Earth Science Frontiers ›› 2022, Vol. 29 ›› Issue (3): 239-247.DOI: 10.13745/j.esf.sf.2022.1.46
Previous Articles Next Articles
YE Xiangyu1(), CHEN Xuexia1, YU Bo1, ZHANG Min2, GUO Caijuan2, LU Xiaoxia1,*()
Received:
2022-01-15
Revised:
2022-02-23
Online:
2022-05-25
Published:
2022-04-28
Contact:
LU Xiaoxia
CLC Number:
YE Xiangyu, CHEN Xuexia, YU Bo, ZHANG Min, GUO Caijuan, LU Xiaoxia. Pollutant distribution and microbial characteristics at a petrochemical site in the Yangtze River Economic Belt[J]. Earth Science Frontiers, 2022, 29(3): 239-247.
点位 | 样品编号 | 深度/m | 有效序列数 | OTU数/Richness | Chao1 | Shannon_e | Simpson |
---|---|---|---|---|---|---|---|
A | A-2.4 | 2.4 | 38 846 | 2 017 | 2 019.9 | 5.75 | 0.010 |
A | A-4.0 | 4.0 | 33 155 | 1 387 | 1 390.3 | 4.41 | 0.051 |
A | A-4.5 | 4.5 | 44 892 | 1 467 | 1 470.5 | 4.43 | 0.033 |
A | A-5.5 | 5.5 | 49 012 | 1 122 | 1 125.2 | 2.91 | 0.171 |
A | A-7.5 | 7.5 | 31 459 | 596 | 605.6 | 2.64 | 0.314 |
B | B-2.4 | 2.4 | 36 422 | 2 145 | 2 147.3 | 5.89 | 0.009 |
B | B-4.0 | 4.0 | 29 742 | 1 117 | 1 121.4 | 3.53 | 0.142 |
B | B-4.5 | 4.5 | 41 625 | 970 | 974.2 | 3.02 | 0.133 |
B | B-5.0 | 5.0 | 28 294 | 1 095 | 1 099.7 | 3.38 | 0.134 |
B | B-7.5 | 7.5 | 46 683 | 795 | 801.0 | 2.29 | 0.273 |
C | C-3.2 | 3.2 | 48 404 | 1 290 | 1 294.2 | 3.70 | 0.105 |
C | C-4.0 | 4.0 | 49 236 | 843 | 847.5 | 2.23 | 0.319 |
C | C-5.0 | 5.0 | 52 117 | 1 341 | 1 344.1 | 2.95 | 0.161 |
C | C-7.5 | 7.5 | 49 358 | 765 | 770.4 | 3.95 | 0.054 |
Table 1 Sequencing results and α diversity index of soil samples
点位 | 样品编号 | 深度/m | 有效序列数 | OTU数/Richness | Chao1 | Shannon_e | Simpson |
---|---|---|---|---|---|---|---|
A | A-2.4 | 2.4 | 38 846 | 2 017 | 2 019.9 | 5.75 | 0.010 |
A | A-4.0 | 4.0 | 33 155 | 1 387 | 1 390.3 | 4.41 | 0.051 |
A | A-4.5 | 4.5 | 44 892 | 1 467 | 1 470.5 | 4.43 | 0.033 |
A | A-5.5 | 5.5 | 49 012 | 1 122 | 1 125.2 | 2.91 | 0.171 |
A | A-7.5 | 7.5 | 31 459 | 596 | 605.6 | 2.64 | 0.314 |
B | B-2.4 | 2.4 | 36 422 | 2 145 | 2 147.3 | 5.89 | 0.009 |
B | B-4.0 | 4.0 | 29 742 | 1 117 | 1 121.4 | 3.53 | 0.142 |
B | B-4.5 | 4.5 | 41 625 | 970 | 974.2 | 3.02 | 0.133 |
B | B-5.0 | 5.0 | 28 294 | 1 095 | 1 099.7 | 3.38 | 0.134 |
B | B-7.5 | 7.5 | 46 683 | 795 | 801.0 | 2.29 | 0.273 |
C | C-3.2 | 3.2 | 48 404 | 1 290 | 1 294.2 | 3.70 | 0.105 |
C | C-4.0 | 4.0 | 49 236 | 843 | 847.5 | 2.23 | 0.319 |
C | C-5.0 | 5.0 | 52 117 | 1 341 | 1 344.1 | 2.95 | 0.161 |
C | C-7.5 | 7.5 | 49 358 | 765 | 770.4 | 3.95 | 0.054 |
组分 | 各组分间的相关系数 | |||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
P1 | P2 | P3 | P4 | P5 | P6 | P7 | P8 | P9 | P10 | P11 | C6-C9 | C10-C40 | ||||||
P1 | 1.000 | |||||||||||||||||
P2 | -0.916** | 1.000 | ||||||||||||||||
P3 | -0.776** | 0.692** | 1.000 | |||||||||||||||
P4 | -0.349 | 0.284 | -0.108 | 1.000 | ||||||||||||||
P5 | 0.037 | -0.090 | -0.147 | 0.174 | 1.000 | |||||||||||||
P6 | -0.332 | 0.231 | 0.055 | 0.754** | 0.015 | 1.000 | ||||||||||||
P7 | 0.279 | -0.174 | -0.125 | -0.020 | 0.490 | 0.059 | 1.000 | |||||||||||
P8 | -0.604* | 0.442 | 0.560* | 0.121 | 0.099 | 0.165 | -0.218 | 1.000 | ||||||||||
P9 | -0.029 | 0.059 | -0.015 | -0.015 | 0.499 | 0.020 | 0.424 | -0.103 | 1.000 | |||||||||
P10 | -0.055 | -0.112 | 0.110 | 0.416 | -0.242 | 0.279 | -0.268 | 0.320 | -0.643* | 1.000 | ||||||||
P11 | -0.099 | 0.196 | -0.103 | 0.569* | 0.486 | 0.363 | 0.310 | -0.024 | 0.059 | 0.220 | 1.000 | |||||||
C6-C9 | -0.422 | 0.298 | 0.678** | -0.280 | -0.136 | -0.060 | -0.167 | 0.642* | -0.073 | 0.157 | -0.444 | 1.000 | ||||||
C10-C40 | -0.726** | 0.726** | 0.757** | -0.141 | 0.031 | -0.185 | -0.130 | 0.581* | 0.009 | -0.037 | -0.145 | 0.724** | 1.000 |
Table 2 Correlation coefficients between microorganisms, between pollutants, and between microorganisms and pollutants
组分 | 各组分间的相关系数 | |||||||||||||||||
---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
P1 | P2 | P3 | P4 | P5 | P6 | P7 | P8 | P9 | P10 | P11 | C6-C9 | C10-C40 | ||||||
P1 | 1.000 | |||||||||||||||||
P2 | -0.916** | 1.000 | ||||||||||||||||
P3 | -0.776** | 0.692** | 1.000 | |||||||||||||||
P4 | -0.349 | 0.284 | -0.108 | 1.000 | ||||||||||||||
P5 | 0.037 | -0.090 | -0.147 | 0.174 | 1.000 | |||||||||||||
P6 | -0.332 | 0.231 | 0.055 | 0.754** | 0.015 | 1.000 | ||||||||||||
P7 | 0.279 | -0.174 | -0.125 | -0.020 | 0.490 | 0.059 | 1.000 | |||||||||||
P8 | -0.604* | 0.442 | 0.560* | 0.121 | 0.099 | 0.165 | -0.218 | 1.000 | ||||||||||
P9 | -0.029 | 0.059 | -0.015 | -0.015 | 0.499 | 0.020 | 0.424 | -0.103 | 1.000 | |||||||||
P10 | -0.055 | -0.112 | 0.110 | 0.416 | -0.242 | 0.279 | -0.268 | 0.320 | -0.643* | 1.000 | ||||||||
P11 | -0.099 | 0.196 | -0.103 | 0.569* | 0.486 | 0.363 | 0.310 | -0.024 | 0.059 | 0.220 | 1.000 | |||||||
C6-C9 | -0.422 | 0.298 | 0.678** | -0.280 | -0.136 | -0.060 | -0.167 | 0.642* | -0.073 | 0.157 | -0.444 | 1.000 | ||||||
C10-C40 | -0.726** | 0.726** | 0.757** | -0.141 | 0.031 | -0.185 | -0.130 | 0.581* | 0.009 | -0.037 | -0.145 | 0.724** | 1.000 |
[1] | 谭海涛, 刘涛, 曹兴涛, 等. 石油石化企业土壤污染防治思考[J]. 中国石油和化工标准与质量, 2019, 39(8): 152-154. |
[2] | 唐冰. 天津某地区石化工业周边特征有机污染物分析[J]. 黑龙江科学, 2016, 7(8): 110-112, 115. |
[3] | 陈金花, 杨冬雪, 林杰, 等. 福建某石化企业土壤污染状态调查研究[J]. 海峡科学, 2019, 146(2): 30-34. |
[4] | 张丹, 姜林, 夏天翔, 等. 土壤-地下水系统中石油烃的迁移和生物降解述评[J]. 环境工程, 2015, 33(7): 1-6, 11. |
[5] | 翟勇. 某石化企业有机污染土壤调查及风险评估研究[J]. 环境工程, 2019, 37(增): 389-393. |
[6] | 孙颖, 董姝娟, 孟凡伟, 等. 某沿海石化企业地下水污染特性分析[J]. 油气田环境保护, 2016, 26(1): 42-44, 62. |
[7] | 孙娟, 王宁, 陈宏坤, 等. 石油污染土壤微生物群落分布特征[J]. 石油学报(石油加工), 2021, 37(2): 372-383. |
[8] | 郝春博, 王广才, 董建楠, 等. 石油污染地下水中细菌分子生态学研究[J]. 地学前缘, 2009, 16(4): 389-400. |
[9] |
CHEEMA S, LAVANIA M, LAL B. Impact of petroleum hydrocarbon contamination on the indigenous soil microbial community[J]. Annals of Microbiology, 2015, 65(1): 359-369.
DOI URL |
[10] |
ZHOU A X, ZHANG Y L, DONG T Z, et al. Response of the microbial community to seasonal groundwater level fluctuations in petroleum hydrocarbon-contaminated groundwater[J]. Environmental Science and Pollution Research International, 2015, 22: 10094-10106.
DOI URL |
[11] |
LV H, LIN X Y, SU X S, et al. 14C Isotopes and microbial community structures as evidence for biodegradation in a petroleum hydrocarbon-contaminated aquifer[J]. Environmental Earth Sciences, 2016, 75(2): 1-8.
DOI URL |
[12] | NÕLVAK H, LIGI T, KRIIPSALU M, et al. Application of microbial community profiling and functional gene detection for assessment of natural attenuation of petroleum hydrocarbons in boreal subsurface[J]. Boreal Environment Research, 2012, 17(2): 113-127. |
[13] | 中华人民共和国生态环境部. J 1020-2019土壤和沉积物石油烃(C6-C9)的测定吹扫捕集/气相色谱法[S]. 北京: 中国环境出版集团, 2019: 1-13. |
[14] | 中华人民共和国生态环境部. HJ 1021-2019土壤和沉积物石油烃(C10-C40)的测定气相色谱法[S]. 北京: 中国环境出版集团, 2019: 1-15. |
[15] | 中华人民共和国环境保护部. HJ 605-2011土壤和沉积物挥发性有机物的测定吹扫捕集气相色谱-质谱法[S]. 北京: 中国环境出版社, 2011: 1-22. |
[16] | 中华人民共和国环境保护部.HJ 834-2017 土壤和沉积物半挥发性有机物的测定气相色谱-质谱法[S]. 北京: 中国环境出版社, 2017: 1-28. |
[17] |
ZHANG Q, WANG G C, SUGIURA N, et al. Distribution of petroleum hydrocarbons in soils and the underlying unsaturated subsurface at an abandoned petrochemical site, North China[J]. Hydrological Processes, 2014, 28(4): 2185-2191.
DOI URL |
[18] | 中华人民共和国环境保护部, 国家市场监督管理总局.GB 36600-2018 土壤环境质量建设用地土壤污染风险管控标准(试行)[S]. 北京: 中国环境出版集团, 2018: 1-18. |
[19] | PIDGORSKYI V S, NOGINA T M. Biodegradation of petroleum hydrocarbons by actinobacteria and acinetobacteria strains producing biosurfactant[J]. Mikrobiolohichnyi Zhurnal (Kiev, Ukraine: 1993), 2016, 78(6): 92-103. |
[20] |
FRANK Y, BANKS D, AVAKIAN M, et al. Firmicutes is an important component of microbial communities in water-injected and pristine oil reservoirs, Western Siberia, Russia[J]. Geomicrobiology Journal, 2016, 33(5): 387-400.
DOI URL |
[21] |
ZHOU Z C, LIANG B, WANG L Y, et al. Identifying the core bacterial microbiome of hydrocarbon degradation and a shift of dominant methanogenesis pathways in the oil and aqueous phases of petroleum reservoirs of different temperatures from China[J]. Biogeosciences, 2019, 16(21): 4229-4241.
DOI URL |
[22] |
BALACHANDRAN C, DURAIPANDIYAN V, BALAKRISHNA K, et al. Petroleum and polycyclic aromatic hydrocarbons (PAHs) degradation and naphthalene metabolism in Streptomyces sp. (ERI-CPDA-1) isolated from oil contaminated soil[J]. Bioresource Technology, 2012, 112: 83-90.
DOI URL |
[23] |
BAOUNE H, APARICIO J D, PUCCI G, et al. Bioremediation of petroleum-contaminated soils using Streptomyces sp. Hlh1[J]. Journal of Soils and Sediments, 2019, 19(5): 2222-2230.
DOI URL |
[24] | 胡恒宇, 顾贵洲, 张强, 等. 残余油微生物气化产甲烷菌群的研究进展[J]. 化学与生物工程, 2014, 31(4): 9-14. |
[25] |
KUNAPULI U, JAHN M K, LUEDERS T, et al. Desulfitobacterium aromaticiuorans sp. nov. and Geobacter toluenoxydans sp. nov., iron-reducing bacteria capable of anaerobic degradation of monoaromatic hydrocarbons[J]. International Journal of Systematic and Evolutionary Microbiology, 2010, 60(3): 686-695.
DOI URL |
[26] | 梁家豪, 刘知远, 姚显阳, 等. UASB处理含油废水的研究及微生物群落动态分析[J]. 工业水处理, 2017, 37(12): 29-33. |
[27] | 梁英. 炼厂剩余活性污泥的水解酸化实验研究[D]. 北京: 中国石油大学(北京), 2017. |
