扬子板块新元古代中期的持续俯冲作用:来自南华纪岛弧火山岩年代学和岩石地球化学新证据

doi:10.13745/j.esf.sf.2020.4.27

摘要/Abstract

摘要：

产于扬子板块东南缘皖南祁门北部地区的铺岭组和扬子板块东北缘皖东张八岭地区的西冷岩组分别发育一套火山岩。前者为陆相火山岩,岩性以玄武安山岩为主;后者为海相火山岩,岩性以细碧-角斑岩系为主。两者之上均角度不整合覆盖着一套砂泥质沉积岩。铺岭组玄武安山岩LA-ICP-MS锆石U-Pb年龄为(765±15) Ma,西冷岩组石英角斑岩LA-ICP-MS锆石U-Pb年龄为(726.8±1.4) Ma,均属南华纪(新元古代中期)。二者主量元素含量差别较大(铺岭组为玄武-安山岩;西冷岩组为石英角斑岩),但它们均属于钙碱性系列,并具有相似的微量元素特征:它们均富集轻稀土元素和Ba、Th、U等大离子亲石元素,高场强元素Nb、Ta、Ti强烈亏损,δEu、Zr、Hf异常不明显。这些特征显示它们与岛弧火山岩类似,可能是受俯冲板片流体影响的亏损地幔楔和新生地壳熔体的混合形成的。这些火山岩系形成于华夏向扬子俯冲形成的沟弧盆体系消失之后。结合前人研究成果,我们认为:扬子板块晋宁期深部的俯冲作用可能一直持续到约700 Ma,新元古代中期可能存在多岛弧拼贴过程,到了南华纪晚期才正式进入板内伸展阶段。

关键词: 南华纪, 岛弧火山岩, 俯冲作用, 多岛弧, 扬子板块

Abstract:

The Puling Formation in the northern Qimen area on the southeastern margin of the Yangtze Plate, and the Xileng Formation in the Zhangbaling area on the northeastern margin of the Yangtze Plate, each developed a suite of volcanic rocks. The former is continental volcanic rocks with basalt-andesite series, and the latter is marine volcanic rocks with spilite-keratophyre series. The volcanic rocks are unconformities covered with sand mudstone sedimentary. The LA-ICP-MS zircon U-Pb age of basalt-andesite from the Puling Formation is 765±15 Ma, while quartz keratophyre from the Xileng Formation is 726.8±1.4 Ma, indicating they are formed in the Nanhua Period (Middle Neoproterozoic) after the disappearance of the “trench-arc-basin system” formed by the subduction of the Cathaysian to the Yangtze Plate in the Neoproterozoic. The whole rock geochemical analysis showed that the major elemental contents of the two volcanic rocks were quite different, but they all belonged to calc-alkaline series, and with similar trace elemental characteristics: they were enriched in LREE and large ion lithophile elements (e.g., Ba, Th, U), strongly depleted in high field strength elements (e.g., Nb, Ta, Ti), with inconspicuous δEu, Zr and Hf anomalies. These features suggest that they are similar to island arc volcanic rocks and possibly formed by the mixing of the depleted mantle wedges metasomatized by subduction-related fluids and melt of new crust. Combined with previous research results, we consider the deep subduction in the Jinning period might have lasted until ca. 700 Ma, affected by a multi-island arc collage process in the Middle Neoproterozoic, and then this area entered an intra-plate extension stage until the late Nanhua Period.

Key words: Nanhua Period, island arc volcanic rocks, subduction, multi-island arc, Yangtze Plate

中图分类号:

朱强, 施珂, 吴礼彬, 江来利, 胡召齐, 徐生发, 翁望飞. 扬子板块新元古代中期的持续俯冲作用:来自南华纪岛弧火山岩年代学和岩石地球化学新证据[J]. 地学前缘, 2020, 27(4): 17-32.

ZHU Qiang, SHI Ke, WU Libin, JIANG Laili, HU Zhaoqi, XU Shengfa, WENG Wangfei. Continued subduction of the Yangtze Plate in the Middle Neoproterozoic: new evidence based on the geochronology and petro-geochemistry of island arc volcanic rocks in the Nanhua Period[J]. Earth Science Frontiers, 2020, 27(4): 17-32.

图/表 18

参考文献 71

[1]	ZHOU M F, KENNEDY A K, SUN M, et al. Neo-proterozoic arc-related mafic intrusions in the northern margin of South China: implications for accretion of Rodinia[J]. Journal of Geology, 2002, 110:611-618. DOI URL
[2]	ZHOU M F, YAN D P, KENNEDY A K, et al. SHRIMP zircon geochronological and geochemical evidence for Neo-proterozoic arc-related magmatism along the western margin of the Yangtze Block, South China[J]. Earth and Planetary Science Letters, 2002, 196:51-67.
[3]	ZHOU M F, MA Y X, YAN D P, et al. The Yanbian Terrane (southern Sichuan Province, SW China): a Neoproterozoic arc assemblage in the western margin of the Yangtze Block[J]. Precambrian Research, 2006, 144:19-38. DOI URL
[4]	ZHOU M F, YAN D P, WANG C Q, et al. Subduction-related origin of the 750 Ma Xuelongbao adakitic complex (Sichuan Province, China): implications for the tectonic setting of the giant Neoproterozoic magmatic event in South China[J]. Earth and Planetary Science Letters, 2006, 248:271-285.
[5]	LING W L, GAO S, ZHANG B R, et al. Neoproterozoic tectonic evolution of the northwestern Yangtze Craton, South China: implications for amalgamation and break-up of the Rodinia Supercontinent[J]. Precambrian Research, 2003, 122:111-140. DOI URL
[6]	LING W L, REN B F, DUAN R C, et al. Timing of the Wudangshan, Yaolinghe volcanic sequences and mafic sills in South Qinling: U-Pb zircon geochronology and tectonic implication[J]. Chinese Science Bulletin, 2008, 53:2192-2199.
[7]	杨钊, 董云鹏, 周鼎武, 等. 南秦岭柞水地区小磨岭杂岩基性岩类的地球化学特征及其地质意义[J]. 地质通报, 2008, 27(5):611-617.
[8]	DONG Y P, LIU X M, SANTOSH M, et al. Neoproterozoic subduction tectonics of the northwestern Yangtze Block in South China: constraints from zircon U-Pb geochronology and geochemistry of mafic intrusions in the Hannan Massif[J]. Precambrian Research, 2011, 189:66-90. DOI URL
[9]	DONG Y P, LIU X M, SANTOSH M, et al. Neoproterozoic accretionary tectonics along the northwestern margin of the Yangtze Block, China: constraints from zircon U-Pb geochronology and geochemistry[J]. Precambrian Research, 2012, 196/197:247-274. DOI URL
[10]	DONG Y P, SUN S S, YANG Z, et al. Neoproterozoic subduction-accretionary tectonics of the South Qinling Belt, China[J]. Precambrian Research, 2017, 293:73-90. DOI URL
[11]	ZHU X Y, CHEN F K, NIE H, et al. Neoproterozoic tectonic evolution of South Qinling, China: evidence from zircon ages and geochemistry of the Yaolinghe volcanic rocks[J]. Precambrian Research, 2014, 245:115-130. DOI URL
[12]	HU F Y, LIU S W, SANTOSH M, et al. Chronology and tectonic implications of Neoproterozoic blocks in the South Qinling Orogenic Belt, Central China[J]. Gondwana Research, 2016, 30:24-47. DOI URL
[13]	王建其, 杨钊, 董云鹏, 等. 南秦岭城口火山岩锆石 LA-ICP-MS U-Pb定年和地球化学研究[J]. 地质论评, 2016, 62(2):492-499.
[14]	徐通, 裴先治, 李瑞保, 等. 南秦岭勉略构造带黑沟峡火山岩年代学及地球化学特征: 新元古代勉略洋盆存在及俯冲的记录[J]. 地质论评, 2017, 63(2):376-390.
[15]	赖绍聪, 朱韧之. 四川泸定地区新元古代火山岩地球化学特征及其大陆动力学意义[J]. 地球科学与环境学报, 2017, 39(4):460-471.
[16]	王孝磊, 周金城, 陈昕, 等. 江南造山带的形成与演化[J]. 矿物岩石地球化学通报, 2017, 36(5):715-727.
[17]	董学发, 余盛强, 唐增才, 等. 浙江“陈蔡增生杂岩”中洋内弧型变基性火山岩的地球化学特征及其地质意义[J]. 中国地质, 2016, 43(3):818-836.
[18]	郭坤一, 王迎平. 张八岭变质地体细碧角斑岩系岩石学和岩石化学[J]. 火山地质与矿产, 1995, 16(4):25-34.
[19]	WANG X L, SHU L S, XING G F, et al. Post-orogenic extension in the eastern part of the Jiangnan orogen: evidence from ca 800-760 Ma volcanic rocks[J]. Precambrian Research, 2012, 222/223:404-423. DOI URL
[20]	LI L M, LIN S F, XING G F, et al. Ca. 830 Ma back-arc type volcanic rocks in the eastern part of the Jiangnan orogen: implications for the Neoproterozoic tectonic evolution of South China Block[J]. Precambrian Research, 2016, 275:209-224.
[21]	ANDERSEN T. Correction of common lead in U-Pb analyses that do not report ²⁰⁴Pb[J]. Chemical Geology, 2002, 192:59-79. DOI URL
[22]	WILISON B M. Igneous petrogenesis: a global tectonic approach[M]. Dordrecht: Springer, 1989.
[23]	SUN S S, MCDONOUGH W F. Chemical and isotopic systematics of oceanic basalts: implications for mantle composition and processes[J]. Geological Society, London, Special Publication, 1989, 42(1):313-345. DOI URL
[24]	王金荣, 陈万峰, 张旗, 等. N-MORB和E-MORB数据挖掘: 玄武岩判别图及洋中脊源区地幔性质的讨论[J]. 岩石学报, 2017, 33(3):994-1003.
[25]	陈万峰, 王金荣, 张旗, 等. 洋岛和洋底高原玄武岩数据挖掘: 地球化学特征及其与MORB的对比[J]. 地质学报, 2017, 91(11):2443-2453.
[26]	杨婧, 王金荣, 张旗, 等. 弧后盆地玄武岩 (BABB) 数据挖掘: 与MORB及IAB的对比[J]. 地球科学进展, 2016, 31(1):66-77.
[27]	王金荣, 潘振杰, 张旗, 等. 大陆板内玄武岩数据挖掘: 成分多样性及在判别图中的表现[J]. 岩石学报, 2016, 32(7):1919-1933.
[28]	CAMPBELL I H, GRIFFITHS R W. The evolution of the mantle's chemical structure[J]. Lithos, 1993, 30(3/4):389-399. DOI URL
[29]	MACDONALD R, ROGERS N W, FITTON J G, et al. Plume-lithosphere interactions in the generation of the basalts of the Kenya Rift, East Africa[J]. Journal of Petrology, 2001, 42(5):877-900. DOI URL
[30]	KIEFFER B, ARNDT N, LAPIERRE H, et al. Flood and shield basalts from Ethiopia: magmas from the African Superswell[J]. Journal of Petrology, 2004, 45(4):793-834. DOI URL
[31]	ZHAO J H, ZHOU M F. Geochemistry of Neoproterozoic mafic intrusions in the Panzhihua district (Sichuan Province, SW China): implications for subduction-related metasomatism in the upper mantle[J]. Precambrian Research, 2007, 152:27-47. DOI URL
[32]	NEAL C R, MAHONEY J J, CHAZEY W J. Mantle sources and the highly variable role of continental lithosphere in basalt petrogenesis of the Kerguelen Plateau and Broken Ridge LIP: results from ODP Leg 183[J]. Journal of Petrology, 2002, 43(5):1177-1205. DOI URL
[33]	TARNEY J, JONES C E. Trace element geochemistry of orogenic igneous rocks and crustal growth models[J]. Journal of the Geological Society, 1994, 151(5):855-868. DOI URL
[34]	LIEGEOIS J P, NAVEZ J, HERTOGEN J, et al. Contrasting origin of post-collisional high-K calc-alkaline and shoshonitic versus alkaline and peralkaline granitoids. The use of sliding normalization[J]. Lithos, 1998, 45(1/2/3/4):1-28. DOI URL
[35]	WILSON M. Igneous petrogenesis[M]. London: Unwin Hyman, 1989: 1-466.
[36]	THOMPSON R N, MPRRISON M A, Hendry G L, et al. An assessment of the relative roles of crust and mantle in magma genesis: an elemental approach[J]. Philosophical Transactions of the Royal Society of London, 1984, 310(1514):549-590.
[37]	ERNST R E, BUCHAN K L, CAMPBELL I H. Frontiers in large igneous province research[J]. Lithos, 2005, 79(3/4):271-297. DOI URL
[38]	HANDLEY H K, MACPHERSON C G, DAVIDSON J P, et al. Constraining fluid and sediment contributions to subduction related magmatism in Indonesia: Ijen volcanic complex[J]. Journal of Petrology, 2007, 48(6):1155-1183. DOI URL
[39]	GREEN T H. Significance of Nb/Ta as an indicator of geochemical processes in the crust-mantle system[J]. Chemical Geology, 1995, 120(3/4):347-359. DOI URL
[40]	TAYLOR S R, MCLENNAN S M. The composition and evolution of the continental crust: rare earth element evidence from sedimentary rocks[J]. Philosophical Transactions of the Royal Society of London, 1981, 301(1416):381-399.
[41]	FITTON J G, SAUNDERS A D, NORRY M J, et al. Thermal and chemical structure of the Iceland plume[J]. Earth and Planetary Science Letters, 1997, 153(3/4):197-208. DOI URL
[42]	BAKSI A K. Search for a deep-mantle component in mafic lavas using a Nb-Y-Zr plot[J]. Canadian Journal of Earth Sciences, 2001, 38(5):813-824.
[43]	RUDNICK R L, GAO S. Composition of the continental crust[J]. Treatise on Geochemistry, 2003, 3:1-64.
[44]	PEARCE J A. Role of sub-continental lithosphere in magma genesis at active continental margins[M]// HAWKESWORTH C J, NORRY M J. Continental basalts and mantle Xenoliths. Nantwich, Cheshire: Shiva Publications, 1983: 230-249.
[45]	ZHAO G C, CAWOOD P A. Tectonothermal evolution of the Mayuan assemblage in the Cathaysia Block: implications for Neoproterozoic collision-related assembly of the South China craton[J]. American Journal of Science, 1999, 299(4):309-339. DOI URL
[46]	LI X H, LI Z X, GE W C, et al. Neoproterozoic granitoids in South China: crustal melting above a mantle plume at ca. 825 Ma?[J]. Precambrian Research, 2003, 122:45-83. DOI URL
[47]	LI X H, LI W X, LI Z X, et al. 850-790 Ma bimodal volcanic and intrusive rocks in northern Zhejiang, South China: a major episode of continental rift magmatism during the breakup of Rodinia[J]. Lithos, 2008, 102:341-357. DOI URL
[48]	LI X H, LI W X, LI Z X, et al. Amalgamation between the Yangtze and Cathaysia Blocks in South China: constraints from SHRIMP U-Pb zircon ages, geochemistry and Nd-Hf isotopes of the Shuangxiwu volcanic rocks[J]. Precambrian Research, 2009, 174:117-128. DOI URL
[49]	LI Z X, ZHANG L H, POWELL C M. et al. South China in Rodinia: part of the missing link between Australia-East Antarctica and Laurentia?[J]. Geology, 1993, 23:407-410. DOI URL
[50]	LI Z X, LI X H, ZHOU H W, et al. Grenvillian continental collision in south China: new SHRIMP U-Pb zircon results and implications for the configuration of Rodinia[J]. Geology, 2002, 30:163-166. DOI URL
[51]	LI Z X, LI X H, KINNY P D, et al. Geochronology of Neoproterozoic syn-rift magmatism in the Yangtze Craton, South China and correlations with other continents: evidence for a mantle superplume that broke up Rodinia[J]. Precambrian Research, 2003, 122:85-109. DOI URL
[52]	LI Z X, LI X H, WARTHOL J A, et al. Magmatic and metamorphic events during the early Paleozoic Wuyi-Yunkai orogeny, southeastern South China: new age constraints and pressure-temperature conditions[J]. Geological Society American Bulletin, 2010, 122:772-793. DOI URL
[53]	LING H F, SHEN W Z, WANG R C, et al. Geochemical characteristics and genesis of Neoproterozoic granitoids in the northwestern margin of the Yangtze block[J]. Physics and Chemistry of the Earth, Part A: Solid Earth and Geodesy, 2001, 26(9/10):805-819. DOI URL
[54]	ZHOU M F, ZHAO T F, MALPAS J, et al. Crustal-contaminated komatiitic basalts in Southern China: products of a Proterozoic mantle plume beneath the Yangtze Block[J]. Precambrian Research, 2000, 103:175-189. DOI URL
[55]	ZHOU M F, ZHAO J H, XIA X P, et al. Comment on “Revisiting the “Yanbian Terrane”: implications for Neoproterozoic tectonic evolution of the western Yangtze Block, South China”[J]. Precambrian Research, 2007, 155:313-317. DOI URL
[56]	ZHOU M F, KENNEDY A K, SUN M, et al. Neoproterozoic arc-related mafic intrusions along the northern margin of South China: implications for the accretion of Rodinia[J]. The Journal of Geology, 2002, 110(5):611-618. DOI URL
[57]	ZHOU M F, YAN D P, KENNEDY A K, et al. SHRIMP U-Pb zircon geochronological and geochemical evidence for Neoproterozoic arc-magmatism along the western margin of the Yangtze Block, South China[J]. Earth and Planetary Science Letters, 2002, 196(1/2):51-67. DOI URL
[58]	周金城, 王孝磊, 邱检生, 等. 桂北中—新元古代镁铁质-超镁铁质岩的岩石地球化学[J]. 岩石学报, 2003, 19(1):9-18.
[59]	周金城, 王孝磊, 邱检生, 等. 南桥高度亏损 N-MORB的发现及其地质意义[J]. 岩石矿物学杂志, 2003, 22(3):211-216.
[60]	WANG X L, ZHAO G C, ZHOU J C, et al. Geochronology and Hf isotopes of zircon from volcanic rocks of the Shuang-qiaoshan Group, South China: implications for the Neoproterozoic tectonic evolution of the eastern Jiangnan orogen[J]. Gondwana Research, 2008, 14(3):355-367. DOI URL
[61]	WANG X L, ZHOU J C, GRIFFIN W L, et al. Detrital zircon geochronology of Precambrian basement sequences in the Jiangnan orogen: dating the assembly of the Yangtze and Cathaysia blocks[J]. Precambrian Research, 2007, 159(1/2):117-131. DOI URL
[62]	WANG X L, ZHOU J C, GRIFFIN W L, et al. Geochemical zonation across a Neoproterozoic orogenic belt: isotopic evidence from granitoids and metasedimentary rocks of the Jiangnan orogen, China[J]. Precambrian Research, 2014, 242:154-171. DOI URL
[63]	WANG X L, ZHOU J C, QIU J S, et al. Geochemistry of the Meso-to Neoproterozoic basic-acid rocks from Hunan Province, South China: implications for the evolution of the western Jiangnan orogen[J]. Precambrian Research, 2004, 135(1/2):79-103. DOI URL
[64]	WANG X L, ZHOU J C, QIU J S, et al. Geochronology and geochemistry of Neoproterozoic mafic rocks from western Hunan, South China: implications for petrogenesis and post-orogenicextension[J]. Geological Magazine, 2008, 145(2):215-233.
[65]	WANG X L, ZHOU J C, QIU J S, et al. LA-ICP-MS U-Pb zircon geochronology of the Neoproterozoic igneous rocks from Northern Guangxi, South China: implications for tectonic evolution[J]. Precambrian Research, 2006, 145(1/2):111-130. DOI URL
[66]	WANG X L, ZHOU J C, WAN Y S, et al. Magmatic evolution and crustal recycling for Neoproterozoic strongly peraluminous granitoids from southern China: Hf and O isotopes in zircon[J]. Earth and Planetary Science Letters, 2013, 366:71-82. DOI URL
[67]	ZHENG Y F, WU Y B, CHEN F K, et al. Zircon U-Pb and oxygen isotope evidence for a large-scale ¹⁸O depletion event in igneous rocks during the Neoproterozoic[J]. Geochimica et Cosmochimica Acta, 2004, 68(20):4145-4165.
[68]	ZHENG Y F, ZHANG S B, ZHAO Z F, et al. Contrasting zircon Hf and O isotopes in the two episodes of Neoproterozoic granitoids in South China: implications for growth and reworking of continental crust[J]. Lithos, 2007, 96(1/2):127-150. DOI URL
[69]	ZHENG Y F. Position of South China in configuration of Neoproterozoic supercontinent[J]. Chinese Science Bulletin, 2004, 49(8):751-753.
[70]	CUI X, ZHU W B, FITZSIMONS I C W, et al. U-Pb age and Hf isotope composition of detrital zircons from Neoproterozoic sedimentary units in southern Anhui Province, South China: implications for the provenance, tectonic evolution and glacial history of the eastern Jiangnan Orogen[J]. Precambrian Research, 2016, 271:65-82. DOI URL
[71]	XIANG Z J, YAN Q R, WHITE J D L, et al. Geochemical constraints on the provenance and depositional setting of Neoproterozoic volcaniclastic rocks on the northern margin of the Yangtze Block, China: implications for the tectonic evolution of the northern margin of the Yangtze Block[J]. Precambrian Research, 2015, 264:140-155.

样品测点	w_B/10^-6			Th/U	同位素比值及误差				同位素年龄及误差/Ma
样品测点	Pb	²³²Th	²³⁸U	Th/U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁶Pb/²³⁸U	1σ
121001-3
1	55	145	93	1.56	0.126 0	0.002 0	0.376 1	0.007 0	2 044	20	2 058	33
2	15	48	79	0.60	0.085 2	0.002 3	0.151	0.002 8	1 320	41	907	16
3	14	58	92	0.63	0.063 9	0.001 5	0.124 8	0.002 2	738	32	758	13
4	17	71	101	0.71	0.067 8	0.001 5	0.133 8	0.002 4	864	33	810	13
5	46	84	86	0.98	0.123 8	0.002 0	0.383 3	0.006 9	2 011	20	2 092	32
6	56	112	398	0.28	0.064 9	0.001 1	0.123 2	0.002 1	772	24	749	12
7	44	93	77	1.20	0.125 1	0.002 1	0.384 0	0.006 9	2 031	20	2 095	32
8	30	141	173	0.81	0.067 8	0.001 2	0.131 0	0.002 3	863	25	794	13
9	42	106	265	0.40	0.064 4	0.001 2	0.130 8	0.002 4	755	22	792	14
10	20	57	133	0.43	0.065 6	0.001 4	0.124 1	0.002 2	795	25	754	13
11	32	130	179	0.73	0.066 2	0.001 3	0.135 8	0.002 5	814	24	821	14
12	55	375	304	1.23	0.073 4	0.001 3	0.121 2	0.002 1	1 026	18	737	12
13	23	31	151	0.21	0.064 3	0.001 2	0.129 7	0.002 3	753	22	786	13
14	29	54	53	1.02	0.123 0	0.002 1	0.382 8	0.007 1	2 001	17	2 089	33
15	21	80	134	0.59	0.063 4	0.001 5	0.121 6	0.002 2	722	26	740	13
16	30	133	181	0.74	0.068 1	0.001 5	0.121 7	0.002 2	873	27	740	13
17	24	7	45	0.15	0.147 5	0.002 7	0.451 7	0.008 7	2 317	20	2 403	39
18	84	187	544	0.34	0.067 3	0.001 1	0.131 3	0.002 4	847	22	795	14
19	19	101	114	0.89	0.083 8	0.002 8	0.119 3	0.002 4	1 287	41	726	14
20	10	61	55	1.11	0.076 9	0.002 0	0.125 1	0.002 3	1 118	33	760	13
21	23	84	106	0.79	0.068 4	0.001 4	0.153 8	0.003 0	880	27	922	17
22	51	92	290	0.32	0.090 7	0.003 9	0.123 0	0.002 2	1 441	61	748	13
23	37	227	237	0.96	0.067 4	0.001 4	0.121 5	0.002 1	849	23	739	12
24	187	210	348	0.60	0.160 3	0.002 3	0.396 8	0.007 4	2 459	14	2 154	34
25	131	1 555	486	3.20	0.074 5	0.001 5	0.129 2	0.002 3	1 054	20	783	13
150709-3
1	156	226	190	1.19	0.065 4	0.001 5	0.119 6	0.001 5	787	48	728	8
2	136	178	251	0.71	0.065 8	0.001 2	0.119 1	0.001 4	1 200	38	725	8
3	150	213	194	1.09	0.064 2	0.001 1	0.120 2	0.001 2	750	31	732	7
4	56	78	87	0.9	0.063 7	0.001 6	0.119 3	0.001 4	731	52	727	8
5	220	302	233	1.3	0.063 1	0.001 1	0.117 9	0.001 2	722	37	718	7
6	108	154	148	1.04	0.064 9	0.001 2	0.119 3	0.001 3	772	32	727	8
7	54	74	83	0.88	0.066 0	0.001 5	0.118 7	0.001 4	806	42	723	8
8	59	80	97	0.83	0.063 7	0.001 6	0.119 4	0.001 6	731	53	727	9
9	213	320	229	1.4	0.063 6	0.001 1	0.119 0	0.001 2	728	36	725	7
10	82	113	128	0.88	0.066 3	0.001 2	0.119 1	0.001 1	817	32	725	7
11	129	175	197	0.89	0.065 3	0.001 5	0.119 0	0.001 4	783	44	725	8
12	147	212	174	1.22	0.064 2	0.001 5	0.119 4	0.001 2	750	48	727	7
13	63	83	107	0.77	0.063 9	0.001 5	0.119 5	0.001 1	739	52	728	7
14	263	356	344	1.03	0.063 0	0.001 0	0.119 3	0.001 2	707	34	726	7
15	52	63	89	0.71	0.066 7	0.001 7	0.118 4	0.001 6	828	52	721	9
16	125	164	192	0.85	0.063 7	0.001 4	0.119 2	0.001 5	731	46	726	9
17	97	126	139	0.9	0.064 9	0.001 6	0.119 0	0.001 5	772	56	725	9
18	56	70	96	0.73	0.064 6	0.001 8	0.119 5	0.001 6	761	57	728	9
19	53	66	88	0.75	0.064 2	0.001 9	0.119 3	0.001 6	746	63	726	9
20	97	133	110	1.21	0.066 0	0.001 6	0.118 4	0.001 7	806	52	722	10
21	67	86	104	0.82	0.063 0	0.002 0	0.119 2	0.001 4	709	69	726	8
22	54	71	87	0.82	0.065 1	0.001 6	0.118 9	0.001 4	776	52	724	8
23	63	87	73	1.19	0.066 4	0.001 7	0.119 4	0.001 7	820	54	727	10
24	194	263	206	1.28	0.064 7	0.001 2	0.119 4	0.001 4	765	237	727	8
25	62	81	103	0.79	0.066 1	0.001 9	0.118 7	0.001 4	809	64	723	8

样品测点	w_B/10^-6			Th/U	同位素比值及误差				同位素年龄及误差/Ma
样品测点	Pb	²³²Th	²³⁸U	Th/U	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁶Pb/²³⁸U	1σ	²⁰⁷Pb/²⁰⁶Pb	1σ	²⁰⁶Pb/²³⁸U	1σ
121001-3
1	55	145	93	1.56	0.126 0	0.002 0	0.376 1	0.007 0	2 044	20	2 058	33
2	15	48	79	0.60	0.085 2	0.002 3	0.151	0.002 8	1 320	41	907	16
3	14	58	92	0.63	0.063 9	0.001 5	0.124 8	0.002 2	738	32	758	13
4	17	71	101	0.71	0.067 8	0.001 5	0.133 8	0.002 4	864	33	810	13
5	46	84	86	0.98	0.123 8	0.002 0	0.383 3	0.006 9	2 011	20	2 092	32
6	56	112	398	0.28	0.064 9	0.001 1	0.123 2	0.002 1	772	24	749	12
7	44	93	77	1.20	0.125 1	0.002 1	0.384 0	0.006 9	2 031	20	2 095	32
8	30	141	173	0.81	0.067 8	0.001 2	0.131 0	0.002 3	863	25	794	13
9	42	106	265	0.40	0.064 4	0.001 2	0.130 8	0.002 4	755	22	792	14
10	20	57	133	0.43	0.065 6	0.001 4	0.124 1	0.002 2	795	25	754	13
11	32	130	179	0.73	0.066 2	0.001 3	0.135 8	0.002 5	814	24	821	14
12	55	375	304	1.23	0.073 4	0.001 3	0.121 2	0.002 1	1 026	18	737	12
13	23	31	151	0.21	0.064 3	0.001 2	0.129 7	0.002 3	753	22	786	13
14	29	54	53	1.02	0.123 0	0.002 1	0.382 8	0.007 1	2 001	17	2 089	33
15	21	80	134	0.59	0.063 4	0.001 5	0.121 6	0.002 2	722	26	740	13
16	30	133	181	0.74	0.068 1	0.001 5	0.121 7	0.002 2	873	27	740	13
17	24	7	45	0.15	0.147 5	0.002 7	0.451 7	0.008 7	2 317	20	2 403	39
18	84	187	544	0.34	0.067 3	0.001 1	0.131 3	0.002 4	847	22	795	14
19	19	101	114	0.89	0.083 8	0.002 8	0.119 3	0.002 4	1 287	41	726	14
20	10	61	55	1.11	0.076 9	0.002 0	0.125 1	0.002 3	1 118	33	760	13
21	23	84	106	0.79	0.068 4	0.001 4	0.153 8	0.003 0	880	27	922	17
22	51	92	290	0.32	0.090 7	0.003 9	0.123 0	0.002 2	1 441	61	748	13
23	37	227	237	0.96	0.067 4	0.001 4	0.121 5	0.002 1	849	23	739	12
24	187	210	348	0.60	0.160 3	0.002 3	0.396 8	0.007 4	2 459	14	2 154	34
25	131	1 555	486	3.20	0.074 5	0.001 5	0.129 2	0.002 3	1 054	20	783	13
150709-3
1	156	226	190	1.19	0.065 4	0.001 5	0.119 6	0.001 5	787	48	728	8
2	136	178	251	0.71	0.065 8	0.001 2	0.119 1	0.001 4	1 200	38	725	8
3	150	213	194	1.09	0.064 2	0.001 1	0.120 2	0.001 2	750	31	732	7
4	56	78	87	0.9	0.063 7	0.001 6	0.119 3	0.001 4	731	52	727	8
5	220	302	233	1.3	0.063 1	0.001 1	0.117 9	0.001 2	722	37	718	7
6	108	154	148	1.04	0.064 9	0.001 2	0.119 3	0.001 3	772	32	727	8
7	54	74	83	0.88	0.066 0	0.001 5	0.118 7	0.001 4	806	42	723	8
8	59	80	97	0.83	0.063 7	0.001 6	0.119 4	0.001 6	731	53	727	9
9	213	320	229	1.4	0.063 6	0.001 1	0.119 0	0.001 2	728	36	725	7
10	82	113	128	0.88	0.066 3	0.001 2	0.119 1	0.001 1	817	32	725	7
11	129	175	197	0.89	0.065 3	0.001 5	0.119 0	0.001 4	783	44	725	8
12	147	212	174	1.22	0.064 2	0.001 5	0.119 4	0.001 2	750	48	727	7
13	63	83	107	0.77	0.063 9	0.001 5	0.119 5	0.001 1	739	52	728	7
14	263	356	344	1.03	0.063 0	0.001 0	0.119 3	0.001 2	707	34	726	7
15	52	63	89	0.71	0.066 7	0.001 7	0.118 4	0.001 6	828	52	721	9
16	125	164	192	0.85	0.063 7	0.001 4	0.119 2	0.001 5	731	46	726	9
17	97	126	139	0.9	0.064 9	0.001 6	0.119 0	0.001 5	772	56	725	9
18	56	70	96	0.73	0.064 6	0.001 8	0.119 5	0.001 6	761	57	728	9
19	53	66	88	0.75	0.064 2	0.001 9	0.119 3	0.001 6	746	63	726	9
20	97	133	110	1.21	0.066 0	0.001 6	0.118 4	0.001 7	806	52	722	10
21	67	86	104	0.82	0.063 0	0.002 0	0.119 2	0.001 4	709	69	726	8
22	54	71	87	0.82	0.065 1	0.001 6	0.118 9	0.001 4	776	52	724	8
23	63	87	73	1.19	0.066 4	0.001 7	0.119 4	0.001 7	820	54	727	10
24	194	263	206	1.28	0.064 7	0.001 2	0.119 4	0.001 4	765	237	727	8
25	62	81	103	0.79	0.066 1	0.001 9	0.118 7	0.001 4	809	64	723	8

样品号	w_B/%																							Mg^#
样品号	SiO₂		Al₂O₃		Fe₂O₃		FeO		CaO		MgO			K₂O		Na₂O		TiO₂		P₂O₅	MnO	LOI	Total	Mg^#
121001-1	52.28		15.84		3.49		4.57		5.02		6.25			0.103		5.95		0.7		0.107	0.136	4.85	99.29	71.1
121001-2	50.25		15.76		4		5.88		5.2		7.96			0.045		5.11		0.8		0.085	0.199	3.91	99.20	70.9
121001-3	50.21		17.54		2.68		6.34		2.28		8.79			0.024		5.77		0.78		0.094	0.168	4.42	99.10	71.4
121001-4	51.34		15.99		5.38		5.14		4.25		7.55			0.03		5.13		0.72		0.092	0.159	3.43	99.21	72.6
121001-5	49.49		15.52		4.13		5.72		6.4		7.79			0.023		4.87		0.81		0.082	0.196	4.19	99.22	71.0
121001-6	50.24		15.68		3.63		5.72		6.49		6.86			0.028		5.16		0.77		0.081	0.162	4.4	99.22	68.3
1210017	49.37		16.21		2.93		6.76		5.8		8.87			0.037		4.4		0.81		0.089	0.172	3.63	99.08	70.3
H083-2	54.1		14.69		1.74		7.81		6.6		5.72			0.8		4.48		1.17		0.123	0.179	1.59	99.00	56.9
H083-3	60.79		13.6		1.49		7.17		3.64		2.92			1.65		3.89		1.68		0.163	0.118	1.96	99.07	42.3
H083-4	57.14		13.2		0.974		8.37		5		2.44			0.337		4.21		1.45		0.191	0.153	5.5	98.97	34.4
H083-5	59.62		13.6		1.41		7.69		4.41		3.45			1.12		4.97		1.39		0.21	0.162	0.995	99.03	44.7
H083-6	48.32		16.12		6.42		6.79		9.88		3.38			1.41		1.6		1.88		0.266	0.2	2.74	99.01	47.3
H083-7	56.97		14.14		2.87		6.98		4.64		3.43			0.987		5.9		1.38		0.21	0.146	1.44	99.09	46.9
H083-8	54.49		14.76		2.28		7.76		5.75		4.65			0.528		5.1		1.42		0.171	0.185	1.91	99.00	51.9
样品号	w_B/10^-6
样品号	La		Ce		Pr		Nd		Sm		Eu			Gd		Tb		Dy		Ho	Er	Tm	Yb	Lu
121001-1	10.5		20.7		2.85		12.4		2.98		0.72			3.01		0.58		4.08		0.89	2.4	0.37	2.33	0.3
121001-2	6.5		13.7		1.98		9.32		2.56		0.78			2.84		0.58		4.02		0.86	2.35	0.37	2.31	0.3
121001-3	7.2		14.3		2.24		10.4		2.86		0.71			3.03		0.62		4.35		0.94	2.56	0.4	2.48	0.32
121001-4	9.51		16.2		2.37		10.6		2.7		1.21			2.82		0.55		3.8		0.82	2.27	0.36	2.31	0.29
121001-5	5.21		11.4		1.67		8.11		2.35		0.67			2.61		0.54		3.76		0.81	2.24	0.35	2.25	0.3
121001-6	5.42		11.8		1.73		8.13		2.35		0.93			2.62		0.53		3.68		0.78	2.1	0.32	2.18	0.25
1210017	6.3		13.3		1.93		9.12		2.59		0.82			2.84		0.57		4.05		0.85	2.37	0.37	2.37	0.29
H083-2	8.98		18.4		2.92		13.7		3.88		1.13			3.76		0.78		5.42		1.15	3.05	0.47	2.92	0.38
H083-3	21		39.4		5.67		24.7		5.92		1.47			5.47		1.06		6.99		1.42	3.76	0.58	3.67	0.48
H083-4	16.7		32.4		4.82		21.4		5.3		1.4			4.92		0.93		6.08		1.22	3.14	0.48	2.93	0.39
H083-5	19.9		37.3		5.56		24.6		6.3		1.65			5.91		1.15		7.54		1.53	3.95	0.59	3.69	0.46
H083-6	24.7		44.4		6.76		29.9		7.32		2.21			6.97		1.32		8.72		1.8	4.62	0.69	4.27	0.54
H083-7	9.27		17.2		2.55		11.4		2.91		0.72			2.86		0.56		3.68		0.76	1.96	0.3	1.86	0.24
H083-8	21.1		35.4		5.38		24		5.87		1.7			5.75		1.12		7.28		1.51	3.88	0.6	3.72	0.51
样品号	w_B/10^-6																					(La/ Yb)_N	δEu	δCe
样品号	Rb	Ba		Th		U		Nb		Ta		Sr	Zr		Hf		Y		∑REE			(La/ Yb)_N	δEu	δCe
121001-1	4.96		184		1.91		0.39		7.4		0.6			125		76.2		2.96		21.3	64.11	3.23	0.73	0.91
121001-2	1.79		112		1.6		0.3		2.63		0.23			89.7		63		2.57		19.8	48.47	2.02	0.88	0.93
121001-3	1.1		148		1.46		0.25		1.82		0.16			70.6		60.6		2.52		22.3	52.41	2.08	0.73	0.87
121001-4	0.71		256		1.4		0.22		1.6		0.14			138		53.8		2.24		18.8	55.81	2.95	1.33	0.81
121001-5	0.78		109		1.54		0.26		2.17		0.19			94.8		60.7		2.53		18.8	42.27	1.66	0.82	0.94
121001-6	0.86		76.4		1.54		0.25		2.3		0.21			124		57		2.43		18.4	42.82	1.78	1.14	0.94
1210017	1.28		71.7		1.71		0.31		2.42		0.21			202		64.7		2.66		20.2	47.77	1.91	0.92	0.93
H083-2	31.6		236		2.86		0.93		4.51		0.37			169		113		3.66		30.8	66.94	2.21	0.89	0.88
H083-3	72.7		442		6.77		1.77		11.2		0.86			151		236		6.96		37.5	121.59	4.10	0.78	0.87
H083-4	17.6		128		4.94		1.27		7.38		0.59			155		170		5.14		32.2	102.11	4.09	0.82	0.87
H083-5	50.5		258		4.76		1.35		8.09		0.6			86		189		5.5		40.2	120.13	3.87	0.81	0.86
H083-6	87.9		371		5.27		2.44		14.4		1.14			769		333		9.86		51	144.22	4.15	0.93	0.83
H083-7	42.5		265		4.17		1.11		7.06		0.55			92.6		165		5		19.8	56.27	3.57	0.75	0.85
H083-8	18.4		164		4.32		1.11		6.61		0.51			116		153		4.63		41.3	117.82	4.07	0.88	0.79

样品号	w_B/%																							Mg^#
样品号	SiO₂		Al₂O₃		Fe₂O₃		FeO		CaO		MgO			K₂O		Na₂O		TiO₂		P₂O₅	MnO	LOI	Total	Mg^#
121001-1	52.28		15.84		3.49		4.57		5.02		6.25			0.103		5.95		0.7		0.107	0.136	4.85	99.29	71.1
121001-2	50.25		15.76		4		5.88		5.2		7.96			0.045		5.11		0.8		0.085	0.199	3.91	99.20	70.9
121001-3	50.21		17.54		2.68		6.34		2.28		8.79			0.024		5.77		0.78		0.094	0.168	4.42	99.10	71.4
121001-4	51.34		15.99		5.38		5.14		4.25		7.55			0.03		5.13		0.72		0.092	0.159	3.43	99.21	72.6
121001-5	49.49		15.52		4.13		5.72		6.4		7.79			0.023		4.87		0.81		0.082	0.196	4.19	99.22	71.0
121001-6	50.24		15.68		3.63		5.72		6.49		6.86			0.028		5.16		0.77		0.081	0.162	4.4	99.22	68.3
1210017	49.37		16.21		2.93		6.76		5.8		8.87			0.037		4.4		0.81		0.089	0.172	3.63	99.08	70.3
H083-2	54.1		14.69		1.74		7.81		6.6		5.72			0.8		4.48		1.17		0.123	0.179	1.59	99.00	56.9
H083-3	60.79		13.6		1.49		7.17		3.64		2.92			1.65		3.89		1.68		0.163	0.118	1.96	99.07	42.3
H083-4	57.14		13.2		0.974		8.37		5		2.44			0.337		4.21		1.45		0.191	0.153	5.5	98.97	34.4
H083-5	59.62		13.6		1.41		7.69		4.41		3.45			1.12		4.97		1.39		0.21	0.162	0.995	99.03	44.7
H083-6	48.32		16.12		6.42		6.79		9.88		3.38			1.41		1.6		1.88		0.266	0.2	2.74	99.01	47.3
H083-7	56.97		14.14		2.87		6.98		4.64		3.43			0.987		5.9		1.38		0.21	0.146	1.44	99.09	46.9
H083-8	54.49		14.76		2.28		7.76		5.75		4.65			0.528		5.1		1.42		0.171	0.185	1.91	99.00	51.9
样品号	w_B/10^-6
样品号	La		Ce		Pr		Nd		Sm		Eu			Gd		Tb		Dy		Ho	Er	Tm	Yb	Lu
121001-1	10.5		20.7		2.85		12.4		2.98		0.72			3.01		0.58		4.08		0.89	2.4	0.37	2.33	0.3
121001-2	6.5		13.7		1.98		9.32		2.56		0.78			2.84		0.58		4.02		0.86	2.35	0.37	2.31	0.3
121001-3	7.2		14.3		2.24		10.4		2.86		0.71			3.03		0.62		4.35		0.94	2.56	0.4	2.48	0.32
121001-4	9.51		16.2		2.37		10.6		2.7		1.21			2.82		0.55		3.8		0.82	2.27	0.36	2.31	0.29
121001-5	5.21		11.4		1.67		8.11		2.35		0.67			2.61		0.54		3.76		0.81	2.24	0.35	2.25	0.3
121001-6	5.42		11.8		1.73		8.13		2.35		0.93			2.62		0.53		3.68		0.78	2.1	0.32	2.18	0.25
1210017	6.3		13.3		1.93		9.12		2.59		0.82			2.84		0.57		4.05		0.85	2.37	0.37	2.37	0.29
H083-2	8.98		18.4		2.92		13.7		3.88		1.13			3.76		0.78		5.42		1.15	3.05	0.47	2.92	0.38
H083-3	21		39.4		5.67		24.7		5.92		1.47			5.47		1.06		6.99		1.42	3.76	0.58	3.67	0.48
H083-4	16.7		32.4		4.82		21.4		5.3		1.4			4.92		0.93		6.08		1.22	3.14	0.48	2.93	0.39
H083-5	19.9		37.3		5.56		24.6		6.3		1.65			5.91		1.15		7.54		1.53	3.95	0.59	3.69	0.46
H083-6	24.7		44.4		6.76		29.9		7.32		2.21			6.97		1.32		8.72		1.8	4.62	0.69	4.27	0.54
H083-7	9.27		17.2		2.55		11.4		2.91		0.72			2.86		0.56		3.68		0.76	1.96	0.3	1.86	0.24
H083-8	21.1		35.4		5.38		24		5.87		1.7			5.75		1.12		7.28		1.51	3.88	0.6	3.72	0.51
样品号	w_B/10^-6																					(La/ Yb)_N	δEu	δCe
样品号	Rb	Ba		Th		U		Nb		Ta		Sr	Zr		Hf		Y		∑REE			(La/ Yb)_N	δEu	δCe
121001-1	4.96		184		1.91		0.39		7.4		0.6			125		76.2		2.96		21.3	64.11	3.23	0.73	0.91
121001-2	1.79		112		1.6		0.3		2.63		0.23			89.7		63		2.57		19.8	48.47	2.02	0.88	0.93
121001-3	1.1		148		1.46		0.25		1.82		0.16			70.6		60.6		2.52		22.3	52.41	2.08	0.73	0.87
121001-4	0.71		256		1.4		0.22		1.6		0.14			138		53.8		2.24		18.8	55.81	2.95	1.33	0.81
121001-5	0.78		109		1.54		0.26		2.17		0.19			94.8		60.7		2.53		18.8	42.27	1.66	0.82	0.94
121001-6	0.86		76.4		1.54		0.25		2.3		0.21			124		57		2.43		18.4	42.82	1.78	1.14	0.94
1210017	1.28		71.7		1.71		0.31		2.42		0.21			202		64.7		2.66		20.2	47.77	1.91	0.92	0.93
H083-2	31.6		236		2.86		0.93		4.51		0.37			169		113		3.66		30.8	66.94	2.21	0.89	0.88
H083-3	72.7		442		6.77		1.77		11.2		0.86			151		236		6.96		37.5	121.59	4.10	0.78	0.87
H083-4	17.6		128		4.94		1.27		7.38		0.59			155		170		5.14		32.2	102.11	4.09	0.82	0.87
H083-5	50.5		258		4.76		1.35		8.09		0.6			86		189		5.5		40.2	120.13	3.87	0.81	0.86
H083-6	87.9		371		5.27		2.44		14.4		1.14			769		333		9.86		51	144.22	4.15	0.93	0.83
H083-7	42.5		265		4.17		1.11		7.06		0.55			92.6		165		5		19.8	56.27	3.57	0.75	0.85
H083-8	18.4		164		4.32		1.11		6.61		0.51			116		153		4.63		41.3	117.82	4.07	0.88	0.79

样品号	w_B/%																						Mg^#
样品号	SiO₂		TiO₂		Al₂O₃		TFe₂O₃		MnO		MgO		CaO		Na₂O		K₂O		P₂O₅	BaO	LOI	Total	Mg^#
160725-1	73.24		0.41		13.36		3.00		0.14		0.51		0.65		5.60		1.93		0.05	0.06	0.55	99.50	25
160725-2	73.63		0.32		13.66		2.63		0.16		0.53		0.66		5.88		1.86		0.05	0.10	0.72	100.20	29
160725-3	73.33		0.36		13.67		2.70		0.17		0.56		0.70		5.74		2.00		0.05	0.11	0.83	100.22	29
160725-4	71.87		0.35		14.17		3.35		0.25		0.76		0.68		5.78		2.20		0.05	0.12	0.72	100.30	31
样品号	w_B/10^-6
样品号	La		Ce		Pr		Nd		Sm		Eu		Gd		Tb		Dy		Ho	Er	Tm	Yb	Lu
160725-1	29.30		56.30		6.30		25.00		5.29		1.91		5.17		0.80		4.72		1.05	3.16	0.49	2.97	0.45
160725-2	39.50		63.80		6.58		25.80		5.45		2.05		5.40		0.81		4.81		1.00	3.12	0.43	2.86	0.42
160725-3	39.50		67.40		7.13		28.20		6.12		2.21		6.15		0.86		5.15		1.05	3.01	0.45	2.74	0.40
160725-4	45.30		78.30		7.45		28.90		5.68		2.15		5.57		0.84		4.93		1.04	3.19	0.47	3.14	0.46
样品号	w_B/10^-6																				(La/ Yb)_N	δEu	δCe
样品号	Rb	Sr		Ba		Th		U		Zr	Hf	Nb		Ta		Y		ΣREE			(La/ Yb)_N	δEu	δCe
160725-1	92.70		126.00		552.00		4.17		1.09		169.00		4.40		7.00		0.50		28.30	142.91	7.08	1.10	0.97
160725-2	82.70		166.00		937.00		3.84		0.90		140.00		3.80		6.30		0.50		28.20	162.03	9.91	1.14	0.88
160725-3	81.60		167.00		1075.00		3.87		0.95		155.00		3.80		6.60		0.50		29.70	170.37	10.34	1.09	0.91
160725-4	96.40		152.50		1060.00		4.42		0.94		165.00		4.50		7.50		0.50		29.60	187.42	10.35	1.15	0.95
