J, et al. Cellular dissolution at hypha- and spore-mineral interfaces revealing unrecognized mechanisms and scales of fungal weathering[J]. Geology, 2016, 44(4):319-322. DOI URL
[48]	LI Z B, LU X C, TENG H H, et al. Specificity of low molecular weight organic acids on the release of elements from lizardite during fungal weathering[J]. Geochimica et Cosmochimica Acta, 2019, 256:20-34. DOI URL
[49]	马毅杰, 罗家贤, 蒋梅茵, 等. 我国南方铁铝土矿物组成及其风化和演变[J]. 沉积学报, 1999, 17(增刊1):681-686.
[50]	GALÁN E, FERRELL R E. Genesis of clay minerals[M]//BERGAYA F, LAGALY G. Developments in clay science. Amsterdam: Elsevier, 2013: 83-126.
[51]	赵芝, 王登红, 王成辉, 等. 离子吸附型稀土找矿及研究新进展[J]. 地质学报, 2019, 93(6):1454-1465.
[52]	LANGMUIR D. Aqueous environmental geochemistry[M]. New Jersey: Prentice Hall, 1997: 312-340.
[53]	BANFIELD J F, EGGLETON R A. Analytical transmission electron-microscope studies of plagioclase, muscovite, and K-feldspar weathering[J]. Clays and Clay Minerals, 1990, 38(1):77-89. DOI URL
[54]	YUAN G H, CAO Y C, SCHULZ H M, et al. A review of feldspar alteration and its geological significance in sedimentary basins: from shallow aquifers to deep hydrocarbon reservoirs[J]. Earth-Science Reviews, 2019, 191:114-140. DOI URL
[55]	PAPOULIS D, TSOLIS-KATAGAS P, KATAGAS C. Progressive stages in the formation of kaolin minerals of different morphologies in the weathering of plagioclase[J]. Clays and Clay Minerals, 2004, 52(3):275-286. DOI URL
[56]	WILSON M J. Weathering of the primary rock-forming minerals: processes, products and rates[J]. Clay Minerals, 2004, 39(3):233-266. DOI URL
[57]	VELDE B B, MEUNIER A. The origin of clay minerals in soils and weathered rocks[M]. Berlin: Springer Science and Business Media, 2008: 156-192.
[58]	AHN J H, PEACOR D R. Kaolinitization of biotite - TEM data and implications for an alteration mechanism[J]. American Mineralogist, 1987, 72:353-356.
[59]	DONG H L, PEACOR D R, MURPHY S F. TEM study of progressive alteration of igneous biotite to kaolinite throughout a weathered soil profile[J]. Geochimica et Cosmochimica Acta, 1998, 62(11):1881-1887. DOI URL
[60]	张祖海. 华南风化壳离子吸附型稀土矿床[J]. 地质找矿论丛, 1990, 5(1):57-71.
[61]	张培善, 林传仙. 华南离子型稀土矿地质矿物和地球化学[R]. 赣州: 中国科学院稀土办公室, 1993: 32-36.
[62]	刘英俊, 曹励明, 李兆麟. 元素地球化学[M]. 北京: 科学出版社, 1984: 80-95.
[63]	BANFIELD J F. The mineralogy and chemistry of granite weathering[D]. Canberra: Australian National University, 1985: 69-72.
[64]	VANIMAN D T, CHIPERA S J, BISH D L, et al. Crystal chemistry of clay-Mn oxide associations in soils, fractures, and matrix of the Bandelier Tuff, Pajarito Mesa, New Mexico[J]. Geochimica et Cosmochimica Acta, 2002, 66(8):1349-1374. DOI URL
[65]	SAWKA W N, BANFIELD J F, CHAPPELL B W. A weathering-related origin of widespread monazite in S-type granites[J]. Geochimica et Cosmochimica Acta, 1986, 50(1):171-175. DOI URL
[66]	BANFIELD J F, EGGLETON R A. Apatite replacement and rare earth mobilization, fractionation, and fixation during weathering[J]. Clays and Clay Minerals, 1989, 37(2):113-127. DOI URL
[67]	SANEMATSU K, KON Y, IMAI A. Influence of phosphate on mobility and adsorption of REEs during weathering of granites in Thailand[J]. Journal of Asian Earth Sciences, 2015, 111:14-30. DOI URL
[68]	BERN C R, YESAVAGE T, FOLEY N K. Ion-adsorption REEs in regolith of the Liberty Hill pluton, South Carolina, USA: an effect of hydrothermal alteration[J]. Journal of Geochemical Exploration, 2017, 172:29-40. DOI URL
[69]	池汝安, 田君. 风化壳淋积型稀土矿评述[J]. 中国稀土学报, 2007, 25(6):641-650.
[70]	HUANG J, TAN W, LIANG X L, et al. REE fractionation controlled by REE speciation during formation of the Renjü regolith-hosted REE deposits in Guangdong Province, South China[J]. Ore Geology Reviews, 2021, 134:104172. DOI URL
[71]	胡淙声. 赣南离子吸附型稀土矿成矿规律研究[R]. 赣州: 江西省地矿局赣南地调大队, 1986: 63-64.
[72]	COPPIN F, BERGER G, BAUER A, et al. Sorption of lanthanides on smectite and kaolinite[J]. Chemical Geology, 2002, 182(1):57-68. DOI URL
[73]	YANG M J, LIANG X L, MA L Y, et al. Adsorption of REEs on kaolinite and halloysite: a link to the REE distribution on clays in the weathering crust of granite[J]. Chemical Geology, 2019, 525:210-217. DOI URL
[74]	MESTDAGH M M, VIELVOYE L L, HERBILLON A J. Iron in kaolinite: II. the relationship between kaolinite crystallinity and iron content[J]. Clay Minerals, 1980, 15(1):1-13. DOI URL
[75]	ALSHAMERI A, HE H P, CHEN X, et al. Understanding the role of natural clay minerals as effective adsorbents and alternative source of rare earth elements: adsorption operative parameters[J]. Hydrometallurgy, 2019, 185:149-161. DOI URL
[76]	QUINN K A, BYRNE R H, SCHIJF J. Sorption of yttrium and rare earth elements by amorphous ferric hydroxide: influence of pH and ionic strength[J]. Marine Chemistry, 2006, 99(1/2/3/4):128-150. DOI URL
[77]	HAFERBURG G, MERTEN D, BÜCHEL G, et al. Biosorption of metal and salt tolerant microbial isolates from a former uranium mining area: their impact on changes in rare earth element patterns in acid mine drainage[J]. Journal of Basic Microbiology, 2007, 47(6):474-484. DOI URL
[78]	MULLEN M D, WOLF D C, FERRIS F G, et al. Bacterial sorption of heavy metals[J]. Applied and Environmental Microbiology, 1989, 55(12):3143-3149. DOI URL
[79]	KAMIJO M, SUZUKI T, KAWAI K, et al. Accumulation of yttrium by variovorax paradoxus[J]. Journal of Fermentation and Bioengineering, 1998, 86(6):564-568. DOI URL
[80]	PALMIERI M C, GARCIA O, MELNIKOV P. Neodymium biosorption from acidic solutions in batch system[J]. Process Biochemistry, 2000, 36(5):441-444. DOI URL
[81]	MERROUN M L, BEN CHEKROUN K, ARIAS J M, et al. Lanthanum fixation by Myxococcus Xanthus: cellular location and extracellular polysaccharide observation[J]. Chemosphere, 2003, 52(1):113-120. DOI URL
[82]	MARKAI S, ANDRÈS Y, MONTAVON G, et al. Study of the interaction between europium (Ⅲ) and Bacillus subtilis: fixation sites, biosorption modeling and reversibility[J]. Journal of Colloid and Interface Science, 2003, 262(2):351-361. DOI URL
[83]	MORGAN J W, FORSTER C F, EVISON L. A comparative study of the nature of biopolymers extracted from anaerobic and activated sludges[J]. Water Research, 1990, 24(6):743-750. DOI URL
[84]	YOSHIDA T, OZAKI T, OHNUKI T, et al. Adsorption of rare earth elements by γ-Al₂O₃ and pseudomonas fluorescens cells in the presence of desferrioxamine B: implication of siderophores for the Ce anomaly[J]. Chemical Geology, 2004, 212(3/4):239-246. DOI URL
[85]	OHTA A, KAWABE I. REE(Ⅲ) adsorption onto Mn dioxide (δ-MnO₂) and Fe oxyhydroxide: Ce(Ⅲ) oxidation by δ-MnO₂[J]. Geochimica et Cosmochimica Acta, 2001, 65(5):695-703. DOI URL
[86]	OHTA A, KAGI H, NOMURA M, et al. Coordination study of rare earth elements on Fe oxyhydroxide and Mn dioxides: Part I. Influence of a multi-electron excitation on EXAFS analyses of La, Pr, Nd, and Sm[J]. American Mineralogist, 2009, 94(4):467-475. DOI URL
[87]	KOEPPENKASTROP D, DE CARLO E H. Sorption of rare-earth elements from seawater onto synthetic mineral particles: an experimental approach[J]. Chemical Geology, 1992, 95(3/4):251-263. DOI URL
[88]	OHTA A, KAWABE I. Theoretical study of tetrad effects observed in REE distribution coefficients between marine Fe-Mn deposit and deep seawater, and in REE(Ⅲ)-carbonate complexation constants[J]. Geochemical Journal, 2000, 34(6):455-473. DOI URL
[89]	JOHANNESSON K H, LYONS W B, YELKEN M A, et al. Geochemistry of the rare-earth elements in hypersaline and dilute acidic natural terrestrial waters: complexation behavior and middle rare-earth element enrichments[J]. Chemical Geology, 1996, 133(1/2/3/4):125-144. DOI URL
[90]	DAVRANCHE M, POURRET O, GRUAU G, et al. Impact of humate complexation on the adsorption of REE onto Fe oxyhydroxide[J]. Journal of Colloid and Interface Science, 2004, 277(2):271-279. DOI URL
[91]	LEE J H, BYRNE R H. Examination of comparative rare earth element complexation behavior using linear free-energy relationships[J]. Geochimica et Cosmochimica Acta, 1992, 56(3):1127-1137. DOI URL
[92]	LIU X W, BYRNE R H. Rare earth and yttrium phosphate solubilities in aqueous solution[J]. Geochimica et Cosmochimica Acta, 1997, 61(8):1625-1633. DOI URL
[93]	TAKAHASHI Y, CHÂTELLIER X, HATTORI K H, et al. Adsorption of rare earth elements onto bacterial cell walls and its implication for REE sorption onto natural microbial mats[J]. Chemical Geology, 2005, 219(1/2/3/4):53-67. DOI URL
[94]	LI M YH, ZHOU M F, WILLIAMS-JONES A E. Controls on the dynamics of rare earth elements during subtropical hillslope processes and formation of regolith-hosted deposits[J]. Economic Geology, 2020, 115(5):1097-1118. DOI URL
[95]	TESSIER A, CAMPBELL P G C, BISSON M. Particulate trace-metal speciation in stream sediments and relationships with grain-size: implications for geochemical exploration[J]. Journal of Geochemical Exploration, 1982, 16(2):77-104. DOI URL
[96]	SUTHERLAND R A. BCR©-701: a review of 10-years of sequential extraction analyses[J]. Analytica Chimica Acta, 2010, 680(1/2):10-20. DOI URL
[97]	范晨子, 张誉, 陈郑辉, 等. 江西赣南风化淋滤型稀土矿床中的黏土矿物研究[J]. 岩石矿物学杂志, 2015, 34(6):803-810.
[98]	周军明, 袁鹏, 余亮, 等. 八尺风化淋积型稀土矿凝灰岩风化壳中的细粒矿物特征[J]. 矿物学报, 2018, 38(4):420-428.
[99]	刘楠, 王宏伟. 单颗粒冷冻电镜技术的研究现状和未来展望[J]. 中国基础科学, 2019, 21(5):1-7.
[100]	LIAO J L, SUN X M, LI D F, et al. New insights into nanostructure and geochemistry of bioapatite in REE-rich deep-sea sediments: LA-ICP-MS, TEM, and Z-contrast imaging studies[J]. Chemical Geology, 2019, 512:58-68. DOI URL
[101]	刘容, 王汝成, 陆现彩, 等. 赣南花岗岩风化壳型稀土矿床中纳米级稀土矿物的研究[J]. 岩石矿物学杂志, 2016, 35(4):617-626
[102]	BORST A M, SMITH M P, FINCH A A, et al. Adsorption of rare earth elements in regolith-hosted clay deposits[J]. Nature Communications, 2020, 11:4386. DOI URL
[103]	ELZINGA E J, REEDER R J, WITHERS S H, et al. EXAFS study of rare-earth element coordination in calcite[J]. Geochimica et Cosmochimica Acta, 2002, 66(16):2875-2885. DOI URL

基岩类型	岩性	(含)稀土矿物	典型矿床
花岗岩类	黑/白云母花岗岩	独居石、氟碳钙钇矿、硅钍钇矿、锆石、磷灰石、磷钇矿、钛铁矿、烧绿石等	江西省足洞矿区^[5]
	花岗闪长岩	独居石、锆石、磷灰石等	赣南清溪岩体稀土矿区^[14]
	石英正长/二长岩	独居石、榍石、锆石、磁铁矿、钛铁矿等	福建龙岩万安稀土矿区^[15]
	花岗斑岩	独居石、褐帘石、磁铁矿、磷灰石、锆石等	广东省仁居矿区^[16]
变质岩类	板岩	独居石、磷钇矿、锆石、含稀土钛铁矿、含稀土金红石	江西宁都葛藤嘴地区^[17,18]
	千枚岩	独居石、磷钇矿、锆石、含稀土钛铁矿
	片岩	独居石、磷钇矿、锆石、含稀土钛铁矿、磷铝酸盐类、褐帘石
	变砂岩	独居石、磷钇矿、锆石、磷铝酸盐、水磷酸盐、褐帘石
	变质凝灰岩	独居石、磷钇矿、锆石、含稀土金红石、含稀土绿泥石、含稀土钍石、方铈石
	变粒岩	独居石、磷钇矿、锆石、含稀土绿泥石
火山岩类	流纹岩/英安岩	独居石、磷钇矿、锆石、磷灰石等	江西省寻乌河岭矿区^[19]
碱性岩类	碱性正长岩	独居石、磷钇矿、烧绿石、水磷镧石、水磷铈石、水菱钇矿、氟碳镧矿等	云南省建水普雄铌稀土矿^[20]

基岩类型	岩性	(含)稀土矿物	典型矿床
花岗岩类	黑/白云母花岗岩	独居石、氟碳钙钇矿、硅钍钇矿、锆石、磷灰石、磷钇矿、钛铁矿、烧绿石等	江西省足洞矿区^[5]
	花岗闪长岩	独居石、锆石、磷灰石等	赣南清溪岩体稀土矿区^[14]
	石英正长/二长岩	独居石、榍石、锆石、磁铁矿、钛铁矿等	福建龙岩万安稀土矿区^[15]
	花岗斑岩	独居石、褐帘石、磁铁矿、磷灰石、锆石等	广东省仁居矿区^[16]
变质岩类	板岩	独居石、磷钇矿、锆石、含稀土钛铁矿、含稀土金红石	江西宁都葛藤嘴地区^[17,18]
	千枚岩	独居石、磷钇矿、锆石、含稀土钛铁矿
	片岩	独居石、磷钇矿、锆石、含稀土钛铁矿、磷铝酸盐类、褐帘石
	变砂岩	独居石、磷钇矿、锆石、磷铝酸盐、水磷酸盐、褐帘石
	变质凝灰岩	独居石、磷钇矿、锆石、含稀土金红石、含稀土绿泥石、含稀土钍石、方铈石
	变粒岩	独居石、磷钇矿、锆石、含稀土绿泥石
火山岩类	流纹岩/英安岩	独居石、磷钇矿、锆石、磷灰石等	江西省寻乌河岭矿区^[19]
碱性岩类	碱性正长岩	独居石、磷钇矿、烧绿石、水磷镧石、水磷铈石、水菱钇矿、氟碳镧矿等	云南省建水普雄铌稀土矿^[20]

(含)稀土矿物	微生物菌种	参考文献
三水铝石	嗜酸氧化亚铁硫杆菌(Acidithiobacillus ferrooxidans)	[36]
氟碳铈矿	链霉菌属(Streptomyces sp.)	[37]
	微球菌属(Micrococcus sp.)
	小单孢菌属(Micromonospora sp.)
独居石	曲霉菌属(Aspergillus sp.)	[38]
	假单胞菌属(Pseudomonas sp.)	[34]
	芽孢杆菌属(Bacillus sp.)	[39]
	产气肠杆菌(Enterobacter aerogenes)	[40]
	拟青霉属(Paecilomyces sp.)	[41]
	醋杆菌属(Acetobacter sp.)	[39]
	嗜酸氧化亚铁硫杆菌(Acidithiobacillus ferrooxidans)	[42]
锆石	嗜酸硫杆菌属(Acidithiobacillus sp.)	[43]
锆石	甲醇醋杆菌(Acetobacter methanolicus)	[44]

(含)稀土矿物	微生物菌种	参考文献
三水铝石	嗜酸氧化亚铁硫杆菌(Acidithiobacillus ferrooxidans)	[36]
氟碳铈矿	链霉菌属(Streptomyces sp.)	[37]
	微球菌属(Micrococcus sp.)
	小单孢菌属(Micromonospora sp.)
独居石	曲霉菌属(Aspergillus sp.)	[38]
	假单胞菌属(Pseudomonas sp.)	[34]
	芽孢杆菌属(Bacillus sp.)	[39]
	产气肠杆菌(Enterobacter aerogenes)	[40]
	拟青霉属(Paecilomyces sp.)	[41]
	醋杆菌属(Acetobacter sp.)	[39]
	嗜酸氧化亚铁硫杆菌(Acidithiobacillus ferrooxidans)	[42]
锆石	嗜酸硫杆菌属(Acidithiobacillus sp.)	[43]
锆石	甲醇醋杆菌(Acetobacter methanolicus)	[44]
